SIEMENS 6GK5734-1FX00-0AA0 – Industrial Ethernet Switch | SCALANCE XR500 Platform
Engineering Background: The SCALANCE XR500 series represents Siemens’ flagship managed industrial Ethernet switching platform, engineered for backbone-level network infrastructure in demanding process and factory automation environments. The XR534-8C variant delivers high-port-density Layer 2/3 switching with redundancy protocols critical for zero-downtime industrial operations.
Product Positioning: The 6GK5734-1FX00-0AA0 is a rack-mount managed Ethernet switch designed for system integrators and plant engineers who require deterministic network performance, ring redundancy, and seamless integration with SIMATIC S7 controllers, PROFINET IO, and TIA Portal engineering environments. Sourced directly from authorized Siemens distribution channels and verified for OEM authenticity at Konmask.com.
Complete Technical Specifications
- Part Number / SKU: 6GK5734-1FX00-0AA0
- Product Family: SCALANCE XR500
- Model: SCALANCE XR534-8C
- Manufacturer: Siemens AG, Germany
- Device Type: Managed Industrial Ethernet Switch (Layer 2/3)
- Form Factor: 19″ Rack-Mount
- Total Ports: 34 (configurable via media modules)
- Fixed Ports: 8 × combo ports (RJ45 / SFP)
- Expansion Slots: Up to 8 × C-PLUG media module slots
- Switching Capacity: Non-blocking wire-speed switching
- Redundancy Protocols: MRP (Media Redundancy Protocol), RSTP, STP, HSR, PRP
- PROFINET Support: PROFINET IO Device, IRT-capable
- Management: Web-based, SNMP v1/v2c/v3, CLI, TIA Portal integration
- Power Supply: Dual redundant 24 VDC (18–32 V)
- Operating Temperature: -40 °C to +70 °C
- Protection Rating: IP20
- Certifications: CE, UL, cUL, ATEX Zone 2, IECEx, DNV GL
- Country of Origin: Germany
- Weight: Approx. 5.4 kg
- Firmware: Compatible with SINEMA Network Manager
Proven Application Environments
- PROFINET backbone networks in automotive assembly lines
- Oil & gas process control ring topologies requiring MRP/HSR redundancy
- Power utility substations with IEC 61850 GOOSE messaging
- Water treatment SCADA networks with high EMI exposure
- Railway trackside and signaling communication infrastructure
- Pharmaceutical manufacturing with FDA 21 CFR Part 11 audit trail requirements
- Mining and heavy industry with extended temperature operation (-40 °C)
Engineering Advantages
- Zero-Downtime Redundancy: MRP ring recovery <20 ms; HSR/PRP for parallel redundancy without reconfiguration delay
- TIA Portal Native Integration: Drag-and-drop device configuration within STEP 7 / TIA Portal V15+; no separate engineering tool required
- Modular Port Expansion: C-PLUG media modules support copper, multimode, and singlemode fiber — future-proof for topology changes
- Cybersecurity Hardening: IEEE 802.1X port authentication, RADIUS, TACACS+, HTTPS/SSH management, MAC/IP ACLs
- Diagnostics & Alarming: RMON, SYSLOG, SNMP traps, signal contact relay output for fault annunciation to PLC
- Dual PSU Redundancy: Hot-swap power supply modules eliminate single point of failure in critical infrastructure
System Architecture & Signal Flow
In a typical SIMATIC S7-1500 / ET 200MP PROFINET architecture, the 6GK5734-1FX00-0AA0 operates as the network backbone switch. PROFINET IO controllers connect via the fixed RJ45/SFP combo ports; field-level IO devices (ET 200SP, ET 200MP, drives, HMIs) connect through downstream unmanaged or managed switches. The XR534-8C enforces VLAN segmentation between PROFINET, OPC UA, and office IT traffic, while MRP ring topology ensures sub-20 ms failover if any fiber segment is severed. SINEMA Network Manager provides centralized topology visualization and firmware lifecycle management across all SCALANCE nodes.
Sourcing & Quality Verification
- All units sourced from authorized Siemens distribution or verified surplus channels
- Each module inspected for firmware version, label authenticity, and physical condition prior to listing
- Original Siemens packaging and documentation preserved where available
- Batch traceability records maintained for enterprise and OEM procurement compliance
- Certificate of Conformance (CoC) available upon request for regulated industries
Procurement Process
- Step 1: Submit RFQ via Konmask.com product page or email [email protected] with quantity and delivery requirements
- Step 2: Receive formal quotation with lead time, unit price, and shipping options within 24 business hours
- Step 3: Confirm PO; payment via T/T, PayPal, or trade credit (approved accounts)
- Step 4: Dispatch with tracking; DHL Express / FedEx International Priority standard for urgent orders
- Step 5: Post-delivery technical support available via email and WhatsApp
Technical FAQ
Q: Is 6GK5734-1FX00-0AA0 compatible with STEP 7 Classic (V5.x)?
A: Basic SNMP management is supported; however, full TIA Portal integration (PROFINET device configuration, topology detection) requires TIA Portal V13 SP1 or later. STEP 7 Classic users should manage via web interface or SINEMA.
Q: Can this switch operate in a PROFINET IRT (Isochronous Real-Time) network?
A: Yes. The XR534-8C supports PROFINET IRT when connected to IRT-capable IO controllers (e.g., S7-1500, S7-300 with PN interface). IRT domains must be configured in TIA Portal hardware configuration.
Q: What fiber media modules are compatible?
A: Siemens C-PLUG SFP modules for 100 Mbps / 1 Gbps multimode (LC, SC) and singlemode fiber. Third-party SFPs may function but are not officially supported by Siemens.
Q: Is this product available with Siemens warranty?
A: New-in-box units carry standard Siemens warranty. Refurbished/surplus units are covered by Konmask’s 90-day functional warranty. Contact us for warranty documentation.
Q: What is the typical lead time?
A: In-stock units ship within 1–3 business days. Out-of-stock items: 2–6 weeks depending on Siemens production schedule. Expedited sourcing available for critical plant shutdowns.
