Industrial HMI & Automation Solution – Siemens 6AV7800-1BA00-1AA0 | SIMATIC IPC477C
Where This Product Is Used
The Siemens 6AV7800-1BA00-1AA0 (SIMATIC IPC477C Panel PC) is deployed across demanding industrial environments where reliable human-machine interface (HMI) and real-time process visualization are mission-critical:
- Automotive Manufacturing: Body-in-white welding lines, paint shop SCADA stations, and end-of-line test benches requiring 24/7 uptime.
- Chemical & Pharmaceutical Plants: Batch process control panels operating under strict GMP and ATEX-adjacent environments.
- Food & Beverage Processing: Hygienic-area operator stations with stainless-steel enclosure integration, monitoring CIP/SIP cycles.
- Power Generation & Utilities: Substation HMI consoles and turbine control visualization panels.
- Machine Tool & OEM Equipment: Embedded into CNC machining centers and packaging machinery as the primary operator interface.
- Water & Wastewater Treatment: SCADA visualization nodes in pump stations and filtration control rooms.
Technical Specifications
| Parameter | Value |
|---|---|
| Order Number (MLFB) | 6AV7800-1BA00-1AA0 |
| Product Family | SIMATIC IPC477C |
| Form Factor | Panel PC (Flat Panel, Front-mount) |
| Display | 15″ TFT LCD, 1024 × 768 (XGA) |
| Processor | Intel® Celeron® M 1.0 GHz (or equivalent generation) |
| RAM | 512 MB DDR SDRAM (expandable) |
| Storage | 40 GB HDD / CompactFlash option |
| Operating System | Windows XP Professional / Windows Embedded Standard |
| Interfaces | 2× USB 2.0, 1× RJ45 Ethernet (10/100 Mbps), 1× RS-232, 1× PS/2 |
| Supply Voltage | 24 V DC (18–30 V DC) |
| Power Consumption | Approx. 60 W |
| Protection Rating | IP65 (front panel) |
| Operating Temperature | 0 °C to +50 °C |
| Storage Temperature | -20 °C to +60 °C |
| Relative Humidity | 5–95% (non-condensing) |
| Dimensions (W × H × D) | Approx. 400 × 310 × 75 mm |
| Weight | Approx. 12 kg |
| Mounting | Panel cut-out, VESA 75/100 optional |
| Country of Origin | Germany |
Why Engineers Specify This Model
- IP65 Front Protection: Sealed against dust ingress and water jets — essential for washdown and dusty production floors.
- 24 V DC Industrial Power: Directly compatible with standard PLC cabinet power rails; no additional PSU required.
- SIMATIC Ecosystem Integration: Native compatibility with SIMATIC WinCC, WinCC flexible, and Step 7 engineering environments.
- Fanless / Low-Vibration Design: Reduces mechanical wear in high-vibration machine tool applications.
- Long-Term Availability: Siemens IPC477C series supported by Siemens Industry Online Support (SIOS) with documented spare-parts lifecycle.
- Compact Panel-Mount Form Factor: Fits standard 19″ rack cutouts and custom enclosure designs without additional adapters.
Complete System Bill of Materials
For a fully operational SIMATIC IPC477C-based HMI station, engineers typically specify:
- 6AV7800-1BA00-1AA0 — SIMATIC IPC477C Panel PC (this unit)
- 6AV6 671-5AE11-0AX0 — WinCC Runtime Software License
- 6ES7 315-2EH14-0AB0 — SIMATIC S7-315 CPU (upstream PLC)
- 6GK7 343-1EX30-0XE0 — CP 343-1 Ethernet Communication Processor
- 6EP1 334-3BA10 — SITOP PSU100S 24 V / 10 A Power Supply
- 6XV1 840-2AH10 — PROFINET Industrial Ethernet Cable (per meter)
- Panel-mount enclosure with IP54 or better rating (customer-supplied)
Compliance & Industry Standards
- CE Marking — EU Machinery Directive & EMC Directive compliant
- UL/cUL Listed — North American safety certification
- IEC 61131-2 — Programmable controllers: equipment requirements
- EN 55011 / CISPR 11 — Industrial, scientific, and medical equipment EMC
- RoHS Compliant — Restriction of Hazardous Substances Directive
- WEEE Registered — Waste Electrical and Electronic Equipment
Quality Assurance & Sourcing
Konmask.com specializes in industrial automation components sourced from verified global supply chains. Every unit offered undergoes the following process:
- Visual and dimensional inspection against Siemens factory documentation
- Label and serial number verification against Siemens SIOS database references
- Functional power-on test where applicable
- Anti-static packaging with humidity indicator cards for long-haul shipping
- Full traceability documentation provided on request
We supply OEMs, system integrators, MRO procurement teams, and plant maintenance engineers globally.
How to Source This Part
- Request a Quote: Email support@konmask.com with your required quantity and delivery timeline.
- Phone / WhatsApp: +0086 19859288691 (Mon–Fri, 09:00–18:00 CST)
- Lead Time: In-stock units ship within 3–5 business days; sourced units typically 7–15 business days.
- Shipping: DHL Express, FedEx International Priority, and sea freight available. Export documentation (CO, packing list, commercial invoice) included.
- Payment: T/T (Bank Wire), PayPal, and trade assurance options available.
Application-Specific FAQ
Q: Is the 6AV7800-1BA00-1AA0 compatible with SIMATIC WinCC V7?
A: The IPC477C was originally designed for WinCC V6.x and WinCC flexible 2008. WinCC V7 can be installed on compatible hardware configurations — confirm OS and RAM requirements with your Siemens integrator before upgrading.
Q: Can this panel PC run STEP 7 and WinCC simultaneously?
A: Yes, with sufficient RAM (minimum 1 GB recommended for dual-application use). The base 512 MB configuration is best suited for dedicated HMI runtime only.
Q: What is the replacement / successor model?
A: Siemens has transitioned this series to the SIMATIC IPC477E and IPC477E Pro lines. Konmask can supply both legacy and current-generation units — contact us for a cross-reference quote.
Q: Is the front panel truly IP65 rated?
A: Yes, the front bezel achieves IP65 per IEC 60529 when correctly installed in a panel cutout with the supplied gasket. The rear enclosure is IP20.
Q: Do you provide a warranty?
A: All units are supplied with a 90-day functional warranty. Extended warranty and repair services are available — inquire at support@konmask.com.
