Industrial Motor Drive Solution – SIEMENS 6SE7035-1EJ84-1JC2 | SIMOVERT MASTERDRIVES
Where This Product Is Used
The SIEMENS 6SE7035-1EJ84-1JC2 is a high-power inverter module from the SIMOVERT MASTERDRIVES Vector Control series, engineered for demanding industrial motor drive applications. Engineers and system integrators specify this unit across a wide range of sectors:
- Steel & Metal Processing: Rolling mills, coilers, and winding machines requiring precise torque and speed control under heavy load.
- Mining & Quarrying: Conveyor drives, crushers, and hoisting equipment where reliable high-power output is critical.
- Paper & Pulp Industry: Section drives and winder/unwinder systems demanding synchronized multi-axis control.
- Marine & Offshore: Thruster drives, winch systems, and pump drives in harsh environments.
- Water & Wastewater: Large pump and blower drives in municipal and industrial treatment plants.
- Chemical & Petrochemical: Compressor and agitator drives requiring explosion-safe, stable operation.
- Power Generation: Auxiliary drives for turbines, fans, and cooling systems.
Technical Specifications
- Part Number / SKU: 6SE7035-1EJ84-1JC2
- Series: SIMOVERT MASTERDRIVES Vector Control (VC)
- Manufacturer: SIEMENS AG
- Type: Inverter Module (Compact Plus / Cabinet Unit)
- Output Power: ~160 kW (refer to nameplate for exact rating)
- Output Current: ~315 A (nominal, refer to datasheet)
- Input Voltage: 3-phase AC, 380–480 V ±10%
- Control Mode: Vector Control (sensorless & encoder-based)
- Communication: PROFIBUS DP via CBP2 option board (1JC2 suffix)
- Cooling: Forced air cooling (internal fan)
- Protection Class: IP20 (cabinet installation)
- Weight: Approx. 880 g (module only; refer to full unit datasheet)
- Standards: CE, UL, cUL, EN 61800-3
Why Engineers Specify This Model
- High Dynamic Performance: Vector control with encoder feedback delivers fast torque response, essential for tension-controlled winding and positioning applications.
- PROFIBUS DP Integration (1JC2): The -1JC2 option suffix confirms integrated PROFIBUS DP communication, enabling seamless integration into SIMATIC S7 and other PLC-based automation architectures.
- Modular Architecture: The MASTERDRIVES platform supports common DC bus configurations, allowing energy sharing between drives and reducing overall system energy consumption.
- Proven Reliability: Widely deployed in mission-critical industrial environments globally since the 1990s, with extensive spare parts and service ecosystem.
- Scalable System Design: Compatible with SIEMENS rectifier/regenerative units, braking modules, and line filters for complete drive train solutions.
