Industrial Automation Infeed Solution – SIEMENS 6SL3130-6AE15-0AB1 | SINAMICS S120
Where This Product Is Used
The SIEMENS 6SL3130-6AE15-0AB1 Active Line Module is the regenerative infeed backbone for demanding multi-axis drive systems. Engineers specify this unit across a wide range of industrial environments:
- CNC Machining Centers – Provides clean, regulated DC bus power to spindle and feed drives, enabling high-precision multi-axis coordination.
- Robotic Welding & Assembly Lines – Supplies stable infeed to SINAMICS S120 Motor Modules driving articulated robot joints, with regenerative braking energy fed back to the grid.
- Plastics Injection Molding – Supports high-dynamic servo axes for clamping, injection, and ejection with consistent DC link voltage.
- Packaging & Converting Machinery – Powers multi-axis servo systems requiring synchronized motion and low harmonic distortion.
- Textile & Printing Equipment – Delivers stable infeed for tension-controlled winding/unwinding drives.
- Material Handling & Conveyors – Enables energy-efficient operation with regenerative capability during deceleration cycles.
Technical Specifications
| Part Number | 6SL3130-6AE15-0AB1 |
| Series | SINAMICS S120 |
| Module Type | Active Line Module (ALM) |
| Rated Power | 5 kW |
| Input Voltage | 3-phase AC 380–480 V (±10%) |
| Input Frequency | 47–63 Hz |
| DC Link Voltage | ~600 V DC |
| Rated Input Current | ~10 A |
| Cooling Method | Internal air cooling (push-through option available) |
| Protection Class | IP20 |
| Ambient Temperature | 0 °C to +40 °C (derating above 40 °C) |
| Storage Temperature | -40 °C to +70 °C |
| Dimensions (H×W×D) | Booksize format – refer to SINAMICS S120 hardware manual |
| Weight | Approx. 3.5 kg |
| Communication Interface | DRIVE-CLiQ |
| Firmware Compatibility | SINAMICS S120 firmware V4.x and above |
Why Engineers Specify This Model
- Regenerative Infeed – Returns braking energy to the supply grid, reducing net energy consumption by up to 30% in cyclic applications.
- Low Harmonic Distortion – Active front-end topology keeps THDi well below passive rectifier alternatives, protecting sensitive plant equipment.
- Unity Power Factor – Operates at cos φ ≈ 1, eliminating reactive power penalties on industrial tariffs.
- DRIVE-CLiQ Integration – Plug-and-play topology recognition within SINAMICS S120 booksize cabinet kits; automatic parameterization via STARTER / TIA Portal.
- Compact Booksize Form Factor – Minimizes cabinet footprint; mounts directly alongside Motor Modules on a shared DC bus rail.
- Proven Reliability – Designed to SIEMENS IEC/EN 61800-5-1 standards with full CE and UL recognition.
Complete System Bill of Materials
The 6SL3130-6AE15-0AB1 is the infeed node in a complete SINAMICS S120 booksize drive line-up. A typical system includes:
- Active Line Module: 6SL3130-6AE15-0AB1 (this unit)
- Active Interface Module (AIM): 6SL3100-0BE21-6AB0 (recommended for grid compliance)
- Single Motor Module: 6SL3120-1TE21-0AA3 / 6SL3120-1TE23-0AA3 (per axis)
- Control Unit: 6SL3040-1MA00-0AA0 (CU320-2 DP or CU320-2 PN)
- DRIVE-CLiQ Hub: 6SL3162-2AA00-0AA0
- Braking Module (optional): 6SL3100-1BE21-3AA0
- Cabinet Kit / Mounting Rail: per SINAMICS S120 cabinet design guide
Compliance & Industry Standards
- CE Marking – EU Low Voltage Directive 2014/35/EU & EMC Directive 2014/30/EU
- UL Listed – UL 508C (Power Conversion Equipment)
- IEC/EN 61800-5-1 – Adjustable speed electrical power drive systems
- IEC/EN 61800-3 – EMC requirements, Category C2/C3
- RoHS Compliant
- REACH Compliant
Quality Assurance & Sourcing
Every unit offered through Konmask.com undergoes a structured verification process:
- Visual Inspection – Label authenticity, housing integrity, connector condition, and firmware version label checked against SIEMENS factory standards.
- Functional Pre-test – DC link charge/discharge cycle and DRIVE-CLiQ handshake verified where applicable.
- Traceability – Serial number and date code recorded; traceable to authorized distribution or OEM decommission channels.
- Packaging – Anti-static bag + foam-lined export carton; humidity indicator card included for long-haul shipments.
How to Source This Part
Ready to order or need a formal quotation for your procurement team?
- Online Order – Add to cart and check out directly. We accept T/T, PayPal, and major credit cards.
- RFQ / Bulk Inquiry – Email support@konmask.com with your required quantity, delivery timeline, and destination port.
- Lead Time – In-stock units ship within 1–3 business days. Ex-stock orders confirmed by proforma invoice.
- Export Documentation – Commercial invoice, packing list, and certificate of origin available for all international shipments.
Application-Specific FAQ
Q: Can the 6SL3130-6AE15-0AB1 operate on a 480 V / 60 Hz North American supply?
A: Yes. The unit accepts 380–480 V AC ±10% at 47–63 Hz, making it fully compatible with North American 480 V / 60 Hz industrial supplies.
Q: How many Motor Modules can this Active Line Module support?
A: The 5 kW rating limits the total connected Motor Module load. For multi-axis systems exceeding 5 kW aggregate, a higher-rated ALM (e.g., 6SL3130-6AE21-0AB1 or above) is recommended.
Q: Is a line reactor or Active Interface Module required?
A: SIEMENS recommends pairing the ALM with an Active Interface Module (AIM) for full grid compliance and to meet IEC 61000-3-12 harmonic limits. Contact us for AIM part numbers.
Q: What SINAMICS firmware version is required?
A: Firmware V4.7 SP9 or later is recommended for full feature support. Older firmware versions may limit certain ALM functions.
Q: Do you provide a warranty?
A: Yes. All units carry a 12-month warranty against manufacturing defects. Warranty claims are processed via support@konmask.com.
