Industrial Drive Storage Solution – SIEMENS 6SL3054-0FC00-1BA0 | SINAMICS S120 Series
Where This Product Is Used
The SIEMENS 6SL3054-0FC00-1BA0 CompactFlash Card is purpose-built for use with the SINAMICS S120 drive system — one of Siemens’ most widely deployed modular servo and vector drive platforms in industrial automation. Typical deployment environments include:
- CNC Machine Tools – Stores axis-specific drive parameters and firmware for multi-axis machining centers, ensuring rapid parameter restore after drive replacement.
- Automotive Assembly Lines – Used in body-in-white welding robots and conveyor drive units where parameter backup is critical for minimizing unplanned downtime.
- Packaging Machinery – Enables fast commissioning of replacement drives on high-speed form-fill-seal and cartoning lines.
- Printing & Paper Converting – Stores tension-control and register-correction parameters for web-fed press drives.
- Crane & Hoist Systems – Retains safety-relevant drive parameters in overhead crane applications where parameter loss could create safety hazards.
- Wind Turbine Pitch Control – Deployed in pitch drive cabinets where reliable non-volatile parameter storage is mandatory.
Technical Specifications
| Part Number | 6SL3054-0FC00-1BA0 |
| Manufacturer | SIEMENS AG |
| Product Series | SINAMICS S120 |
| Product Type | CompactFlash Card (CF Card) |
| Compatible Devices | SINAMICS S120 Control Units (CU320-2, CU310-2, etc.) |
| Function | Drive parameter storage, firmware storage, project data backup |
| Interface | CompactFlash Type I/II slot |
| Operating Temperature | -25 °C to +85 °C (storage); 0 °C to +70 °C (operation) |
| Weight | approx. 500 g (packaged) |
| Country of Origin | Germany / EU |
Why Engineers Specify This Model
- Non-volatile parameter retention – All drive parameters, firmware, and project data are retained without battery backup, eliminating a common failure point.
- Plug-and-play drive replacement – Insert the CF card into a replacement Control Unit and the drive is fully configured within minutes, dramatically reducing MTTR.
- Firmware portability – Carry the exact firmware version required by your machine OEM, preventing version mismatch issues during field service.
- Siemens-certified compatibility – Designed and validated exclusively for SINAMICS S120; avoids the risk of data corruption associated with generic CF cards.
- Rugged industrial-grade flash – Rated for extended temperature ranges and vibration environments typical of drive cabinet installations.
Complete System Bill of Materials
Engineers integrating the 6SL3054-0FC00-1BA0 typically source the following complementary components:
- SINAMICS S120 Control Unit CU320-2 DP – 6SL3040-1MA01-0AA0
- SINAMICS S120 Control Unit CU320-2 PN – 6SL3040-1MA00-0AA0
- SINAMICS S120 Active Line Module – 6SL3130-series
- SINAMICS S120 Motor Module (Single-Axis) – 6SL3120-series
- SINAMICS S120 DRIVE-CLiQ Cable – 6FX2002-series
- STARTER / SINAMICS Startdrive Engineering Software – for parameter upload/download
Compliance & Industry Standards
- CE Marked – compliant with EU Low Voltage Directive and EMC Directive
- UL Listed components within SINAMICS S120 system
- RoHS compliant
- Designed to IEC 61800-5-1 (Adjustable speed electrical power drive systems – safety requirements)
- Compatible with PROFIBUS DP and PROFINET IO network architectures
Quality Assurance & Sourcing
At Konmask.com, every SIEMENS part is sourced through verified supply channels. Our quality process includes:
- Visual and label inspection against Siemens OEM packaging standards
- Hologram and serial number verification where applicable
- Functional test documentation available on request
- Traceability records maintained for each unit shipped
- Secure anti-static packaging for all memory and electronic components
How to Source This Part
To place an order or request a quotation for the SIEMENS 6SL3054-0FC00-1BA0:
- Online: Add to cart directly on this page
- Email RFQ: [email protected]
- Phone / WhatsApp: +0086 19859288691
- Lead Time: In-stock units ship within 1–3 business days; ex-stock orders confirmed at time of inquiry
- MOQ: 1 piece
- Payment: T/T, PayPal, credit card accepted
Application-Specific FAQ
Q: Can I use a standard commercial CompactFlash card instead of 6SL3054-0FC00-1BA0?
A: No. Siemens SINAMICS S120 Control Units require the OEM-specified CF card. Generic cards may cause firmware load failures, data corruption, or drive faults. Always use the Siemens-specified part.
Q: Does this card come pre-loaded with firmware?
A: The card may contain factory firmware. Confirm the firmware version with your machine OEM or Siemens service documentation before installation. Firmware updates can be performed via STARTER or Startdrive software.
Q: Is this card compatible with CU310-2 as well as CU320-2?
A: Compatibility depends on the specific firmware version and hardware revision. Please contact us with your Control Unit order number and we will confirm compatibility before shipment.
Q: What happens if the CF card is removed while the drive is powered?
A: Removing the CF card during operation can cause drive faults and potential data loss. Always power down the Control Unit before inserting or removing the card.
Q: Do you provide a warranty?
A: Yes. All parts supplied by Konmask.com carry a 12-month warranty against manufacturing defects. Warranty claims are processed via our support team.
