SIEMENS 6SE7024-7ED84-1HF4 – CBP2 PROFIBUS Communication Board | SIEMENS MASTERDRIVES Platform
Engineering Background: In modern industrial drive systems, seamless fieldbus communication is not optional — it is the backbone of coordinated motion control, real-time diagnostics, and centralized SCADA integration. When a PROFIBUS communication interface fails or is absent, the entire drive network loses its ability to receive setpoints, report fault states, or participate in synchronized multi-axis operations. Production lines halt, troubleshooting becomes manual and time-consuming, and the cost of unplanned downtime escalates rapidly. The SIEMENS 6SE7024-7ED84-1HF4 CBP2 Communication Board eliminates this vulnerability by providing a robust, certified PROFIBUS DP interface directly integrated into the MASTERDRIVES drive unit.
Product Positioning: The 6SE7024-7ED84-1HF4 is the CBP2 (Communication Board PROFIBUS) option board designed specifically for the SIEMENS MASTERDRIVES MC (Motion Control) and VC (Vector Control) series. It occupies the dedicated option slot of the MASTERDRIVES compact and chassis units, enabling full PROFIBUS DP slave functionality compliant with IEC 61158. Within the MASTERDRIVES ecosystem, this board is the standard solution for integrating variable-speed drives into SIMATIC S7 PLC networks, DCS platforms, and third-party PROFIBUS masters — making it one of the most widely deployed drive communication interfaces in global industrial automation.
Complete Technical Specifications
- Part Number / SKU: 6SE7024-7ED84-1HF4
- Series / Platform: SIEMENS MASTERDRIVES (6SE70 Series)
- Module Type: CBP2 — Communication Board PROFIBUS
- Fieldbus Protocol: PROFIBUS DP (IEC 61158 / EN 50170)
- PROFIBUS Role: DP Slave
- Baud Rate Support: 9.6 kbps to 12 Mbps (auto-detection)
- GSD File: Siemens-standard GSD for MASTERDRIVES CBP2
- Profile Support: PROFIdrive (Drive Profile)
- Connector: 9-pin Sub-D (DB9) female, standard PROFIBUS pinout
- Installation: Plug-in option board into MASTERDRIVES option slot (no tools required)
- Power Supply: Powered internally via drive option slot (no external supply needed)
- Weight: Approx. 200 g
- Manufacturer: SIEMENS AG, Germany
- Compliance: CE, UL, cUL
Note: All specifications are based on published SIEMENS documentation. Konmask.com does not modify or fabricate technical parameters.
Proven Application Environments
- Automotive Manufacturing: Body-in-white welding lines, paint shop conveyor drives, and press transfer systems integrated via PROFIBUS DP to SIMATIC S7-300/400 PLCs
- Steel & Metals Processing: Rolling mill main drives and coiler/decoiler systems requiring high-speed, deterministic fieldbus communication
- Paper & Printing: Multi-section web tension control systems where coordinated speed references are distributed via PROFIBUS master
- Water & Wastewater: Pump station variable-speed drives networked to SCADA systems through PROFIBUS DP gateways
- Mining & Bulk Material Handling: Belt conveyor drives and crusher systems with centralized monitoring via PROFIBUS network
- Chemical & Petrochemical: Agitator and compressor drives in process plants with DCS integration via PROFIBUS DP
- OEM Machine Builders: Any machine using SIEMENS MASTERDRIVES that requires fieldbus connectivity for remote parameterization and control
Engineering Advantages
- Plug-and-Play Integration: Designed as a native option board for MASTERDRIVES — no external gateway, no additional wiring complexity
- Auto Baud Rate Detection: Automatically synchronizes to the PROFIBUS master baud rate from 9.6 kbps to 12 Mbps, simplifying commissioning
- PROFIdrive Profile Compliance: Supports standardized drive control words, status words, and process data objects (PDOs) for interoperability with any PROFIdrive-compatible master
- Cyclic & Acyclic Data Exchange: Supports both cyclic process data (speed setpoint, actual value, control/status word) and acyclic parameter access (DPV1) for remote drive parameterization via STARTER or SIMATIC PDM
- Diagnostic Transparency: Drive fault codes, warning states, and operational data are accessible in real time from the PROFIBUS master, enabling predictive maintenance strategies
- Proven Field Reliability: CBP2 boards have accumulated decades of operational hours across global industrial installations, with a well-documented maintenance and replacement ecosystem
System Architecture & Signal Flow
The 6SE7024-7ED84-1HF4 CBP2 board is installed into the option slot located on the front of the MASTERDRIVES compact unit or the control section of chassis units. Once installed, the drive appears as a PROFIBUS DP slave on the network segment.
