SIEMENS 6SL3000-0BE23-6DA1 – Line Reactor for Harmonic Mitigation | SINAMICS S120 Platform
Engineering Background: The 6SL3000-0BE23-6DA1 is a Siemens SINAMICS S120 series line reactor (commutating choke) engineered to reduce harmonic distortion on the AC supply side of variable-speed drive systems. It is a passive inductive component inserted between the mains supply and the Active Line Module (ALM) or Basic Line Module (BLM) of the SINAMICS S120 booksize/chassis drive family. By limiting the rate of current rise (di/dt) during rectifier commutation, it protects upstream equipment, reduces THDi, and extends drive service life.
Product Positioning: Designed for procurement engineers specifying harmonic-compliance solutions in industrial automation, machine tool, and process-control applications. The 6SL3000-0BE23-6DA1 is the OEM-recommended line reactor for SINAMICS S120 drive configurations operating at 380–480 V AC, 36 A rated current. It is a direct Siemens factory part, fully compatible with TIA Portal commissioning workflows and CE/UL-certified installations.
Complete Technical Specifications
- Part Number (MLFB): 6SL3000-0BE23-6DA1
- Product Family: SINAMICS S120 – Line-Side Components
- Component Type: Line Reactor (Commutating Choke / AC Line Filter)
- Rated Current: 36 A
- Supply Voltage: 380 – 480 V AC, 3-phase
- Frequency: 47 – 63 Hz
- Inductance: Optimized for SINAMICS S120 ALM/BLM input stage
- Degree of Protection: IP00 (panel/cabinet mounting)
- Cooling Method: Natural convection (self-cooled)
- Mounting: DIN rail / chassis panel
- Weight: approx. 6.98 kg
- Country of Origin: Germany
- Certifications: CE, UL, cUL
- Compatible Drive Modules: SINAMICS S120 Active Line Module, Basic Line Module (booksize & chassis)
- Siemens Product Group: 6SL30xx – Drive System Accessories
Proven Application Environments
- CNC machine tool spindle and feed-axis drive systems
- Industrial conveyor and hoist variable-speed drive installations
- Pump and fan VFD applications requiring IEEE 519 / EN 61000-3-12 harmonic compliance
- Packaging machinery with multi-axis SINAMICS S120 servo drive topologies
- Process automation panels where upstream transformer protection is required
- Retrofit projects replacing legacy Masterdrives or SIMOVERT VC systems
Engineering Advantages
- Harmonic Reduction: Reduces supply-side THDi, supporting IEEE 519 and EN 61000-3-12 compliance without active filtering hardware
- Drive Protection: Limits peak inrush and commutation notch depth, extending IGBT and DC-link capacitor service life
- OEM Integration: Factory-matched inductance value for SINAMICS S120 36 A input stage — no derating calculation required
- Compact Footprint: Booksize-compatible form factor minimizes cabinet space consumption
- Plug-and-Play Commissioning: Recognized natively in STARTER / TIA Portal Drive Wizard; no additional parameterization needed
- Thermal Reliability: Self-cooled design eliminates fan dependency and associated maintenance intervals
System Architecture & Signal Flow
In a standard SINAMICS S120 drive line-up, the 6SL3000-0BE23-6DA1 is installed on the AC supply side, upstream of the Line Module. The signal/power flow is:
Mains Supply (3-phase, 380–480 V AC) → Main Contactor / Circuit Breaker → 6SL3000-0BE23-6DA1 Line Reactor → SINAMICS S120 Active/Basic Line Module → DC Bus → Motor Modules → Servo / Induction Motors
The reactor’s inductance creates a controlled impedance that smooths the rectifier current waveform, reducing harmonic injection back into the supply network and protecting both the drive and upstream distribution equipment.
Sourcing & Quality Verification
- Origin: Genuine Siemens factory production, Germany
- Traceability: Each unit carries Siemens MLFB label with date code and serial number for warranty and service tracking
- Inspection: Pre-shipment functional and dimensional inspection performed by Konmask technical team
- Packaging: Original Siemens OEM packaging with anti-static protection and moisture barrier
- Warranty: 12-month Konmask quality guarantee; Siemens factory warranty terms apply to new-in-box units
- Counterfeit Risk: Konmask sources exclusively from authorized Siemens distribution channels and verified industrial surplus — no gray-market or refurbished units without explicit disclosure
Procurement Process
- Step 1 – RFQ: Contact support@konmask.com or call +0086 19859288691 with your project BOM and required delivery date
- Step 2 – Quotation: Receive itemized quotation with lead time, unit price, and shipping options within 24 business hours
- Step 3 – Order Confirmation: Purchase order accepted via email; proforma invoice issued for T/T, L/C, or online payment
- Step 4 – Inspection & Dispatch: Pre-shipment inspection report provided; DHL / FedEx / sea freight options available with full tracking
- Step 5 – After-Sales: Technical support available for installation, commissioning queries, and warranty claims
Technical FAQ
Q: Is the 6SL3000-0BE23-6DA1 mandatory for SINAMICS S120 operation?
A: Not mandatory for basic operation, but strongly recommended by Siemens for all installations where supply impedance is low (<1%) or where harmonic standards (IEEE 519, EN 61000-3-12) must be met. It is required when using a Basic Line Module without an Active Front End.
Q: Can this reactor be used with other Siemens drive families (e.g., G120, S150)?
A: The 6SL3000-0BE23-6DA1 is dimensioned for the S120 36 A input stage. While physically compatible with other 3-phase 380–480 V systems, always verify inductance and current rating against the target drive’s input specification before substitution.
Q: What is the difference between a line reactor and a line filter (EMC filter)?
A: A line reactor (this product) is an inductive choke that reduces harmonic current distortion. An EMC/RFI filter additionally attenuates high-frequency conducted emissions. For full EMC compliance, both components may be required depending on the installation category.
Q: Do you provide a test report or certificate of conformity?
A: Yes. Siemens Declaration of Conformity and, upon request, a Konmask pre-shipment inspection report are available for every order.
Q: What is the lead time for stock and non-stock units?
A: In-stock units ship within 2–3 business days. Non-stock orders are subject to Siemens factory lead time (typically 4–8 weeks). Contact us for current availability.
