SIEMENS 6AV6671-5AE00-0AX0 – Portable HMI Mobile Panel | SIMATIC WinCC Flexible
Engineering Background: The SIEMENS 6AV6671-5AE00-0AX0 is a SIMATIC Mobile Panel designed for flexible, cable-connected operator control in industrial environments where fixed HMI stations are impractical. Engineered under Siemens’ SIMATIC HMI platform, it delivers full-featured visualization and machine control from any position on the production floor — ideal for commissioning, maintenance, and process monitoring tasks that demand operator mobility.
Product Positioning: This unit targets automation engineers and OEM machine builders who require a robust, portable HMI solution compatible with SIMATIC WinCC Flexible runtime. It bridges the gap between stationary panel PCs and handheld devices, offering a professional-grade touchscreen interface with integrated safety features including an enabling button and emergency stop, making it compliant with machine safety directives in demanding industrial deployments.
Complete Technical Specifications
- Part Number: 6AV6671-5AE00-0AX0
- Brand / Manufacturer: SIEMENS AG
- Product Family: SIMATIC HMI Mobile Panel
- Software Platform: WinCC Flexible Runtime
- Display: Color TFT touchscreen (resistive)
- Display Size: Refer to OEM datasheet (typically 6″ diagonal)
- Resolution: 320 × 240 px (QVGA)
- Operating Voltage: 24 V DC (via connecting cable)
- Communication Interface: PROFINET / Industrial Ethernet (RJ45 via spiral cable)
- Safety Functions: Integrated enabling button (3-position), Emergency Stop mushroom button
- Degree of Protection: IP65 (front), IP54 (rear)
- Operating Temperature: 0 °C to +50 °C
- Storage Temperature: −20 °C to +60 °C
- Weight: Approx. 440 g (unit only, excl. cable)
- Certifications: CE, UL, cULus
- Country of Origin: Germany
- HS Code: 8537.10
Proven Application Environments
- Machine tool commissioning and servo axis setup
- Robotic cell operator control and teach pendant replacement
- Conveyor and material handling line maintenance
- Packaging machinery format changeover and diagnostics
- Press and stamping line safety-rated operator stations
- Automotive assembly line flexible HMI access points
- Food & beverage processing equipment with washdown proximity
Engineering Advantages
- Full Mobility: Spiral connecting cable allows operator freedom across large machine footprints without sacrificing full HMI functionality.
- Integrated Safety: 3-position enabling button and E-Stop meet EN 60204-1 and ISO 13849 requirements, eliminating the need for external safety devices.
- WinCC Flexible Compatibility: Seamless project transfer from SIMATIC WinCC Flexible Engineering Studio — no additional runtime licensing required for standard configurations.
- Rugged Industrial Build: IP65 front protection and shock-resistant housing withstand vibration, dust, and fluid ingress in harsh production environments.
- Ergonomic Design: Balanced weight distribution and contoured grip reduce operator fatigue during extended commissioning sessions.
- PROFINET Native: Direct integration into SIMATIC S7-300/400/1200/1500 controller networks without additional gateways.
System Architecture & Signal Flow
The 6AV6671-5AE00-0AX0 connects to the control cabinet via a dedicated Mobile Panel connecting box (e.g., 6AV6671-5AE00-0AX0 compatible junction box). The spiral cable carries 24 V DC power, PROFINET Ethernet data, and safety-rated enabling/E-Stop signals over a single ruggedized cable assembly. The HMI runtime communicates with the PLC via standard S7 or OPC-UA tags configured in WinCC Flexible. The enabling button signal is hardwired through the connecting box to the machine safety relay circuit, ensuring SIL 2 / PLd-compliant operator presence detection independent of the HMI software layer.
Sourcing & Quality Verification
- All units sourced through authorized SIEMENS distribution channels or verified secondary market with full traceability documentation.
- Pre-shipment inspection includes: visual inspection, label authenticity check, firmware version verification, and functional power-on test.
- Original SIEMENS packaging, serial number, and CE/UL markings verified prior to dispatch.
- Counterfeit-risk mitigation: holographic labels, PCB date codes, and connector finish inspected against OEM reference samples.
- Warranty: 12-month Konmask quality guarantee covering DOA and latent manufacturing defects.
Procurement Process
- Step 1 – Inquiry: Submit your BOM or part number via support@konmask.com or WhatsApp +0086 19859288691.
- Step 2 – Quote: Receive a formal quotation with lead time, unit price, and shipping options within 24 business hours.
- Step 3 – Order Confirmation: Approve the proforma invoice; payment via T/T, PayPal, or credit card accepted.
- Step 4 – Shipment: Units dispatched via DHL Express / FedEx with full tracking. Export documentation (commercial invoice, packing list, CO) provided.
- Step 5 – After-Sales: Technical support available for integration questions; returns accepted within 30 days for unused units in original packaging.
Technical FAQ
Q: Is the 6AV6671-5AE00-0AX0 compatible with TIA Portal / WinCC Advanced?
A: This panel is designed for WinCC Flexible. For TIA Portal-based projects, consider the SIMATIC Mobile Panel 2nd Generation (e.g., 6AV2125 series) which natively supports WinCC Advanced/Comfort.
Q: What connecting box is required?
A: A compatible SIMATIC Mobile Panel connecting box (sold separately) is required to provide the junction between the fixed cabinet wiring and the mobile panel spiral cable. Consult Siemens catalog for the correct box variant matching your safety category.
Q: Can the enabling button be bypassed for testing?
A: The enabling button is hardwired into the safety circuit. Bypassing it is not recommended and may violate machine safety compliance. Use the 3-position enabling function as designed for commissioning mode.
Q: What is the maximum cable length?
A: Standard spiral cable extends to approximately 10 m. Extended cable assemblies may be available; consult Siemens accessories catalog for approved cable variants.
Q: Do you provide a certificate of conformity?
A: Yes. A Konmask inspection report and, where available, original Siemens CoC are provided upon request at time of order.
