SIEMENS 6ED1052-1MD00-0BA7 Display & Keypad Module – LOGO! 0BA7 Series
Imagine a compact automation system running a building’s HVAC schedule, pump control, or lighting sequence — and the operator has no way to read status, adjust setpoints, or acknowledge alarms on-site. Without a dedicated display and keypad interface, even the most capable LOGO! logic module becomes a black box, forcing costly service calls for the simplest parameter changes. The SIEMENS 6ED1052-1MD00-0BA7 eliminates that blind spot entirely, delivering a clear on-device interface that puts real-time control directly in the operator’s hands.
Within the LOGO! 0BA7 generation — Siemens’ most widely deployed compact PLC family — the 6ED1052-1MD00-0BA7 serves as the dedicated display and keypad expansion module. It pairs seamlessly with LOGO! Base Modules (6ED1052-xCC01-0BA7 / xDB01-0BA7 variants) to provide a 6-line × 16-character backlit LCD and a 6-button navigation keypad, enabling on-site program monitoring, parameter editing, and I/O diagnostics without a PC or LOGO! Soft Comfort software. Its global installed base spans millions of units across Europe, Asia, and the Americas, making it one of the most recognized operator interface accessories in the sub-PLC automation segment.
Technical Specifications
- Part Number: 6ED1052-1MD00-0BA7
- Series: SIEMENS LOGO! 0BA7
- Module Type: Display & Keypad Module (Operator Panel)
- Display: 6-line × 16-character backlit LCD
- Keypad: 6 navigation keys (ESC, OK, ▲, ▼, ◄, ►)
- Interface: Direct plug-in to LOGO! Base Module (0BA7 compatible)
- Supply Voltage: Powered via Base Module (no separate supply required)
- Operating Temperature: 0 °C to +55 °C
- Storage Temperature: −40 °C to +70 °C
- Protection Rating: IP20 (module), IP65 (front panel when panel-mounted)
- Mounting: DIN rail or direct snap-on to LOGO! Base Module
- Dimensions (W × H × D): 72 × 90 × 55 mm (approx.)
- Weight: Approx. 260 g
- Certifications: CE, UL, cULus, RCM
- Country of Origin: Germany / China (Siemens authorized production)
Note: All specifications are sourced from official Siemens LOGO! 0BA7 documentation. Konmask.com does not modify or fabricate technical data.
Key Features & Benefits
- On-Site Parameter Editing: Adjust timer values, setpoints, and program parameters directly on the device — no laptop required.
- Real-Time I/O Monitoring: View input/output states and internal flag status live on the LCD for rapid fault diagnosis.
- Alarm & Message Display: Display up to 5 custom text messages with variable values for operator guidance.
- Backlit LCD for Low-Light Environments: Readable in dim control cabinets or outdoor enclosures.
- Tool-Free Installation: Snaps directly onto any LOGO! 0BA7 Base Module — no wiring, no tools.
- Backward Compatibility: Compatible with LOGO! programs created in LOGO! Soft Comfort V7 and V8.
- Compact Footprint: Adds operator interface capability without increasing cabinet space requirements.
Industry & Equipment Applications
- Building Automation: HVAC scheduling, lighting control panels, access control systems
- Water & Wastewater: Pump station monitoring, level control, dosing systems
- Food & Beverage: Conveyor timing, temperature monitoring, batch sequencing
- Agriculture: Irrigation controllers, greenhouse climate management
- OEM Machinery: Packaging machines, small press controls, test benches
- Energy Management: Generator control panels, solar inverter monitoring
System Integration & Compatible Parts
The 6ED1052-1MD00-0BA7 is designed exclusively for the LOGO! 0BA7 ecosystem. Key compatible components include:
- Base Modules: 6ED1052-1CC01-0BA7, 6ED1052-1CC08-0BA7, 6ED1052-1FB00-0BA7, 6ED1052-1HB00-0BA7, 6ED1052-1MD08-0BA7
- Digital Expansion Modules: 6ED1055-1MB00-0BA2, 6ED1055-1NB10-0BA2
- Analog Expansion Modules: 6ED1055-1CB10-0BA2, 6ED1055-1MM00-0BA2
- Communication Module: LOGO! CMR2020 (6GK7 142-7EX00-0AX0) for remote access
- Programming Software: LOGO! Soft Comfort V8.3 (free download from Siemens)
- Power Supply: LOGO! Power 6EP1331-1SH03 (24 VDC, 2.5 A)
If you need a complete LOGO! 0BA7 system BOM or compatibility verification, contact our technical team at support@konmask.com.
Our Quality Assurance Process
Every SIEMENS 6ED1052-1MD00-0BA7 unit shipped by Konmask.com passes through a documented 4-step verification process:
- Source Verification: Units are procured exclusively from Siemens-authorized distributors or directly from Siemens regional warehouses. Purchase documentation is retained on file.
- Physical Authenticity Check: Label printing quality, hologram integrity, housing mold marks, and PCB color are cross-referenced against Siemens OEM standards.
- Functional Pre-Shipment Test: Display backlight, keypad response, and connector integrity are tested before packaging.
- Packaging & Documentation: Units ship in original or equivalent ESD-safe packaging with a Konmask inspection certificate and traceability record.
How to Order
- Submit your inquiry via the “Contact Us” button or email support@konmask.com.
- Provide your required quantity, delivery timeline, and destination country.
- Receive a formal quotation with lead time, shipping options, and payment terms within 24 business hours.
- Confirm the order — we handle export documentation, customs HS classification, and freight booking.
- Track your shipment with a dedicated logistics update from our team.
Minimum Order Quantity: 1 unit | Lead Time: 3–10 business days (stock-dependent) | Payment: T/T, PayPal, Western Union, L/C
Why Choose Konmask.com?
- ✅ Verified Genuine Parts — sourced from authorized Siemens supply chains
- ✅ Global Export Experience — shipping to 60+ countries with full customs documentation
- ✅ Technical Pre-Sales Support — engineers available to confirm compatibility before you order
- ✅ Competitive B2B Pricing — volume discounts available for OEM and system integrator accounts
- ✅ Fast Response — quotations within 24 hours, urgent orders prioritized
- ✅ After-Sales Warranty — 12-month warranty on all genuine parts supplied
Frequently Asked Questions
Q: Is the 6ED1052-1MD00-0BA7 compatible with LOGO! 0BA8 Base Modules?
A: No. The 0BA7 display module is mechanically and electrically designed for the 0BA7 generation only. For 0BA8 systems, you would need the 6ED1052-1MD08-0BA8 variant.
Q: Can I use this module without a LOGO! Base Module?
A: No — the display module has no standalone function. It must be connected to a compatible LOGO! 0BA7 Base Module to operate.
Q: Do you provide a certificate of authenticity?
A: Yes. Every shipment includes a Konmask.com inspection certificate. Original Siemens delivery notes are available upon request for orders from authorized stock.
Q: What is the warranty period?
A: We provide a 12-month warranty against manufacturing defects on all genuine parts. DOA (Dead on Arrival) units are replaced at no charge.
Q: Can you supply multiple LOGO! 0BA7 components in one order?
A: Yes. We regularly fulfill complete LOGO! system BOMs including base modules, expansion modules, power supplies, and accessories in a single consolidated shipment.
{
