SIEMENS 6ES7390-1AB60-0AA0 S7-300 Mounting Rail 2000mm | Replacement, Equivalent & Selection Guide
The SIEMENS 6ES7390-1AB60-0AA0 is a 2000 mm (2 m) mounting rail designed for the SIMATIC S7-300 PLC system. It serves as the mechanical backbone for assembling S7-300 CPU, signal, function, and communication modules into a complete control rack. Sourced and stocked by Konmask.com, this rail is available for immediate dispatch to global industrial buyers.
Technical Specifications
- Part Number: 6ES7390-1AB60-0AA0
- Series: SIMATIC S7-300
- Type: Mounting Rail (Profile Rail)
- Length: 2000 mm (2 m)
- Material: Aluminum alloy, silver anodized
- Mounting: Standard DIN rail compatible slots for S7-300 modules
- Compatible Systems: SIMATIC S7-300 (all CPU variants)
- Weight: Approx. 300 g
- Country of Origin: Germany
- SIEMENS Product Family: SIMATIC S7-300 Accessories
Compatible Replacement & Equivalent Models
The table below lists direct replacements and functionally equivalent mounting rails for the 6ES7390-1AB60-0AA0:
| Part Number | Length | Notes |
|---|---|---|
| 6ES7390-1AB60-0AA0 | 2000 mm | Original — this product |
| 6ES7390-1AE80-0AA0 | 480 mm | Shorter rail, same series |
| 6ES7390-1BC00-0AA0 | 530 mm | Standard rack length |
| 6ES7390-1AF30-0AA0 | 830 mm | Mid-length option |
| 6ES7390-1AJ30-0AA0 | 1000 mm | 1 m rail, same profile |
| Third-party 2m DIN rail | 2000 mm | Compatible if S7-300 slot pitch matches; verify before use |
Note: All SIEMENS S7-300 mounting rails share the same cross-section profile. Length is the primary selection variable.
Why Choose the Original Model
- Guaranteed fit: Precision-machined to SIEMENS S7-300 module slot pitch — no alignment issues.
- Certified quality: Manufactured to IEC/EN standards; CE marked.
- Full 2 m span: Ideal for large racks requiring maximum module density.
- Long-term availability: Stocked by authorized distributors including Konmask.com.
- Warranty compliance: Using OEM rails preserves SIEMENS system warranty.
Typical Applications
- Large-scale S7-300 control panels requiring high module count
- Machine tool automation and CNC control cabinets
- Process control systems in chemical, oil & gas, and water treatment plants
- Building automation and HVAC control racks
- Conveyor and material handling system controllers
- Replacement rail for existing S7-300 installations during panel refurbishment
System Compatibility
- CPU modules: All S7-300 CPUs (CPU 312, 313, 314, 315, 316, 317, 318, 319 series)
- Signal modules (SM): SM 321, SM 322, SM 331, SM 332, SM 334, SM 338
- Function modules (FM): FM 350, FM 351, FM 352, FM 353, FM 354, FM 355
- Communication modules (CP): CP 340, CP 341, CP 342, CP 343, CP 344
- Power supply modules (PS): PS 305, PS 307 series
- Interface modules (IM): IM 360, IM 361, IM 365
Selection Guide
Use the following criteria to select the correct mounting rail length for your S7-300 system:
- Module count: Each S7-300 module occupies 40 mm width. A 2000 mm rail accommodates up to ~48 single-width modules (minus PS and CPU space).
- Cabinet depth: Ensure your enclosure depth allows for the 2 m rail plus wiring clearance.
- Expansion rows: For multi-row configurations, use IM 360/361 interface modules; each row requires its own rail.
- Cut-to-length: The 2 m rail can be cut on-site if a shorter custom length is needed — use a metal saw and deburr edges.
- Grounding: Ensure the rail is properly grounded to the cabinet chassis per SIEMENS installation guidelines.
Quality Assurance & Sourcing
- All units sourced from authorized SIEMENS distribution channels or verified surplus stock.
- Each item inspected for dimensional accuracy, surface finish, and slot integrity before dispatch.
- Packaging: original SIEMENS packaging where available; protective poly-bag and cardboard for surplus stock.
- Traceability: batch records and supplier documentation available on request.
- Export compliance: EAR99 / non-controlled; no export license required for most destinations.
How to Order
- Confirm part number: 6ES7390-1AB60-0AA0
- Specify quantity required.
- Add to cart and proceed to checkout, or contact us for bulk/project pricing.
- For urgent requirements, email support@konmask.com with your project timeline.
- Lead time: in-stock items ship within 1–3 business days; ETA confirmed at order.
Replacement & Compatibility FAQ
- Q: Can I use a third-party DIN rail instead of 6ES7390-1AB60-0AA0?
- A: Standard 35 mm DIN rails are NOT compatible. The S7-300 uses a proprietary SIEMENS profile rail with specific slot pitch. Only SIEMENS 6ES7390-1Axx0-0AA0 series rails are guaranteed compatible.
- Q: Is 6ES7390-1AB60-0AA0 compatible with S7-400 or S7-1500?
- A: No. S7-400 and S7-1500 use different rail profiles. This rail is exclusively for S7-300 systems.
- Q: Can I cut the 2 m rail to a shorter length?
- A: Yes. The aluminum rail can be cut with a metal saw. Deburr all edges and re-drill ground screw holes as needed.
- Q: What is the difference between 6ES7390-1AB60-0AA0 and 6ES7390-1AJ30-0AA0?
- A: Length only — 2000 mm vs. 1000 mm. The cross-section profile and module compatibility are identical.
- Q: Do you offer project/bulk pricing?
- A: Yes. Contact support@konmask.com for volume quotes.
