Siemens 6SE7027-2ED84-1HF5 – Vector Control Unit | MASTERDRIVES MC Platform
Engineering Background
The Siemens MASTERDRIVES MC (Motion Control) series represents Siemens’ flagship modular drive platform for high-performance industrial automation. Designed for demanding applications requiring precise speed and torque regulation, the MASTERDRIVES MC line integrates seamlessly into SIMATIC and PROFIBUS-based control architectures. The 6SE7027-2ED84-1HF5 is a vector-control unit (CU) module engineered for three-phase AC induction and synchronous motor drives in the 37 kW power class.
Product Positioning
This control unit is the intelligence core of the MASTERDRIVES MC compact-plus/vector drive system. It provides closed-loop vector control, encoder feedback processing, and fieldbus communication in a single plug-in module — enabling OEMs and system integrators to achieve servo-class dynamic response on standard AC drives without the cost of a full servo system.
Complete Technical Specifications
| Part Number (SKU) | 6SE7027-2ED84-1HF5 |
| Series / Platform | Siemens MASTERDRIVES MC (Motion Control) |
| Module Type | Control Unit (CU) – Vector / Motion Control |
| Power Class | 37 kW (approx. 50 HP) @ 380–480 V AC |
| Control Mode | Sensorless Vector Control (SLVC) / Closed-Loop Vector (with encoder) |
| Encoder Interface | HTL / TTL incremental encoder input (onboard) |
| Fieldbus | PROFIBUS-DP (integrated, via CBP2 option board slot) |
| Digital Inputs | 6 × DI (24 V DC, programmable) |
| Digital Outputs | 3 × DO (relay, programmable) |
| Analog Inputs | 2 × AI (±10 V / 0–20 mA, 12-bit) |
| Analog Outputs | 2 × AO (0–20 mA, 12-bit) |
| Serial Interface | RS-232 (front panel, for OP1S / PC parameterization) |
| Option Board Slots | 2 × expansion slots (CBP2, CBC, T400, etc.) |
| Firmware | Compatible with DriveMonitor / STARTER commissioning tools |
| Protection Class | IP20 (module installed in drive chassis) |
| Operating Temperature | 0 °C to +40 °C (derating above 40 °C) |
| Storage Temperature | -25 °C to +70 °C |
| Humidity | ≤ 95% RH, non-condensing |
| Weight | Approx. 5 kg (complete drive assembly) |
| Compliance | CE, UL, cUL, EN 61800-3 |
| Country of Origin | Germany |
Proven Application Environments
- Winding & Unwinding Lines – Tension control with encoder feedback for paper, film, and textile mills
- Crane & Hoist Systems – Precise torque control for safe load handling in steel plants and ports
- Extruder Drives – Stable speed regulation under variable load in plastics processing
- Centrifuge & Compressor Drives – High dynamic response for process industry applications
- Machine Tool Spindle Drives – Closed-loop vector control for CNC machining centers
- Conveyor & Positioning Systems – Multi-axis coordination via PROFIBUS in automotive assembly lines
Engineering Advantages
- Modular Architecture – Control unit separates from power section; replace CU without disturbing power wiring
- Dual Encoder Support – HTL and TTL inputs allow flexible motor feedback selection
- Integrated Motion Control – Positioning, synchronization, and cam functions available via T400 technology board
- PROFIBUS-DP Ready – Native integration with SIMATIC S7 PLCs and distributed I/O via CBP2 board
- DriveMonitor / STARTER Compatible – Full parameter access, trace, and diagnostics via PC
- Proven Field Reliability – MTBF-rated design with extensive installed base across global industries since 1990s
System Architecture & Signal Flow
The 6SE7027-2ED84-1HF5 CU plugs directly into the MASTERDRIVES MC compact-plus chassis. The signal flow is as follows:
- Setpoint Input → Analog AI or PROFIBUS DP telegram (STW/HSW)
- Speed/Torque Controller → Internal DSP executes vector algorithm at 1.6 ms cycle time
- Encoder Feedback → HTL/TTL encoder signals processed for closed-loop correction
- PWM Output → Gate drive signals sent to IGBT power section (IPM module)
- Status & Diagnostics → DO relay outputs + PROFIBUS ZSW/HIW feedback to PLC
Option boards (CBP2 for PROFIBUS, T400 for technology functions) insert into the two expansion slots on the CU front face, enabling system-level customization without external hardware.
Sourcing & Quality Verification
- Origin Traceability – Units sourced from authorized Siemens distribution channels and verified OEM surplus stock
- Incoming Inspection – Each unit undergoes visual inspection, label verification (part number, date code, firmware version), and functional power-on test
- Authenticity Check – Holographic Siemens labels, PCB markings, and serial number cross-referenced against Siemens product database
- Packaging – Anti-static bag + foam-lined carton; humidity indicator card included for long-distance shipments
- Warranty – 12-month warranty against manufacturing defects; DOA replacement within 7 business days
Procurement Process
- Inquiry – Submit RFQ via Konmask.com product page or email support@konmask.com with quantity and delivery requirements
- Quotation – Receive formal quotation with lead time, unit price, and shipping options within 24 hours
- Order Confirmation – Purchase order accepted; proforma invoice issued for payment
- Quality Hold – Unit reserved and re-inspected prior to shipment
- Shipping – DHL / FedEx express or sea freight; export documentation (commercial invoice, packing list, CO) provided
- After-Sales – Technical support available via email and phone; remote commissioning assistance available
Technical FAQ
Q: Is the 6SE7027-2ED84-1HF5 compatible with the 6SE7024-7ED84-1HF5 power section?
A: Yes. Both units share the MASTERDRIVES MC compact-plus chassis form factor. The CU is interchangeable across the 6SE702x series power sections within the same voltage class.
Q: Can this CU operate in sensorless vector mode without an encoder?
A: Yes. The 6SE7027-2ED84-1HF5 supports SLVC (Sensorless Vector Control) for applications where encoder installation is not practical. Closed-loop mode requires an HTL or TTL incremental encoder.
Q: What PROFIBUS baud rates are supported?
A: With the CBP2 option board installed, PROFIBUS-DP supports 9.6 kbps to 12 Mbps auto-baud detection.
Q: Is DriveMonitor or STARTER required for commissioning?
A: Basic commissioning can be performed via the OP1S operator panel (connected to the RS-232 port). Full parameter access and trace functions require DriveMonitor (legacy) or STARTER software on a Windows PC.
Q: What is the lead time for this part?
A: In-stock units ship within 2–3 business days. For out-of-stock inquiries, typical lead time is 2–4 weeks depending on sourcing. Contact us for real-time availability.
