Siemens 3RX9501-0BA00 Power Supply Unit for SIRIUS 3RF Solid-State Relays

Industrial Automation Power Solution – Siemens 3RX9501-0BA00 | SIRIUS 3RF Series

In demanding industrial environments — from automotive assembly lines to chemical processing plants — solid-state relays must operate with zero tolerance for power instability. The Siemens 3RX9501-0BA00 is the dedicated auxiliary power supply unit engineered specifically for the SIRIUS 3RF series of solid-state relays, ensuring clean, regulated 24 VDC control power that keeps your switching devices performing at specification, shift after shift.

Without a properly matched power supply, even the most advanced solid-state relay becomes a liability — susceptible to nuisance tripping, thermal runaway, or premature failure. The 3RX9501-0BA00 eliminates that risk by delivering precisely conditioned auxiliary power, purpose-built for Siemens SIRIUS 3RF relay systems deployed across global industrial facilities.

Where This Product Is Used

The 3RX9501-0BA00 is specified by control engineers across a wide range of high-demand industrial sectors:

• Automotive Manufacturing: Body-in-white welding lines, paint shop conveyor drives, and press room motor control centers where SSR reliability is non-negotiable.
• Food & Beverage Processing: Hygienic zone heating control panels, pasteurization systems, and packaging line motor starters requiring stable auxiliary power.
• Plastics & Rubber Industry: Injection molding machine heater band control, extruder barrel temperature zones, and blow molding equipment.
• Chemical & Pharmaceutical Plants: Reactor temperature control loops, HVAC air handling units, and cleanroom environmental control systems.
• Building Automation & HVAC: Central chiller plant control panels, air handling unit motor starters, and BMS-integrated relay panels.
• Water & Wastewater Treatment: Pump station MCC panels, UV disinfection system controls, and aeration blower drive panels.

Technical Specifications

Parameter	Value
Part Number	3RX9501-0BA00
Manufacturer	Siemens
Product Series	SIRIUS 3RF / 3RX9 Accessories
Product Function	Auxiliary Power Supply Unit for SIRIUS 3RF Solid-State Relays
Output Voltage	24 V DC
Compatible Devices	SIRIUS 3RF Solid-State Relays (3RF2x, 3RF3x series)
Mounting	DIN Rail (35 mm)
Degree of Protection	IP20
Weight	Approx. 2,800 g (with packaging)
Standards	IEC/EN 60947-4-2, CE Marked

Note: All specifications are sourced from Siemens official documentation. Contact us to confirm datasheet details for your specific application.

Why Engineers Specify This Model

• OEM-Matched Design: Engineered by Siemens specifically for SIRIUS 3RF relays — no compatibility guesswork, no field modification required.
• Stable Auxiliary Power: Delivers regulated 24 VDC to relay control circuits, preventing false triggering caused by voltage fluctuations on shared power rails.
• DIN Rail Integration: Snaps directly onto standard 35 mm DIN rail alongside SIRIUS 3RF devices, minimizing panel footprint and wiring complexity.
• Reduced Panel Engineering Time: Pre-validated for use with SIRIUS 3RF — eliminates the need for custom power supply sizing calculations.
• Long Service Life: Siemens industrial-grade components rated for continuous duty in harsh electrical environments.
• Global Compliance: CE marked and IEC/EN 60947-4-2 compliant, accepted by panel builders and end-users worldwide.

Complete System Bill of Materials

The 3RX9501-0BA00 is typically specified alongside the following SIRIUS components for a complete solid-state relay control system:

• 3RF2310-1AA02 — SIRIUS 3RF2 Single-Phase Solid-State Relay, 10 A
• 3RF2320-1AA02 — SIRIUS 3RF2 Single-Phase Solid-State Relay, 20 A
• 3RF2330-1AA02 — SIRIUS 3RF2 Single-Phase Solid-State Relay, 30 A
• 3RF3410-1BA04 — SIRIUS 3RF3 Three-Phase Solid-State Relay, 10 A
• 3RX9501-0BA00 — This Unit: Auxiliary Power Supply
• 3RT2 Contactors — For hybrid switching configurations
• SITOP PSU100S — 24 VDC system power supply for broader panel power distribution

Contact our technical team at support@konmask.com for a complete BOM review and cross-reference service.

Compliance & Industry Standards

• IEC/EN 60947-4-2 — Low-voltage switchgear and controlgear: AC semiconductor motor controllers and starters
• CE Marking — Compliant with EU Low Voltage Directive and EMC Directive
• RoHS Compliant — Restriction of Hazardous Substances
• UL Recognition — Suitable for North American panel builder applications (verify current UL file with Siemens)

Quality Assurance & Sourcing

At Konmask.com, every Siemens component we supply undergoes a rigorous multi-point verification process before shipment:

• ✔ Authenticity Verification: Cross-referenced against Siemens factory serial number databases and holographic label inspection.
• ✔ Physical Inspection: Housing integrity, connector condition, label legibility, and packaging seal checked by trained QC staff.
• ✔ Documentation Package: Certificate of conformity, packing list, and optional third-party inspection report available on request.
• ✔ Traceability: Full supply chain traceability records maintained for each batch.

How to Source This Part

1. Submit an Inquiry: Email support@konmask.com or call +0086 19859288691 with your required quantity and delivery timeline.
2. Receive a Quotation: Our team will respond within 24 business hours with pricing, lead time, and availability confirmation.
3. Order Confirmation: Approve the proforma invoice and confirm your shipping address and preferred freight method.
4. Shipment & Tracking: Parts are packed to IEC transport standards and shipped with full tracking. Express DHL/FedEx options available.
5. After-Sales Support: Our technical team remains available post-delivery for installation guidance and compatibility questions.

Application-Specific FAQ

Q: Is the 3RX9501-0BA00 compatible with all SIRIUS 3RF relay variants?
A: It is designed for the SIRIUS 3RF series (3RF2x and 3RF3x families). Please confirm compatibility with your specific relay model by contacting our technical team with your full part number.

Q: Can this power supply unit be used with third-party solid-state relays?
A: The 3RX9501-0BA00 is an OEM accessory designed and validated for Siemens SIRIUS 3RF devices. Use with third-party SSRs is not recommended and may void equipment warranties.

Q: What is the input voltage range for this unit?
A: Please refer to the official Siemens datasheet for confirmed input specifications. Contact us and we will provide the full technical datasheet for your review.

Q: Do you offer expedited shipping for urgent plant shutdowns?
A: Yes. We maintain stock of critical Siemens SIRIUS accessories and can arrange same-day or next-day DHL Express dispatch for urgent requirements. Contact us immediately at +0086 19859288691.

Q: Can Konmask.com provide a certificate of conformity?
A: Yes. A certificate of conformity and full traceability documentation are available for every shipment upon request.

Q: What is the minimum order quantity?
A: We supply from single units to bulk OEM quantities. No minimum order quantity applies for standard stock items.

---
