Process Automation & Large-Scale Manufacturing Solution — SIEMENS 6ES7416-2XP07-0AB0 | CPU 416-2 S7-400 Series
Where This Product Is Used
The SIEMENS 6ES7416-2XP07-0AB0 CPU 416-2 is a high-performance central processing unit designed for demanding industrial automation environments. Engineers and system integrators specify this module across a wide range of critical applications:
- Automotive Manufacturing: Body-in-white welding lines, paint shop conveyors, and powertrain assembly requiring deterministic cycle times and high I/O throughput.
- Chemical & Petrochemical Plants: Continuous process control, reactor management, and safety-instrumented system (SIS) coordination where reliability is non-negotiable.
- Steel & Metal Processing: Rolling mill automation, furnace temperature control, and crane/hoist sequencing with heavy PROFIBUS DP field device networks.
- Water & Wastewater Treatment: SCADA-integrated pump station control, filtration sequencing, and distributed remote I/O via PROFIBUS.
- Power Generation & Utilities: Turbine control auxiliaries, switchgear automation, and substation interlocking logic.
- Pharmaceutical & Food Processing: Batch process management (ISA-88 compliant), CIP/SIP cycle control, and FDA-regulated production line automation.
- Logistics & Material Handling: High-speed sortation systems, automated storage and retrieval systems (AS/RS), and conveyor network coordination.
Technical Specifications
| Parameter | Value |
|---|---|
| Order Number (MLFB) | 6ES7416-2XP07-0AB0 |
| Product Family | SIMATIC S7-400 |
| CPU Type | CPU 416-2 |
| Firmware Version | V7.0 (07 revision) |
| Work Memory | 8 MB (4 MB code / 4 MB data) |
| Load Memory | Expandable via MMC (up to 64 MB) |
| Processing Speed (Bit Operations) | 0.08 µs |
| Processing Speed (Word Operations) | 0.08 µs |
| Communication Interfaces | MPI (187.5 kbps – 12 Mbps) + PROFIBUS DP Master/Slave |
| MPI/DP Interface | 9-pin Sub-D connector |
| Max. I/O Addresses | 16 KB inputs / 16 KB outputs |
| Max. Number of Modules | Up to 131,072 digital I/O / 8,192 analog I/O |
| Counters / Timers | 2,048 / 2,048 |
| Data Blocks | Up to 8,191 DBs |
| Supply Voltage | 24 V DC (via backplane bus) |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +70 °C |
| Dimensions (W × H × D) | 50 × 290 × 219 mm |
| Weight | Approx. 1,980 g |
| Protection Class | IP20 |
Why Engineers Specify This Model
- High Memory Capacity: 8 MB work memory supports large, complex programs with extensive data logging — ideal for multi-axis and multi-zone process control.
- Dual Communication Ports: Simultaneous MPI and PROFIBUS DP connectivity allows seamless integration with SIMATIC HMI panels, distributed I/O (ET 200 series), drives (SINAMICS, MICROMASTER), and third-party field devices.
- Proven S7-400 Platform: Part of Siemens’ most robust PLC family, with decades of field-proven reliability in mission-critical installations worldwide.
- STEP 7 & TIA Portal Compatible: Fully programmable via SIMATIC STEP 7 V5.x and supported in TIA Portal with legacy project migration tools.
- Hot-Swap Capability: S7-400 rack architecture supports module replacement without full system shutdown, minimizing production downtime.
- Scalable Architecture: Expandable across multiple racks via IM (Interface Module) connections, supporting large-scale plant-wide automation.
- Firmware 07 Revision: Latest stable firmware for the 416-2 variant, incorporating bug fixes and enhanced diagnostic capabilities.
