Packaging & Conveyor Automation Solution – SIEMENS 6ES7216-2BD23-0XB0 | S7-200 CPU 226
Where This Product Is Used
The SIEMENS 6ES7216-2BD23-0XB0 (CPU 226) is a high-density I/O programmable logic controller widely deployed across demanding industrial environments. Typical application sites include:
- Packaging lines – coordinating filling, sealing, labeling, and rejection stations with deterministic scan-cycle control
- Conveyor & material handling systems – managing variable-speed drives, diverters, and accumulation zones via PPI/MPI network
- Water & wastewater treatment – pump sequencing, level control, and alarm management in remote unmanned stations
- HVAC & building automation – chiller staging, AHU control, and BMS integration through Modbus RTU
- Textile & printing machinery – tension control, register correction, and web-break detection
- Food & beverage processing – batch recipe execution, CIP cycle management, and temperature loop control
- OEM machine builders – embedded controller for standalone machines requiring compact footprint and high I/O count
Technical Specifications
| Part Number | 6ES7216-2BD23-0XB0 |
| Series | SIMATIC S7-200 CPU 226 |
| Supply Voltage | 24 V DC |
| Digital Inputs (onboard) | 24 × 24 V DC |
| Digital Outputs (onboard) | 16 × 24 V DC transistor (sourcing) |
| Max. Expandable I/O | Up to 248 DI / 248 DO via expansion modules |
| Program Memory | 16 KB |
| Data Memory | 10 KB |
| Communication Ports | 2 × RS-485 (PPI / MPI / Freeport) |
| High-Speed Counters | 6 × HSC up to 30 kHz |
| Pulse Outputs | 2 × PTO/PWM up to 20 kHz |
| Real-Time Clock | Built-in (battery-backed) |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | −40 °C to +70 °C |
| Protection Rating | IP20 |
| Dimensions (W × H × D) | 196 × 80 × 62 mm |
| Weight | Approx. 268 g |
| Programming Software | STEP 7-Micro/WIN V4.0 SP9 or later |
Why Engineers Specify This Model
- Highest I/O density in the S7-200 family – 24 DI + 16 DO onboard eliminates the need for immediate expansion in most mid-size machines, reducing panel space and wiring cost.
- Dual RS-485 ports – Port 0 for HMI/SCADA communication and Port 1 for device-level networking run simultaneously without protocol conflicts.
- Freeport mode – enables custom ASCII/binary protocols for barcode scanners, weighing terminals, and third-party instruments without additional gateways.
- 6 high-speed counters @ 30 kHz – sufficient for multi-axis encoder feedback in conveyor and web-tension applications.
- Battery-backed RTC – supports time-stamped event logging and scheduled recipe execution without external clock modules.
- Proven field reliability – the S7-200 platform has a documented MTBF exceeding 100,000 hours in continuous industrial duty.
Complete System Bill of Materials
A typical CPU 226-based control panel for a packaging line includes the following components. Contact Konmask for bundle pricing.
- 6ES7216-2BD23-0XB0 – CPU 226 DC/DC/DC (this unit)
- 6ES7221-1BF22-0XA0 – EM 221 8 × DI 24 V DC expansion
- 6ES7222-1BF22-0XA0 – EM 222 8 × DO 24 V DC expansion
- 6ES7231-0HC22-0XA0 – EM 231 4 × AI analog input module
- 6ES7232-0HB22-0XA0 – EM 232 2 × AO analog output module
- 6ES7901-3CB30-0XA0 – PC/PPI+ cable for programming
- 6AV6641-0CA01-0AX1 – TD 400C text display (optional HMI)
- 6EP1332-1SH43 – SITOP PSU100S 24 V / 5 A power supply
Compliance & Industry Standards
- CE Marking – compliant with EU Low Voltage Directive 2014/35/EU and EMC Directive 2014/30/EU
- UL Listed – UL 508 (Industrial Control Equipment)
- cULus – Canadian market approval
- FM Approved – Class I, Division 2, Groups A, B, C, D (hazardous locations)
- IEC 61131-2 – programmable controller hardware standard
- RoHS – compliant with EU Directive 2011/65/EU
Quality Assurance & Sourcing
Konmask.com sources the 6ES7216-2BD23-0XB0 exclusively through verified industrial distribution channels. Every unit undergoes the following before dispatch:
- Visual inspection against SIEMENS factory cosmetic standards
- Label and date-code authentication (firmware version cross-checked)
- Power-on functional test: I/O scan, communication port handshake, RTC verification
- Anti-static packaging with humidity indicator card
- Traceability record retained for 5 years
We do not list, sell, or knowingly handle counterfeit or refurbished-as-new product. If a unit fails authentication at any stage, it is quarantined and not shipped.
How to Source This Part
- Add to cart – select quantity and proceed to checkout on Konmask.com.
- Request a quote – for orders of 3+ units, email support@konmask.com with your project BOM for volume pricing.
- Lead time – in-stock units ship within 1–2 business days; ex-stock orders typically 5–10 business days depending on origin warehouse.
- Export documentation – commercial invoice, packing list, and certificate of origin available for international shipments. HS Code: 8537.10.
- Technical pre-sales support – our engineers can review your I/O list and confirm module compatibility before purchase. Call +0086 19859288691.
Application-Specific FAQ
Q: Can the CPU 226 DC/DC/DC control AC loads directly?
A: No. The transistor outputs are 24 V DC sourcing. For AC loads, use an intermediate relay or solid-state relay (SSR) module. Konmask can supply compatible relay output expansion modules.
Q: Is this CPU compatible with STEP 7 (TIA Portal)?
A: No. The S7-200 series uses STEP 7-Micro/WIN exclusively. TIA Portal supports S7-300/400/1200/1500 families. If you are migrating to TIA Portal, consider the S7-1200 CPU 1214C as a functional successor.
Q: How many expansion modules can be connected?
A: The CPU 226 supports up to 7 expansion modules on the local I/O bus, achieving a maximum of 248 DI / 248 DO / 35 AI / 12 AO.
Q: What is the maximum network size for a PPI multi-master network?
A: Up to 32 nodes on a single PPI segment at baud rates from 9.6 kbps to 187.5 kbps. Repeaters can extend the network to 126 nodes.
Q: Does the unit include a memory card slot?
A: Yes. The CPU 226 accepts a SIEMENS EEPROM memory cartridge (6ES7291-8GF23-0XA0) for program backup and recipe storage without a PC connection.
Q: What warranty applies to this purchase?
A: Konmask provides a 12-month warranty against manufacturing defects from the date of shipment. Warranty claims are processed within 5 business days of receipt of the returned unit.
