Siemens 6GK1500-0AA00 PROFIBUS Connecting Cable | Replacement, Equivalent & Selection Guide
The Siemens 6GK1500-0AA00 is a standard PROFIBUS connecting cable designed for use within the SIMATIC NET communication infrastructure. It enables reliable data transmission between PROFIBUS DP/PA devices, PLCs, and field devices in industrial automation environments. This page provides full technical specifications, compatible replacement models, and a structured selection guide to help engineers and procurement teams make informed decisions.
Technical Specifications
- Part Number: 6GK1500-0AA00
- Manufacturer: Siemens AG
- Product Family: SIMATIC NET PROFIBUS
- Cable Type: PROFIBUS Connecting Cable
- Bus Standard: PROFIBUS DP / RS-485
- Connector Type: Sub-D 9-pin (DB9), male/female
- Shielding: Double-shielded (foil + braid)
- Impedance: 150 Ω (nominal)
- Max. Transmission Rate: Up to 12 Mbit/s
- Operating Temperature: -20 °C to +60 °C
- Weight: Approx. 700 g
- Compliance: CE, UL, IEC 61158
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents for the 6GK1500-0AA00. Always verify electrical and mechanical compatibility before substitution:
- Siemens 6XV1830-0EH10 – Standard PROFIBUS cable (sold by meter), suitable for custom-length assemblies
- Siemens 6GK1500-0FC10 – FastConnect PROFIBUS plug with integrated termination resistor
- Siemens 6ES7972-0BB52-0XA0 – PROFIBUS connector 90° with PG socket, compatible with most S7 CPUs
- Phoenix Contact QUINT PROFIBUS Connector – Third-party equivalent for standard DP networks
- Belden 3079A – Industrial PROFIBUS cable, IEC 61158 compliant, suitable for field wiring replacement
Note: Third-party replacements may require additional configuration. Konmask.com recommends using genuine Siemens components for critical applications.
Why Choose the Original Model
- ✅ Guaranteed Compatibility: Designed and tested specifically for SIMATIC NET PROFIBUS systems
- ✅ Signal Integrity: Precision impedance matching minimizes reflections at high baud rates
- ✅ Robust Construction: Double-shielded design resists EMI in harsh industrial environments
- ✅ Plug-and-Play: No additional configuration required; connects directly to standard DB9 PROFIBUS ports
- ✅ Long Service Life: Industrial-grade materials rated for extended temperature and vibration cycles
- ✅ Siemens Warranty: Backed by Siemens global support and spare parts availability
Typical Applications
- SIMATIC S7-300 / S7-400 / S7-1500 PLC to field device connections
- PROFIBUS DP network segment wiring in manufacturing lines
- Drive communication: SINAMICS, MICROMASTER, SIMOREG inverter integration
- Distributed I/O: ET 200M, ET 200S, ET 200SP remote station connections
- Process automation: DCS field bus wiring in chemical, oil & gas, and water treatment plants
- Panel-to-panel and cabinet-to-field device interconnects
System Compatibility
- PLC Platforms: SIMATIC S7-300, S7-400, S7-1200, S7-1500
- HMI / SCADA: SIMATIC HMI TP/OP series, WinCC
- Drives: SINAMICS G120, S120, V20; MICROMASTER 440
- Remote I/O: ET 200M, ET 200S, ET 200SP, ET 200pro
- Network Topology: Linear bus, tree, and star (with repeaters)
- Bus Speed: 9.6 kbit/s to 12 Mbit/s
Selection Guide
Use the following criteria to confirm the 6GK1500-0AA00 is the right cable for your application, or to identify a suitable alternative:
- Step 1 – Confirm Bus Standard: Verify your network uses PROFIBUS DP (RS-485). For PROFIBUS PA, a different cable type is required.
- Step 2 – Check Connector Type: The 6GK1500-0AA00 uses standard DB9 connectors. Confirm your device ports match.
- Step 3 – Determine Cable Length: This model is a fixed-length assembly. For custom lengths, consider 6XV1830-0EH10 bulk cable.
- Step 4 – Assess Environment: For high-EMI or outdoor environments, verify shielding and temperature ratings meet site requirements.
- Step 5 – Termination Requirement: If the device is at the end of the bus segment, ensure termination resistors are enabled (built-in or via connector).
- Step 6 – Baud Rate: Confirm the cable supports your network’s maximum baud rate (up to 12 Mbit/s).
Quality Assurance & Sourcing
All Siemens products supplied by Konmask.com are sourced through verified industrial distribution channels. Each unit undergoes the following before shipment:
- Visual inspection for connector and cable integrity
- Verification of part number label and packaging authenticity
- Continuity and shielding resistance check
- Secure anti-static packaging for transit protection
We maintain traceability records for all stocked components. Certificates of conformity available upon request.
How to Order
- Part Number: 6GK1500-0AA00
- Minimum Order Quantity: 1 piece
- Lead Time: In-stock items ship within 1–3 business days; ex-stock orders confirmed at checkout
- Payment: T/T, PayPal, credit card, and trade terms available for qualified accounts
- Shipping: DHL, FedEx, UPS worldwide; local courier options for mainland China
- RFQ / Bulk Orders: Contact [email protected] for volume pricing and lead time confirmation
Replacement & Compatibility FAQ
Q: Can I use a third-party PROFIBUS cable instead of the 6GK1500-0AA00?
A: Yes, provided the replacement meets IEC 61158 Type 3 specifications (150 Ω impedance, double-shielded). However, Siemens-certified cables are recommended for warranty-covered installations.
Q: Is the 6GK1500-0AA00 compatible with PROFIBUS PA?
A: No. PROFIBUS PA uses a different physical layer (IEC 61158-2, MBP). A dedicated PA cable and coupler are required.
Q: What is the maximum segment length for this cable?
A: At 12 Mbit/s, the maximum segment length is 100 m. At lower baud rates (e.g., 187.5 kbit/s), segments up to 1,000 m are supported per IEC 61158.
Q: Does this cable include termination resistors?
A: The 6GK1500-0AA00 is a passive connecting cable. Termination must be handled by the connector or device at each bus end.
Q: Can Konmask.com supply other Siemens SIMATIC NET cables?
A: Yes. Contact us with your part number or application requirements for availability and pricing.