Complete System Bill of Materials
For a complete S7-400 control system using the 6ES7416-2XP07-0AB0, the following components are typically required:
- Rack: 6ES7400-1JA01-0AA0 (UR1, 18-slot) or 6ES7400-1TA01-0AA0 (UR2, 9-slot)
- Power Supply: 6ES7407-0DA02-0AA0 (PS 407, 4A) or 6ES7407-0KA02-0AA0 (PS 407, 10A)
- CPU (this unit): 6ES7416-2XP07-0AB0
- Memory Card: 6ES7952-1KM00-0AA0 (MMC 64 MB) — required for program storage
- Digital Input Module: 6ES7421-1BL01-0AA0 (SM 421, 32 DI × 24 VDC)
- Digital Output Module: 6ES7422-1BL00-0AA0 (SM 422, 32 DO × 24 VDC)
- Analog Input Module: 6ES7431-1KF20-0AB0 (SM 431, 8 AI)
- Analog Output Module: 6ES7432-1HF00-0AB0 (SM 432, 8 AO)
- PROFIBUS DP Cable: 6XV1830-0EH10 (per meter, shielded)
- PROFIBUS Connector: 6ES7972-0BB52-0XA0 (90° with PG socket)
- MPI Programming Cable: 6ES7901-0BF00-0AA0 (PC Adapter USB)
Compliance & Industry Standards
- CE Marking: Compliant with EU Low Voltage Directive and EMC Directive
- UL/cUL Listed: UL 508 (Industrial Control Equipment)
- IEC 61131-2: Programmable Controllers — Equipment Requirements and Tests
- PROFIBUS Standard: IEC 61158 / EN 50170 compliant DP Master Class 1
- EMC: EN 61000-6-2 (Immunity) / EN 61000-6-4 (Emissions)
- RoHS: Compliant with Directive 2011/65/EU
- ATEX / IECEx: Not rated for Zone 0/1 — use appropriate barriers for hazardous area installations
Quality Assurance & Sourcing
At Konmask.com, every SIEMENS module we supply undergoes a rigorous multi-point verification process before dispatch:
- Authenticity Verification: Each unit is cross-referenced against Siemens’ MLFB database. Holographic labels, date codes, and PCB markings are inspected for consistency.
- Functional Testing: Where applicable, modules are bench-tested for power-on self-test (POST) completion and communication port integrity.
- Condition Grading: Units are clearly graded as New (factory-sealed), Refurbished (tested & restored), or Used (as-removed, tested). Grade is confirmed at order.
- Traceability: Full supply chain documentation available on request, including country of origin and distributor chain records.
- Packaging: Anti-static ESD bags, foam-lined cartons, and moisture-barrier packaging for international shipment.
- Warranty: 12-month replacement warranty on all verified units. Extended warranty available on request.
How to Source This Part
Sourcing the 6ES7416-2XP07-0AB0 through Konmask.com is straightforward:
- Step 1 — Confirm Your Requirement: Verify the exact MLFB (6ES7416-2XP07-0AB0) against your existing system documentation or STEP 7 hardware configuration.
- Step 2 — Request a Quote: Contact us via email at support@konmask.com or WhatsApp/phone at +0086 19859288691 with your required quantity and delivery timeline.
- Step 3 — Receive Confirmation: We confirm stock availability, unit condition grade, lead time, and pricing within 24 business hours.
- Step 4 — Place Order & Payment: Secure payment via T/T (bank transfer), PayPal, or trade assurance. Pro-forma invoice issued upon order confirmation.
- Step 5 — Shipment & Tracking: Units shipped via DHL Express, FedEx, or UPS with full tracking. Export documentation (commercial invoice, packing list, COO) provided for customs clearance.
Application-Specific FAQ
- Q: Is the 6ES7416-2XP07-0AB0 compatible with TIA Portal?
- A: The CPU 416-2 is natively programmed in SIMATIC STEP 7 V5.x. TIA Portal supports this CPU via the “STEP 7 Professional” package with legacy project import. Direct TIA Portal V13+ programming is not supported without migration.
- Q: What is the difference between the -0AB0 and -0AB0 suffix variants?
- A: The suffix “0AB0” denotes the hardware revision. The “07” in the MLFB (2XP07) indicates firmware version 7. Always match the firmware version to your existing project to avoid compatibility issues during replacement.
- Q: Can this CPU be used as a PROFIBUS DP slave?
- A: Yes. The integrated MPI/DP port can be configured as either a DP Master (Class 1) or DP Slave, providing flexibility in multi-CPU or distributed architectures.
- Q: What memory card is required?
- A: The CPU 416-2 requires a SIMATIC Micro Memory Card (MMC). The program is stored on the MMC and must be present for operation. Recommended: 6ES7952-1KM00-0AA0 (64 MB MMC).
- Q: Is this module available as new or refurbished?
- A: Konmask.com stocks both new (factory-sealed) and professionally refurbished units. Please specify your preference when requesting a quote. All units carry our 12-month warranty regardless of grade.
- Q: What is the typical lead time for delivery to China?
- A: In-stock units are dispatched within 1–2 business days. DHL Express delivery to major Chinese cities typically takes 3–5 business days. Customs clearance documentation is provided as standard.