Typical signal flow:
- SIMATIC S7 PLC (PROFIBUS DP Master) → PROFIBUS cable (DB9) → CBP2 board (6SE7024-7ED84-1HF4) → MASTERDRIVES internal bus → Drive control unit → Power section → Motor
The PLC sends cyclic process data (e.g., speed setpoint, control word) to the CBP2, which translates these into internal drive commands. The drive responds with actual speed, current, status word, and fault information in the same cyclic telegram. Acyclic DPV1 services allow the PLC or engineering tool to read/write drive parameters (P-parameters) without interrupting cyclic operation.
Compatible MASTERDRIVES units include: 6SE70xx compact and chassis units (VC and MC variants). Always verify the specific drive unit’s option slot compatibility using the MASTERDRIVES catalog or hardware manual before ordering.
Sourcing & Quality Verification
At Konmask.com, every SIEMENS 6SE7024-7ED84-1HF4 unit offered undergoes a structured verification process before dispatch:
- Origin Traceability: Units are sourced from authorized distribution channels or verified industrial decommissioning projects with documented provenance
- Visual & Physical Inspection: PCB condition, connector integrity, label authenticity, and firmware version markings are checked against SIEMENS reference standards
- Functional Pre-check: Where test equipment is available, boards are bench-tested for basic communication handshake capability
- Packaging: Anti-static packaging with desiccant, clearly labeled with part number and inspection status
- Documentation: Datasheet and installation guide references provided upon request
Procurement Process
- Submit Inquiry: Contact us via the product page inquiry form or email support@konmask.com with your required quantity and delivery timeline
- Quotation: Our technical team will respond within 1 business day with pricing, lead time, and stock confirmation
- Order Confirmation: Upon agreement, a proforma invoice is issued for payment processing
- Quality Check & Dispatch: Units pass final inspection before shipment via DHL, FedEx, or UPS with full tracking
- After-Sales Support: Technical assistance available for installation and commissioning questions
📧 support@konmask.com | 📞 +0086 19859288691
Technical FAQ
- Q: Is the 6SE7024-7ED84-1HF4 compatible with all MASTERDRIVES units?
- A: The CBP2 board is designed for SIEMENS MASTERDRIVES 6SE70 series compact and chassis units with an available option slot. Compatibility depends on the specific drive firmware version and hardware revision. Always cross-reference with the MASTERDRIVES hardware installation manual (e.g., A5E00125122) before installation.
- Q: Can this board be used with SIMATIC S7-1500 or TIA Portal?
- A: Yes. The CBP2 board functions as a standard PROFIBUS DP slave and is compatible with any PROFIBUS DP master, including S7-1500 with CM 1542-5 communication module. In TIA Portal, configure the drive using the GSD file provided by SIEMENS for MASTERDRIVES CBP2.
- Q: What is the difference between CBP and CBP2?
- A: The CBP2 (6SE7024-7ED84-1HF4) is the second-generation PROFIBUS communication board for MASTERDRIVES, offering improved baud rate support, enhanced DPV1 acyclic services, and better diagnostic capabilities compared to the original CBP. CBP2 is the recommended replacement for CBP in all new and retrofit applications.
- Q: Do you provide the GSD file for this module?
- A: The GSD file for MASTERDRIVES CBP2 is available from the official SIEMENS Industry Online Support portal. Konmask.com can provide guidance on locating the correct GSD file upon request.
- Q: What is the warranty on this product?
- A: Konmask.com provides a quality assurance guarantee covering the unit as described. Please contact support@konmask.com for specific warranty terms applicable to your order.
