SIEMENS 6ES7134-4GB62-0AB0 Analog Input Module 2 AI High Speed | Replacement, Equivalent & Selection Guide
The SIEMENS 6ES7134-4GB62-0AB0 is a high-speed 2-channel analog input module designed for the ET 200S distributed I/O system, part of the SIMATIC S7-300/S7-400 automation platform. This page provides full technical specifications, compatible replacement models, application guidance, and a structured selection guide to help engineers and procurement teams make informed decisions.
Technical Specifications
- Part Number: 6ES7134-4GB62-0AB0
- Manufacturer: Siemens AG
- Product Family: SIMATIC ET 200S
- Module Type: Analog Input Module
- Number of Channels: 2 AI (Analog Input)
- Measurement Type: Voltage / Current (configurable)
- Resolution: 15-bit + sign
- Conversion Time: High-speed (≤ 0.5 ms per channel)
- Input Range (Voltage): ±10 V, 0–10 V, 1–5 V
- Input Range (Current): 0–20 mA, 4–20 mA, ±20 mA
- Supply Voltage: 24 V DC (via ET 200S power module)
- Isolation: Electrically isolated from backplane bus
- Dimensions (W×H×D): 15 mm × 81 mm × 52 mm
- Weight: Approx. 180 g
- Operating Temperature: 0 °C to +60 °C
- Protection Class: IP20
- Certifications: CE, UL, cULus, ATEX (Zone 2)
- Interface: ET 200S backplane bus
Compatible Replacement & Equivalent Models
The following modules are functionally compatible or serve as direct/near-direct replacements for the 6ES7134-4GB62-0AB0. Always verify firmware version and terminal block compatibility before substitution.
- 6ES7134-4GB11-0AB0 – Standard-speed 2 AI analog input module (ET 200S); suitable when high-speed conversion is not required
- 6ES7134-4GB01-0AB0 – Earlier revision; functionally equivalent, check hardware revision compatibility
- 6ES7134-4LB02-0AB0 – 4 AI high-speed module; use when additional channels are needed in the same slot width
- 6ES7134-6GD00-0AB0 – ET 200SP equivalent (2 AI, High Speed); requires ET 200SP base unit — suitable for new installations
- 6ES7331-7KF02-0AB0 – SM 331 analog input for S7-300 rack; not a drop-in replacement but functionally equivalent for rack-based systems
- Third-party equivalents: Wago 750-459, Phoenix Contact IB IL AI 2/SF — verify signal range and bus protocol before use
Why Choose the Original Model
- High-Speed Conversion: ≤ 0.5 ms conversion time per channel — critical for fast closed-loop control and motion applications
- Proven Reliability: Siemens SIMATIC platform with decades of industrial deployment history
- Seamless Integration: Native PROFIBUS DP / PROFINET compatibility via ET 200S interface module
- Flexible Signal Range: Supports both voltage and current inputs without hardware modification
- Compact Form Factor: 15 mm width maximizes rack density in space-constrained panels
- ATEX Zone 2 Rated: Suitable for use in potentially explosive atmospheres
Typical Applications
- High-speed PID control loops in process automation
- Pressure, temperature, and flow measurement in chemical and petrochemical plants
- Servo drive feedback signal acquisition
- Conveyor and packaging line speed monitoring
- Water treatment and HVAC control systems
- Power generation and energy management systems
- Pharmaceutical manufacturing (GMP-compliant environments)
System Compatibility
- Host System: SIMATIC ET 200S distributed I/O
- Interface Modules: 6ES7151-1AA05-0AB0, 6ES7151-1BA02-0AB0 (PROFIBUS DP); 6ES7151-3AA23-0AB0 (PROFINET)
- Power Modules Required: 6ES7138-4CA01-0AA0 or equivalent ET 200S PM-E
- Terminal Block: 6ES7193-4CA40-0AA0 (40-pin, included or ordered separately)
- Compatible PLCs: SIMATIC S7-300, S7-400, S7-1500 (via ET 200S IM)
- Engineering Software: STEP 7 V5.x, TIA Portal V13 and above
- Bus Protocol: PROFIBUS DP (up to 12 Mbit/s) / PROFINET IO
Selection Guide
Use the criteria below to determine whether the 6ES7134-4GB62-0AB0 is the right module for your application, or to identify the best alternative:
- Need high-speed (<1 ms) analog acquisition? → 6ES7134-4GB62-0AB0 ✓ (this module)
- Standard speed sufficient (>1 ms)? → Consider 6ES7134-4GB11-0AB0 (lower cost)
- Need 4 channels in one slot? → 6ES7134-4LB02-0AB0
- New installation, ET 200SP platform? → 6ES7134-6GD00-0AB0 (ET 200SP, modern alternative)
- S7-300 rack-based system? → SM 331 series (6ES7331-7KF02-0AB0)
- ATEX Zone 1 required? → Consult Siemens Ex-certified I/O catalog; this module covers Zone 2 only
- Budget-sensitive retrofit? → Contact Konmask for certified refurbished stock of 6ES7134-4GB62-0AB0
Quality Assurance & Sourcing
- Authenticity: All units sourced from authorized distributors or verified surplus channels with full traceability
- Inspection: Each module undergoes visual inspection, label verification, and functional power-on testing before shipment
- Packaging: Anti-static ESD packaging with original or equivalent protective foam
- Warranty: 12-month warranty against manufacturing defects
- Certifications on File: CE Declaration of Conformity available upon request
- Lead Time: In-stock items ship within 1–3 business days; ex-stock lead time quoted on request
How to Order
- Confirm your ET 200S interface module model and firmware version
- Verify terminal block part number (6ES7193-4CA40-0AA0 or equivalent)
- Add 6ES7134-4GB62-0AB0 to cart or contact us for bulk/project pricing
- Provide your project PO number and delivery address at checkout
- Request a Certificate of Conformity or test report if required for your QA process
📧 Email: support@konmask.com
📞 Phone/WhatsApp: +0086 19859288691
🌐 Website: https://Konmask.com
Replacement & Compatibility FAQ
Q: Can I replace 6ES7134-4GB62-0AB0 with 6ES7134-4GB11-0AB0 directly?
A: Yes, in most cases. The GB11 is the standard-speed variant. If your application does not require sub-millisecond conversion, it is a cost-effective drop-in replacement using the same terminal block and configuration parameters.
Q: Is this module compatible with TIA Portal?
A: Yes. The 6ES7134-4GB62-0AB0 is supported in TIA Portal V13 and above via the ET 200S hardware catalog (HSP if required for older TIA versions).
Q: Can I use this module with an ET 200SP interface module?
A: No. ET 200S and ET 200SP use different backplane bus architectures and are not cross-compatible. For ET 200SP, use the 6ES7134-6GD00-0AB0 instead.
Q: What is the difference between 6ES7134-4GB62-0AB0 and 6ES7134-4GB01-0AB0?
A: The -0AB0 suffix indicates the hardware revision. The GB62 is a later revision with improved EMC performance and extended temperature tolerance. Functionally they are equivalent for most applications.
Q: Do you supply refurbished units?
A: Yes. Konmask offers certified refurbished 6ES7134-4GB62-0AB0 modules that have been cleaned, tested, and re-labeled. Contact us for pricing and availability.
Q: What terminal block is required?
A: The standard terminal block is 6ES7193-4CA40-0AA0 (40-pin screw terminal). It is sold separately and must be ordered alongside the module if not already in your system.
