Machine Visualization Solution – Siemens 6AV6647-0AG11-3AX0 | KTP400 Basic PN Series
Where This Product Is Used
The Siemens 6AV6647-0AG11-3AX0 KTP400 Basic PN is a compact 4-inch key/touch HMI panel engineered for machine-level operator interfaces across a wide range of industrial environments. Engineers and system integrators specify this panel in:
- Packaging machinery – conveyor line control, filling machine HMI stations, and labeling systems requiring a compact footprint
- Textile & printing equipment – local operator panels for tension control, speed adjustment, and fault acknowledgment
- HVAC & building automation – pump station monitoring, chiller control panels, and air-handling unit interfaces
- Food & beverage processing – washdown-adjacent control stations with IP65 front protection
- Water treatment & utilities – remote pump and valve control with PROFINET connectivity to S7-1200/1500 PLCs
- OEM machine builders – cost-effective HMI solution for series-produced machines requiring standardized SIMATIC integration
Technical Specifications
| Order Number (MLFB) | 6AV6647-0AG11-3AX0 |
| Series | SIMATIC HMI KTP400 Basic PN |
| Display Size | 4.3″ TFT widescreen |
| Resolution | 480 × 272 px |
| Colors | 64K colors |
| Touch / Keys | Touch screen + 4 function keys |
| Interface | PROFINET (RJ45 × 1) |
| Configuration Software | WinCC Basic (TIA Portal V13+) |
| Compatible PLCs | S7-1200, S7-1500, S7-300/400 (via PN) |
| Supply Voltage | DC 24 V (20.4–28.8 V) |
| Power Consumption | Max. 4.5 W |
| Front Protection | IP65 |
| Rear Protection | IP20 |
| Operating Temperature | 0 °C to +50 °C |
| Storage Temperature | −20 °C to +60 °C |
| Dimensions (W×H×D) | Approx. 164 × 114 × 33 mm |
| Weight | Approx. 0.45 kg |
| Mounting | Panel cutout, portrait or landscape |
| Memory | 10 MB user memory |
Why Engineers Specify This Model
- Native TIA Portal integration – configured entirely within WinCC Basic; no separate licensing required for basic visualization tasks
- PROFINET-first architecture – single Ethernet cable carries both HMI communication and PLC I/O data, simplifying cabinet wiring
- Compact 4.3″ form factor – fits standard 192 × 138 mm panel cutouts; ideal for space-constrained machine doors and enclosures
- Hybrid input – resistive touch plus 4 dedicated function keys allow gloved-hand operation in harsh environments
- IP65 front seal – withstands dust, coolant splash, and cleaning agents on the operator-facing surface
- Low power draw (≤4.5 W) – suitable for 24 VDC distributed power rails without dedicated PSU upsizing
- Proven SIMATIC ecosystem – direct replacement path to KTP700/KTP900 Basic PN without rewriting PLC logic
Complete System Bill of Materials
For a fully operational KTP400 Basic PN station, engineers typically source the following alongside 6AV6647-0AG11-3AX0:
- Siemens S7-1200 CPU (e.g., 6ES7214-1AG40-0XB0) – PLC host
- 24 VDC SITOP PSU100S power supply (e.g., 6EP1332-1SH52) – panel power
- IE FC RJ45 Plug 180 (6GK1901-1BB10-2AA0) – PROFINET field connector
- TIA Portal V16+ with WinCC Basic license – engineering software
- Panel mounting gasket & M4 mounting clamps (included in delivery)
- Shielded Cat5e/Cat6 Ethernet patch cable (≤100 m segment length)
Compliance & Industry Standards
- CE – EU Low Voltage Directive & EMC Directive compliant
- UL/cUL – Listed for North American industrial installations
- PROFINET – Certified PROFINET IO device (RT class)
- RoHS – Restriction of Hazardous Substances compliant
- IEC 61131-2 – Programmable controller equipment standard
- ATEX / IECEx – Not rated for hazardous area; use appropriate barriers if required
Quality Assurance & Sourcing
Every 6AV6647-0AG11-3AX0 unit offered through Konmask.com is:
- Sourced from verified Siemens-authorized distribution channels or factory-sealed surplus stock
- Inspected for intact holographic labels, firmware version consistency, and undamaged connectors before dispatch
- Shipped in original or equivalent ESD-safe packaging with full documentation
- Traceable via batch records maintained for a minimum of 3 years
How to Source This Part
To place an order or request a formal quotation for Siemens 6AV6647-0AG11-3AX0:
- Online: Add to cart directly on this page for standard lead times
- Bulk / project orders: Contact support@konmask.com for volume pricing and project scheduling
- Urgent requirements: Call or WhatsApp +0086 19859288691 for same-day stock confirmation
- Export / cross-border: We support DDP, DAP, and EXW Incoterms with full customs documentation
Application-Specific FAQ
Q: Can the 6AV6647-0AG11-3AX0 communicate with a Siemens S7-300 PLC?
A: Yes, via PROFINET. The S7-300 requires a PN-capable CPU (e.g., CPU 315-2 PN/DP) or a CP 343-1 communication processor.
Q: Is WinCC Comfort required, or is WinCC Basic sufficient?
A: WinCC Basic (included in TIA Portal Essentials) is sufficient for all KTP400 Basic PN projects. WinCC Comfort is not required and offers no additional benefit for this panel.
Q: What is the maximum number of tags/variables supported?
A: The KTP400 Basic PN supports up to 500 tags (process variables) in WinCC Basic.
Q: Can this panel be used in a vertical (portrait) orientation?
A: Yes. The panel supports both landscape and portrait mounting orientations via the panel cutout installation method.
Q: What is the typical lead time for 6AV6647-0AG11-3AX0?
A: In-stock units ship within 1–3 business days. For project quantities (>10 units), contact us for a dedicated lead time confirmation.
Q: Is this panel compatible with WinCC flexible?
A: No. The KTP400 Basic PN is exclusively configured via TIA Portal with WinCC Basic. WinCC flexible projects cannot be migrated directly to this panel.
