Siemens 6ES7223-1PH22-0XA0 Digital I/O Expansion Module – SIMATIC S7-200 SMART EM 223
When a production line loses its digital I/O expansion capability, the consequences are immediate and costly: machine sequences halt, sensor signals go unread, and actuator commands fail to execute. In high-throughput manufacturing environments — from automotive assembly to packaging lines — even a single failed I/O module can cascade into hours of unplanned downtime. The Siemens 6ES7223-1PH22-0XA0 is the precision-engineered solution that keeps these critical control loops intact, delivering reliable digital signal processing exactly where your system demands it.
Within the SIMATIC S7-200 SMART family, the EM 223 series occupies a pivotal role as the go-to digital combination I/O expansion module. The 6ES7223-1PH22-0XA0 variant — featuring 8 digital inputs and 8 transistor (solid-state) outputs — is one of the most widely deployed expansion modules in global OEM machine builds, recognized for its compact DIN-rail footprint, fast response times, and seamless integration with the S7-200 SMART CPU. It is trusted by system integrators and machine builders across Asia, Europe, and the Americas.
Technical Specifications
- Part Number: 6ES7223-1PH22-0XA0
- Series: SIMATIC S7-200 SMART EM 223
- Module Type: Digital Combination I/O Expansion Module
- Digital Inputs: 8 × 24 V DC
- Digital Outputs: 8 × Transistor (Source/Sink), 24 V DC
- Output Current per Channel: 0.75 A
- Input Voltage Range: 20.4 – 28.8 V DC
- Supply Voltage: 24 V DC (via CPU bus connector)
- Isolation: Optocoupler isolation between field and logic circuits
- Input Delay: Configurable (0.2 ms – 12.8 ms)
- Dimensions (W × H × D): 45 × 100 × 81 mm
- Weight: Approx. 180 g
- Mounting: DIN rail (35 mm)
- Operating Temperature: 0 °C to +55 °C
- Storage Temperature: −40 °C to +70 °C
- Protection Rating: IP20
- Certifications: CE, UL, cULus, FM
Key Features & Benefits
- Compact 45 mm Width: Maximizes panel space efficiency in tight control cabinet installations.
- Transistor Outputs: Solid-state switching ensures long service life with no mechanical wear, ideal for high-cycle applications.
- Plug-and-Play Expansion: Connects directly to S7-200 SMART CPUs via the integrated bus connector — no additional wiring harness required.
- Optocoupler Isolation: Protects the CPU from field-side voltage spikes and electrical noise.
- Configurable Input Filtering: Adjustable input delay reduces false triggering from noisy industrial environments.
- LED Status Indicators: Per-channel I/O status LEDs enable rapid field diagnostics without a laptop or programmer.
- Wide Operating Temperature Range: Reliable performance in demanding factory floor conditions up to 55 °C.
Industry & Equipment Applications
- Packaging Machinery: Conveyor control, product counting, reject gate actuation
- Textile & Printing Equipment: Tension control, web break detection, register mark sensing
- Food & Beverage Processing: Filling machine sequencing, level detection, valve control
- HVAC & Building Automation: Fan/pump start-stop, damper control, alarm outputs
- Material Handling: Conveyor routing, pallet transfer, end-of-line detection
- Water Treatment: Pump station control, valve sequencing, fault signaling
- OEM Machine Builders: General-purpose I/O expansion for any S7-200 SMART-based control system
System Integration & Compatible Parts
The 6ES7223-1PH22-0XA0 is designed exclusively for use with the SIMATIC S7-200 SMART CPU family. Compatible CPUs and related modules include:
- S7-200 SMART CPUs: CPU SR20, CPU SR30, CPU SR40, CPU SR60, CPU ST20, CPU ST30, CPU ST40, CPU ST60
- Analog Expansion Modules: EM AM03, EM AM06, EM AE04, EM AQ02
- Other Digital Expansion Modules: 6ES7222-1BF22-0XA0 (8DO), 6ES7221-1BF22-0XA0 (8DI)
- SIMATIC S7-200 SMART Programming Cable / STEP 7-Micro/WIN SMART Software
- 24 V DC Power Supply: e.g., SITOP PSU100S 6EP1334-2BA20
