Industrial Motion Control Solution – Siemens 6SL3201-0BE21-0AA0 | SINAMICS S120
Where This Product Is Used
The Siemens 6SL3201-0BE21-0AA0 is a SINAMICS S120 Single Motor Module in booksize format, designed for high-precision multi-axis motion control in demanding industrial environments. Typical deployment scenarios include:
- CNC Machine Tools – Coordinated axis control for milling, turning, and grinding centers requiring sub-millisecond torque response.
- Packaging Machinery – High-speed servo drives for form-fill-seal lines, cartoners, and palletizers where synchronization is critical.
- Printing & Converting – Register control and tension management on web-fed offset and flexographic presses.
- Robotics & Handling – Joint actuation in SCARA, delta, and 6-axis articulated robots integrated with SIMOTION D controllers.
- Textile & Winding – Constant-tension winding/unwinding with dynamic speed compensation.
- Semiconductor & Electronics Manufacturing – Clean-room compatible motion axes for wafer handling and PCB assembly equipment.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number (SKU) | 6SL3201-0BE21-0AA0 |
| Product Family | SINAMICS S120 |
| Module Type | Single Motor Module (Booksize) |
| Output Current (Continuous) | 1.4 A |
| Output Current (Peak) | 3.0 A |
| DC Link Voltage | 600 V DC |
| Switching Frequency | 4 / 8 / 16 kHz (selectable) |
| Drive Object | Servo / Vector |
| Cooling Method | Forced air (internal fan) |
| Communication Interface | DRIVE-CLiQ |
| Protection Class | IP20 |
| Ambient Temperature | 0 °C … +40 °C (up to +55 °C derated) |
| Dimensions (W × H × D) | 30 mm × 380 mm × 270 mm (approx.) |
| Weight | ~1.0 kg |
| Manufacturer | Siemens AG |
| Country of Origin | Germany / EU |
Why Engineers Specify This Model
- Ultra-compact booksize form factor – 30 mm width enables high-density multi-axis cabinets, reducing panel footprint by up to 40% vs. standalone drives.
- DRIVE-CLiQ daisy-chain topology – Single cable carries power, encoder feedback, and diagnostics, eliminating separate encoder wiring and simplifying commissioning.
- Shared DC bus architecture – Energy regenerated during deceleration is instantly reused by accelerating axes, cutting energy consumption in multi-axis systems.
- Integrated safety functions – STO (Safe Torque Off) and SS1 (Safe Stop 1) certified to SIL 2 / PLe without external safety relays.
- Seamless SIMOTION / SINUMERIK integration – Native isochronous PROFINET and DRIVE-CLiQ ensure deterministic cycle times ≤ 125 µs for servo-class performance.
- Scalable within S120 ecosystem – Mix and match with Line Modules, Control Units (CU320-2), and Sensor Modules without re-engineering the DC bus.
Complete System Bill of Materials
A fully operational SINAMICS S120 drive system based on this Motor Module typically requires:
- Line Module (Active/Smart/Basic) – e.g., 6SL3130-6AE21-0AB1 (Active Line Module, 16 kW) for DC bus supply and regenerative feedback.
- Control Unit – e.g., 6SL3040-1MA01-0AA0 (CU320-2 DP) or CU320-2 PN for centralized multi-axis control.
- DRIVE-CLiQ Hub Module – e.g., 6SL3055-0AA00-2AA0 (DMC20) for topology expansion.
- Sensor Module Cabinet (SMC) – e.g., 6SL3055-0AA00-5AA3 (SMC30) for TTL/HTL encoder evaluation.
- Braking Module & Resistor – Required if regenerative line module is not used.
- 24 V DC Power Supply – SITOP PSU100S or equivalent for control electronics.
- Motor with DRIVE-CLiQ interface – e.g., Siemens 1FK7 or 1FT7 servo motor series.
Contact Konmask for complete BOM configuration support and compatibility verification.
Compliance & Industry Standards
- CE Marking – EU Low Voltage Directive 2014/35/EU & EMC Directive 2014/30/EU
- UL Listed – UL 508C (Power Conversion Equipment)
- cUL Listed – CSA C22.2 No. 14
- Functional Safety – IEC 62061 (SIL 2), EN ISO 13849-1 (PLe, Cat. 3)
- EMC – EN 61800-3 Category C2 (with recommended filter)
- RoHS Compliant – Directive 2011/65/EU
Quality Assurance & Sourcing
- Verified Authentic – All units sourced from authorized Siemens distribution channels or certified industrial surplus with full traceability documentation.
- Pre-shipment Inspection – Each module undergoes visual inspection, label verification, and functional power-on test before dispatch.
- Warranty – 12-month replacement warranty against manufacturing defects.
- Packaging – Original or equivalent ESD-safe packaging with anti-static foam inserts.
- Documentation – Siemens product datasheet, EU Declaration of Conformity, and test report available on request.
How to Source This Part
Konmask maintains ready stock and global sourcing networks for SINAMICS S120 components. To place an order or request a quote:
- Email: support@konmask.com
- Phone / WhatsApp: +0086 19859288691
- Website: https://konmask.com
- Provide your required quantity, delivery timeline, and destination country for a tailored quotation.
- Expedited sourcing available for urgent MRO and production-line-down situations.
Application-Specific FAQ
Q: Can the 6SL3201-0BE21-0AA0 operate as a standalone drive without a CU320-2?
A: No. This Motor Module requires a SINAMICS S120 Control Unit (e.g., CU320-2 DP/PN or CU310-2) connected via DRIVE-CLiQ. It cannot operate independently.
Q: What motor types are compatible?
A: Synchronous servo motors (1FK7, 1FT7), asynchronous induction motors, and linear motors with appropriate encoder feedback. DRIVE-CLiQ-equipped motors enable automatic motor identification.
Q: Is this module suitable for safety-critical applications?
A: Yes. The integrated STO function is certified to SIL 2 / PLe, making it suitable for Category 3 safety architectures per EN ISO 13849-1 without additional external safety relays.
Q: What is the maximum cable length between the Motor Module and the motor?
A: Siemens specifies a maximum motor cable length of 50 m (shielded) for standard configurations. Longer runs require output reactors (e.g., 6SL3202-0AE21-0AA0).
Q: Can I mix this module with older SINAMICS S120 booksize modules on the same DC bus?
A: Yes, provided all modules share the same firmware generation and the Line Module is correctly sized for the total connected load. Consult the SINAMICS S120 System Manual (6SL3097-4AA00-0BP6) for bus sizing rules.
