PROSOFT MVI69E-MBS Modbus Serial Communication Module – MVI69E Series
Imagine a critical production line where your CompactLogix PLC cannot communicate with legacy Modbus RTU/ASCII field devices — drives, meters, sensors, and third-party controllers all go silent. Without a reliable protocol bridge, engineers face costly custom wiring workarounds, integration delays, and unplanned downtime that ripples across the entire facility. The PROSOFT MVI69E-MBS eliminates this gap entirely, serving as the definitive Modbus Serial master/slave communication module engineered specifically for the Allen-Bradley CompactLogix and MicroLogix 1500 platform.
Within the MVI69E product family — ProSoft Technology’s enhanced-generation in-chassis communication modules — the MVI69E-MBS occupies a flagship position for Modbus Serial connectivity. Modbus remains the world’s most widely deployed industrial protocol, and ProSoft’s implementation is trusted by automation engineers across oil & gas, water treatment, power generation, and discrete manufacturing on every continent. The MVI69E-MBS is not simply a protocol converter; it is a production-grade integration component with a proven track record in mission-critical environments.
Technical Specifications
- Part Number: MVI69E-MBS
- Manufacturer: ProSoft Technology
- Series: MVI69E (Enhanced In-Chassis)
- Compatible Platform: Allen-Bradley CompactLogix, MicroLogix 1500
- Protocol Supported: Modbus RTU / Modbus ASCII (Master & Slave)
- Serial Ports: 2 × RS-232/RS-422/RS-485 (software-selectable)
- Backplane Interface: CompactLogix local I/O backplane
- Configuration Tool: ProSoft Configuration Builder (PCB)
- Firmware Upgradeable: Yes, via USB
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Relative Humidity: 5% to 95% non-condensing
- Power Consumption: Supplied via CompactLogix backplane
- Certifications: CE, UL (refer to ProSoft datasheet for current listing)
- Form Factor: Single-slot CompactLogix module
Note: Always verify specifications against the official ProSoft Technology datasheet for your specific firmware revision.
Key Features & Benefits
- Dual-Port Modbus Master/Slave: Two independently configurable serial ports allow simultaneous master and slave operation, maximizing network flexibility without additional hardware.
- Multi-Mode Serial Interface: RS-232, RS-422, and RS-485 modes are software-selectable per port, eliminating the need for external converters in mixed-wiring environments.
- Enhanced Diagnostics: Real-time port statistics, error counters, and message logs accessible directly through the backplane — dramatically reducing commissioning and troubleshooting time.
- ProSoft Configuration Builder (PCB): Intuitive Windows-based configuration software with built-in Modbus simulator for offline testing before live deployment.
- Seamless Backplane Integration: Data is mapped directly into the CompactLogix controller tags, enabling native Ladder Logic and Structured Text access with no custom driver development.
- Firmware Field-Upgradeable: USB port allows on-site firmware updates, protecting your investment as protocol requirements evolve.
- High Message Throughput: Supports up to 100 Modbus commands per port per scan, suitable for high-density polling applications.
Industry & Equipment Applications
- Oil & Gas: RTU polling, wellhead controllers, SCADA integration with Modbus field instruments
- Water & Wastewater: Pump station automation, flow meter integration, chemical dosing control
- Power Generation & Utilities: Generator controllers, UPS systems, power quality meters
- Building Automation: HVAC controllers, energy meters, BMS gateway applications
- Discrete Manufacturing: Variable frequency drives (VFDs), servo drives, barcode readers, weighing systems
- Food & Beverage: Temperature controllers, batch process instruments, CIP system integration
System Integration & Compatible Parts
The MVI69E-MBS is designed for seamless integration within the Allen-Bradley CompactLogix ecosystem. Commonly paired components include:
- CompactLogix controllers: 1769-L16ER, 1769-L18ER, 1769-L24ER, 1769-L27ERM, 1769-L30ER, 1769-L33ER, 1769-L36ERM
- MicroLogix 1500 base units (1764-LSP, 1764-LRP)
- ProSoft MVI69E-MNET (Modbus TCP companion module for hybrid networks)
- ProSoft MVI69E-DFNT (EtherNet/IP to serial gateway)
- Standard 1769 CompactLogix expansion cables and power supplies
Contact our technical team at support@konmask.com for compatibility verification with your specific system configuration.
Our Quality Assurance Process
Every PROSOFT MVI69E-MBS unit sourced and supplied by Konmask.com undergoes a rigorous multi-stage quality process:
- Authenticity Verification: Cross-referenced against manufacturer serial number databases and holographic label inspection to confirm genuine ProSoft origin.
- Visual & Physical Inspection: Examination of PCB, connectors, housing, and firmware label for signs of refurbishment, counterfeiting, or damage.
- Functional Bench Test: Where applicable, modules are powered and communication ports are verified prior to shipment.
- ESD-Safe Packaging: All units are packed in anti-static bags with foam cushioning and clearly labeled with part number and serial number.
- Traceability Documentation: Full supply chain traceability records available upon request for regulated industries.
How to Order
- Submit your inquiry via the “Get a Quote” button or email support@konmask.com with your required quantity and delivery timeline.
- Our technical sales team will confirm availability, lead time, and provide a formal quotation within 1 business day.
- Upon PO confirmation, we arrange quality inspection, ESD-safe packaging, and international shipping with full documentation (commercial invoice, packing list, COO).
- Track your shipment with the provided AWB number; our team remains available for post-delivery technical support.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC, DCS, and automation hardware — not a generalist marketplace.
- Verified Supply Chain: Every unit is traceable to authorized distribution channels with anti-counterfeit verification.
- Global Shipping Expertise: Experienced in export documentation, customs compliance, and time-sensitive industrial procurement.
- Technical Pre-Sales Support: Our engineers can advise on compatibility, configuration, and system integration before you commit to a purchase.
- Responsive B2B Service: Dedicated account management for OEMs, system integrators, and MRO procurement teams.
Frequently Asked Questions
Q: Is the MVI69E-MBS compatible with CompactLogix 5370 controllers?
A: Yes. The MVI69E-MBS is designed for the 1769 CompactLogix backplane and is compatible with the CompactLogix 5370 (L1, L2, L3) family. Always verify slot availability and power budget with your specific chassis configuration.
Q: Can the MVI69E-MBS operate as both Modbus Master and Slave simultaneously?
A: Yes. Each of the two serial ports can be independently configured as either Master or Slave, allowing the module to bridge two separate Modbus networks simultaneously.
Q: What is the difference between MVI69-MBS and MVI69E-MBS?
A: The MVI69E series is the enhanced generation featuring improved diagnostics, USB configuration port, and updated firmware architecture. The MVI69E-MBS is the recommended replacement for the legacy MVI69-MBS.
Q: Do you supply new or refurbished units?
A: Konmask.com supplies new and surplus-new units. All units undergo our quality assurance process. Condition is clearly stated in the quotation.
Q: How long does international shipping take?
A: Typical international delivery is 5–10 business days via DHL/FedEx Express. Expedited options are available upon request.
Q: Can you provide a Certificate of Origin or other export documents?
A: Yes. We provide full export documentation including commercial invoice, packing list, and Certificate of Origin as standard for all international orders.
