Siemens 6AV2143-6GA00-0SN0 – High-Performance 15″ HMI Touch Panel | SIMATIC Comfort Panel Series
Engineering Background
The Siemens SIMATIC HMI Comfort Panel series represents the pinnacle of Siemens’ human-machine interface engineering, designed for demanding industrial automation environments where reliability, precision, and seamless SIMATIC integration are non-negotiable. The TP1500 Comfort (6AV2143-6GA00-0SN0) is the 15-inch widescreen flagship of this series, engineered for complex visualization tasks in process automation, machine building, and infrastructure control.
Product Positioning
Targeted at automation engineers and system integrators who require a high-resolution, multi-touch HMI with native PROFINET/MPI/PROFIBUS connectivity, the 6AV2143-6GA00-0SN0 delivers enterprise-grade visualization with TIA Portal-native configuration. It is the preferred choice for SIMATIC S7-300/400/1200/1500 PLC architectures requiring a large-format operator panel.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Order Number (MLFB) | 6AV2143-6GA00-0SN0 |
| Series | SIMATIC HMI Comfort Panel |
| Display Size | 15.4″ Widescreen TFT |
| Resolution | 1280 × 800 px (WXGA) |
| Color Depth | 16 million colors (24-bit) |
| Touch Technology | Resistive multi-touch (analog) |
| Processor | ARM Cortex-A8, 600 MHz |
| User Memory | 24 MB (project) / 64 MB (user data) |
| Operating System | Windows CE 6.0 |
| Communication Interfaces | 2× PROFINET (RJ45), 1× MPI/PROFIBUS DP (RS-422/485), 2× USB 2.0, 1× SD card slot, 1× CF card slot |
| Supply Voltage | 24 V DC (20.4–28.8 V) |
| Power Consumption | Approx. 30 W |
| Protection Rating | IP65 (front panel) / IP20 (rear) |
| Operating Temperature | 0 °C to +50 °C |
| Storage Temperature | -20 °C to +60 °C |
| Humidity | 10–90% RH (non-condensing) |
| Dimensions (W×H×D) | Approx. 404 × 272 × 56 mm |
| Weight | Approx. 4.45 kg |
| Mounting | Panel cutout, portrait or landscape |
| Configuration Software | SIMATIC WinCC (TIA Portal) V13 SP1 or higher |
| Certifications | CE, UL, cULus, ATEX Zone 2 (optional) |
| Country of Origin | Germany |
Proven Application Environments
- Discrete Manufacturing: Machine tool control panels, robotic cell HMI stations, assembly line supervisory displays
- Process Industry: Chemical plant DCS visualization, water treatment SCADA front-ends, oil & gas skid monitoring
- Building Automation: HVAC system control, energy management dashboards, BMS operator stations
- Power & Energy: Substation automation, generator control panels, UPS monitoring
- Food & Beverage: Hygienic-area operator panels (with appropriate enclosure), batch process control
- Infrastructure: Tunnel ventilation control, pump station automation, conveyor management
Engineering Advantages
- TIA Portal Native Integration: Zero-friction configuration within Siemens’ Totally Integrated Automation ecosystem — no third-party middleware required
- Dual PROFINET Ports: Enables media redundancy (MRP) and daisy-chain topologies without additional switches
- IP65 Front Protection: Suitable for wash-down environments and dusty industrial floors without additional enclosure
- High-Brightness WXGA Display: 1280×800 resolution supports complex P&ID diagrams, trend curves, and multi-window layouts simultaneously
- Unified Communication: Single panel supports PROFINET, MPI, and PROFIBUS DP — bridges legacy S7-300/400 and modern S7-1500 architectures
- Expandable Storage: SD and CF card slots allow recipe management, data logging, and firmware updates without PC connection
System Architecture & Signal Flow
The 6AV2143-6GA00-0SN0 operates as a PROFINET IO Controller or IO Device within a SIMATIC automation network. Typical signal flow:
- PLC Layer: SIMATIC S7-1500 / S7-1200 / S7-300 / S7-400 exchanges process data via PROFINET IRT or RT
- HMI Layer: TP1500 Comfort reads/writes PLC tags via optimized S7 communication; WinCC runtime renders dynamic screens at up to 10 Hz refresh
- Operator Layer: Resistive touch input triggers tag writes, alarm acknowledgments, and recipe parameter changes
- Data Layer: Alarm logs, trend data, and audit trails stored to SD/CF card or transferred via FTP/SMTP to SCADA/MES systems
- Remote Access: VNC server built-in for remote monitoring; OPC UA server optional for MES/ERP integration
Sourcing & Quality Verification
- All units sourced through verified industrial automation supply channels with full traceability
- Pre-shipment inspection: power-on test, display uniformity check, communication port verification
- Original Siemens packaging, labels, and documentation preserved where available
- Serial number and firmware version documented and provided with each shipment
- Warranty: 12 months from shipment date; DOA replacement within 7 business days
Procurement Process
- Inquiry: Submit your project BOM or single-line requirement to support@konmask.com with quantity and delivery timeline
- Quotation: Receive a formal quotation within 1 business day including unit price, lead time, and shipping options
- Order Confirmation: Purchase order accepted via email; proforma invoice issued for payment
- Quality Check: Pre-shipment inspection completed; photos/video provided on request
- Shipping: DHL Express / FedEx / sea freight options; export documentation (CO, packing list, commercial invoice) included
- After-Sales: Technical support available via email and WhatsApp; replacement RMA process initiated within 24 hours of fault report
Technical FAQ
Q: Is the 6AV2143-6GA00-0SN0 compatible with SIMATIC S7-1500?
A: Yes. It connects via PROFINET and is fully configurable in TIA Portal V13 SP1 and above alongside S7-1500 PLCs.
Q: Can this panel replace an older TP1500 Basic or TP1500 Comfort PN/DP?
A: The Comfort series supersedes the Basic series. Migration from older Comfort PN/DP panels is supported via TIA Portal project migration wizard with minimal rework.
Q: What is the maximum number of PLC connections?
A: Up to 8 simultaneous PLC connections (PROFINET + MPI/PROFIBUS combined).
Q: Does it support OPC UA?
A: OPC UA server functionality is available via WinCC Runtime Advanced license upgrade.
Q: What is the panel cutout dimension?
A: Refer to Siemens operating instructions document A5E02479740 for exact cutout dimensions (approximately 380 × 248 mm).
Q: Is ATEX certification available?
A: The standard 6AV2143-6GA00-0SN0 is not ATEX-rated. For Zone 2 applications, consult Siemens for the appropriate Ex-rated variant or third-party enclosure solution.
