SIEMENS 6SL3055-0AA00-4CA4 BOP20 Basic Operator Panel | SINAMICS S120 Drive Platform
Engineering Background: The SIEMENS 6SL3055-0AA00-4CA4 is the BOP20 (Basic Operator Panel 20) designed exclusively for the SINAMICS S120 modular drive system — Siemens’ flagship multi-axis servo and vector drive platform for high-performance industrial automation. The BOP20 serves as the primary local HMI interface, enabling commissioning engineers and maintenance technicians to parameterize, monitor, and diagnose drive units directly at the cabinet without requiring a PC or STARTER software connection.
Product Positioning: Targeted at OEM machine builders, system integrators, and plant maintenance teams operating SINAMICS S120 Control Units (CU320-2, CU310-2, CU250S-2), the 6SL3055-0AA00-4CA4 is an essential commissioning and service tool for servo press lines, winding machines, multi-axis CNC platforms, and high-speed packaging systems. It is stocked and shipped globally by Konmask.com as a verified genuine Siemens component.
Complete Technical Specifications
- Part Number: 6SL3055-0AA00-4CA4
- Product Family: SINAMICS S120 Accessories
- Component Type: BOP20 Basic Operator Panel
- Compatible Control Units: CU320-2 DP, CU320-2 PN, CU310-2 DP, CU310-2 PN, CU250S-2
- Display: 4-line LCD, backlit, alphanumeric
- Interface: Direct plug-in to Control Unit front slot (no external wiring)
- Functions: Parameter read/write, fault/alarm display, drive control (JOG, ON/OFF), status monitoring
- Communication: Local interface via Control Unit slot (not fieldbus)
- Operating Voltage: Powered via Control Unit (no separate supply required)
- Ambient Temperature (Operation): 0 °C to +55 °C
- Storage Temperature: -40 °C to +70 °C
- Protection Rating: IP20 (front panel)
- Weight: approx. 540 g (with packaging)
- Dimensions: Refer to Siemens SINAMICS S120 Manual (6SL3097-4AA00-0BP6)
- Certifications: CE, UL, cUL
- Country of Origin: Germany
Proven Application Environments
- Multi-axis servo drive commissioning on SINAMICS S120 booksize/chassis units
- CNC machine tool spindle and feed axis parameterization
- High-speed packaging and labeling machine drive setup
- Winding and unwinding tension control system commissioning
- Crane and hoist drive diagnostics and fault reset
- Plastics injection molding machine servo axis configuration
- Retrofit and upgrade projects replacing legacy SIMODRIVE 611 systems
- Field service and maintenance without laptop access
Engineering Advantages
- Plug-and-Play Integration: Snaps directly into the CU front slot — no tools, no wiring, operational in seconds.
- Full Parameter Access: Read and write all drive parameters (p-parameters and r-parameters) locally without STARTER/Startdrive software.
- Real-Time Fault Diagnostics: Displays active faults (Fxxxxx) and alarms (Axxxxx) with fault codes for rapid troubleshooting.
- Drive Control Capability: Supports local JOG, enable, and direction commands for commissioning without PLC connection.
- Compact Form Factor: Minimal cabinet space requirement; can remain installed during normal operation as a permanent service interface.
- Genuine Siemens Quality: Full firmware compatibility with SINAMICS S120 firmware V4.x and above; no third-party compatibility risks.
System Architecture & Signal Flow
The BOP20 (6SL3055-0AA00-4CA4) connects directly to the front interface slot of the SINAMICS S120 Control Unit. Communication occurs over the internal CU backplane bus — no additional PROFIBUS or PROFINET address assignment is required. The panel reads drive object parameters from the CU’s parameter memory and writes changes directly to non-volatile storage (EEPROM/flash). During normal PLC-controlled operation, the BOP20 operates in monitoring mode; local control commands are only active when the control source is switched to BOP20 via parameter p0700/p1000 settings.
Typical Wiring / Integration Path:
- SINAMICS S120 Control Unit (CU320-2 / CU310-2) → BOP20 front slot (direct plug)
- No additional power supply, cable, or fieldbus node required
- Compatible with single-axis and multi-axis drive object configurations
Sourcing & Quality Verification
- Source: Authorized distribution channel and verified surplus stock with full traceability
- Inspection: Each unit inspected for physical integrity, label authenticity, and firmware version prior to shipment
- Packaging: Original Siemens ESD-safe packaging or equivalent anti-static packaging for surplus units
- Documentation: Siemens order confirmation or test report available upon request for project documentation
- Warranty: 12-month Konmask operational warranty covering manufacturing defects
Procurement Process
- Confirm part number 6SL3055-0AA00-4CA4 matches your Control Unit model (CU320-2 / CU310-2 / CU250S-2)
- Submit inquiry or place order directly on Konmask.com
- Receive order confirmation with lead time and shipping options (DHL Express / FedEx / sea freight)
- Unit ships with inspection report; tracking provided within 24 hours of dispatch
- Post-delivery technical support available via email or WhatsApp
Technical FAQ
Q: Is the 6SL3055-0AA00-4CA4 compatible with SINAMICS S110 or S150?
A: No. The BOP20 is designed exclusively for SINAMICS S120 Control Units. S110 uses the BOP (6SL3255-0AA00-4CA1) and S150 uses the AOP30 panel.
Q: Can I use the BOP20 to upload/download parameter sets?
A: The BOP20 supports individual parameter read/write but does not support full dataset upload/download (RAM to ROM save is supported). For full dataset transfer, use STARTER or Startdrive with a PC.
Q: Does the BOP20 need to remain installed during machine operation?
A: No. It can be removed after commissioning. The Control Unit operates normally without the BOP20 installed. Many engineers leave it installed as a permanent service interface.
Q: What firmware versions are supported?
A: The 6SL3055-0AA00-4CA4 is compatible with SINAMICS S120 firmware V4.3 and above. Verify your CU firmware version via r0018 before installation.
Q: Can Konmask provide a test certificate or inspection report?
A: Yes. Contact [email protected] with your order number to request documentation for project or audit purposes.
