Siemens 6SE7038-6EK84-1GG0 – High-Power Output Module | MASTERDRIVES MC/VC Platform
Engineering Background
The Siemens 6SE7038-6EK84-1GG0 is a high-power output (inverter) module designed for the SIMOVERT MASTERDRIVES MC/VC series — Siemens’ flagship modular AC drive platform for demanding industrial motion control and process automation applications. This unit forms the core power conversion stage of a cabinet-mounted drive system, converting DC bus voltage into precisely controlled three-phase AC output to drive induction and synchronous motors.
Product Positioning
Engineered for heavy-duty continuous operation in steel mills, paper machines, mining conveyors, marine propulsion, and large HVAC systems, the 6SE7038-6EK84-1GG0 delivers reliable high-current output with full compatibility with Siemens MASTERDRIVES control boards (CU, CB, TB). It is the preferred choice for procurement engineers requiring a drop-in replacement or system expansion module with guaranteed OEM interoperability.
Complete Technical Specifications
| Parameter | Value |
|---|---|
| Part Number / SKU | 6SE7038-6EK84-1GG0 |
| Manufacturer | Siemens AG |
| Product Family | SIMOVERT MASTERDRIVES MC/VC |
| Module Type | Output Module (Inverter Power Section) |
| Rated Output Current | ~386 A (refer to Siemens catalog for exact frame rating) |
| DC Bus Voltage | 510–720 V DC (nominal) |
| Output Voltage | 3-phase AC, 0–480 V (adjustable) |
| Output Frequency | 0–300 Hz |
| Switching Technology | IGBT-based PWM |
| Cooling Method | Forced air (integrated fan) |
| Protection Class | IP20 |
| Ambient Temperature | 0°C to +40°C (operating) |
| Storage Temperature | -25°C to +70°C |
| Relative Humidity | ≤95%, non-condensing |
| Weight | ~1.5 kg |
| Compliance | CE, UL, cUL |
| Compatible Control Units | 6SE70xx CU/CB/TB boards (MASTERDRIVES MC/VC) |
Proven Application Environments
- Steel & Metal Processing: Rolling mill main drives, coiler/uncoiler tension control
- Mining & Minerals: Belt conveyor drives, hoist and winder systems
- Pulp & Paper: Section drives for paper machines requiring precise speed synchronization
- Marine & Offshore: Thruster and propulsion drive systems
- Large HVAC: Central chiller plant pump and fan drives (>200 kW)
- Water & Wastewater: High-power pump station variable speed control
- Test Benches: Motor test rigs requiring regenerative four-quadrant operation
Engineering Advantages
- Modular Architecture: Hot-swap compatible within MASTERDRIVES cabinet systems — minimizes downtime during maintenance
- IGBT Power Stage: Low switching losses, high efficiency (>97%), reduced thermal stress on cabinet components
- Full OEM Compatibility: Direct plug-in replacement for existing 6SE703x/6SE704x series installations without firmware changes
- Integrated Gate Driver & Protection: Overcurrent, overvoltage, short-circuit, and ground fault protection built into the module
- Scalable Power: Parallel operation supported for higher current applications via Siemens parallel interface
- Long Service Life: Industrial-grade IGBT modules rated for >100,000 hours MTBF under rated conditions
System Architecture & Signal Flow
In a MASTERDRIVES MC/VC system, the 6SE7038-6EK84-1GG0 sits between the rectifier/DC bus section and the motor terminals:
- DC Bus Input → Receives stabilized DC voltage from the rectifier module (6SE703x-xExx-xAx0)
- IGBT Inverter Stage → PWM switching converts DC to variable-frequency, variable-voltage 3-phase AC
- Gate Drive Interface → Receives firing pulses from the Control Unit (CU) via the internal fiber-optic or direct interface
- Motor Output Terminals → U2/V2/W2 terminals connect directly to motor cable (screened cable recommended)
- Feedback & Protection → Current sensors feed back to CU for closed-loop vector control (VC mode) or V/f control (MC mode)
Sourcing & Quality Verification
- All units sourced from authorized Siemens distribution channels or verified surplus with full traceability documentation
- Pre-shipment inspection includes: visual inspection, label authenticity check, IGBT gate drive functional test, and insulation resistance test
- Serialized units traceable via Siemens Industry Online Support (SIOS) portal using the module’s nameplate serial number
- Packaging: original Siemens anti-static foam packaging or equivalent ESD-safe export carton
- Certificate of Conformity (CoC) available upon request
Procurement Process
- Confirm Part Number: Verify 6SE7038-6EK84-1GG0 against your existing drive system nameplate or Siemens order documentation
- Request Quote: Contact support@konmask.com with quantity and required delivery timeline
- Lead Time: In-stock units ship within 1–3 business days; ex-stock orders confirmed within 24 hours
- Payment: T/T, L/C, PayPal, and major credit cards accepted
- Shipping: DHL Express, FedEx International Priority, or sea freight for bulk orders; export documentation included
- After-Sales: 12-month warranty; technical support available via email and WhatsApp
Technical FAQ
Q: Is the 6SE7038-6EK84-1GG0 compatible with both MC and VC control units?
A: Yes. The output module is hardware-compatible with both Motion Control (MC) and Vector Control (VC) variants of the MASTERDRIVES platform. The control mode is determined by the CU board, not the output module.
Q: Can this module be used as a standalone inverter?
A: No. It requires a separate rectifier/DC bus supply and a MASTERDRIVES control unit (CU) to operate. It is a power section module only.
Q: What is the motor power rating this module supports?
A: Based on the 6SE7038-6EK84 frame designation, this module is rated for approximately 200–250 kW motor drives at 400 V AC supply. Confirm exact kW rating with your Siemens drive configurator or contact us.
Q: Are spare IGBT modules available separately?
A: We can source compatible IGBT sub-modules. Please contact us with your specific requirement.
Q: Do you provide installation and commissioning support?
A: Remote technical guidance is available. On-site commissioning can be arranged through our partner network in major industrial regions.
