Variable Speed Drive Solution – Siemens 6SL3224-0BE32-2AA0 | SINAMICS S120
Where This Product Is Used
The Siemens 6SL3224-0BE32-2AA0 is a booksize-format Inverter Power Module from the SINAMICS S120 series, engineered for demanding multi-axis and single-axis drive applications across heavy industry. Typical deployment environments include:
- Conveyor & Material Handling Systems – Precise speed regulation for belt conveyors, roller tables, and automated sorting lines in logistics and mining.
- CNC Machine Tools & Machining Centers – Coordinated axis control for spindle drives and feed axes requiring high dynamic response.
- Printing & Packaging Machinery – Synchronised multi-axis motion for web tension control, register accuracy, and high-speed cut-to-length operations.
- Crane & Hoist Applications – Safe torque-off (STO) and controlled deceleration for overhead cranes, gantry systems, and hoisting equipment.
- Pump & Fan Drives – Energy-efficient variable-speed control in HVAC, water treatment, and process cooling systems.
- Plastics & Rubber Processing – Extruder and injection moulding machine drives requiring precise torque and speed profiles.
- Steel & Rolling Mill Drives – High-torque, regenerative operation for rolling stands and coiler/decoiler applications.
Technical Specifications
| Part Number | 6SL3224-0BE32-2AA0 |
| Series | SINAMICS S120 Booksize |
| Module Type | Single Motor Module (Inverter Power Module) |
| Rated Output Current | 22 A (continuous) |
| Peak Output Current | 45 A (60 s overload) |
| Motor Power (400 V) | 11 kW (at 400 V AC) |
| DC Link Voltage | 510–720 V DC |
| Supply Voltage | 3 AC 380–480 V, 50/60 Hz (via Line Module) |
| Switching Frequency | 4 kHz (default); 8 / 16 kHz selectable |
| Protection Class | IP20 |
| Cooling Method | Forced air cooling (internal fan) |
| Communication Interface | DRIVE-CLiQ |
| Safety Function | STO (Safe Torque Off) – SIL 2 / PLd |
| Dimensions (W × H × D) | 50 mm × 380 mm × 270 mm |
| Weight | approx. 6.8 kg |
| Operating Temperature | 0 °C to +40 °C (derating above 40 °C) |
| Storage Temperature | −40 °C to +70 °C |
| Humidity | ≤ 95 % RH, non-condensing |
| Altitude | Up to 1000 m without derating |
Why Engineers Specify This Model
- Booksize Form Factor – Compact 50 mm width enables high-density multi-axis cabinet layouts, reducing panel footprint by up to 40 % versus standalone drives.
- DRIVE-CLiQ Topology – Single-cable connection to motors and encoders eliminates manual parameter entry and enables automatic component identification.
- Integrated STO (SIL 2 / PLd) – Meets EN 62061 and EN ISO 13849-1 without external safety relays, simplifying CE/machinery directive compliance.
- Shared DC Bus Architecture – Energy regenerated during braking is fed back to the DC bus and consumed by motoring axes, reducing net energy consumption.
- Vector & Servo Control Modes – Supports V/f, sensorless vector, and closed-loop servo control from a single firmware platform.
- Seamless TIA Portal Integration – Native integration with Siemens Totally Integrated Automation for commissioning, diagnostics, and lifecycle management.
Complete System Bill of Materials
The 6SL3224-0BE32-2AA0 Motor Module requires the following companion components for a complete SINAMICS S120 drive system:
- Line Module (Active/Smart/Basic) – e.g., 6SL3130-6AE21-0AB1 (Active Line Module, 16 kW) for DC bus supply and regeneration.
- Control Unit – CU320-2 DP (6SL3040-1MA01-0AA0) or CU320-2 PN for PROFIBUS / PROFINET control.
- DRIVE-CLiQ Hub Module – 6SL3162-2AA00-0AA0 for topology expansion.
- Braking Module & Resistor – 6SL3100-1BE21-3AA0 (if non-regenerative braking required).
- Line Filter & Reactor – 6SL3000-0BE21-6DA0 (line reactor) for EMC compliance and harmonic reduction.
- SIMOTICS Motor – Compatible 1FK7 / 1FT7 / 1PH8 series motors with DRIVE-CLiQ encoder interface.
- Cabinet Busbar System – 6SL3162-2BM00-0AA0 DC link busbar adapter for booksize modules.
Contact [email protected] for complete system BOM quotations.
Compliance & Industry Standards
- CE Marking – Low Voltage Directive 2014/35/EU & EMC Directive 2014/30/EU
- UL Listed – UL 508C (Power Conversion Equipment)
- cUL Listed – CSA C22.2 No. 14
- EN 61800-5-1 (Adjustable Speed Electrical Power Drive Systems – Safety)
- EN 61800-3 (EMC Requirements – Category C2)
- EN 62061 / EN ISO 13849-1 – Functional Safety (STO: SIL 2 / PLd)
- RoHS Compliant
Quality Assurance & Sourcing
Konmask.com sources the 6SL3224-0BE32-2AA0 exclusively through verified industrial distribution channels. Every unit undergoes the following before dispatch:
- Visual inspection for physical damage, label integrity, and seal verification.
- Firmware version check and documentation of hardware revision.
- Functional power-on test where applicable.
- Anti-static packaging with humidity indicator card.
- Full traceability documentation available on request (batch records, COC).
We do not supply grey-market, refurbished, or counterfeit components. All stock is traceable to authorised distribution.
How to Source This Part
To request a quotation or check real-time availability for the Siemens 6SL3224-0BE32-2AA0:
- Email: [email protected]
- Phone / WhatsApp: +0086 19859288691
- Website: https://Konmask.com
Please provide your required quantity, delivery timeline, and destination country. We respond to all enquiries within 1 business day. Volume pricing and blanket order arrangements are available for OEM and system integrator customers.
Application-Specific FAQ
Q: Can the 6SL3224-0BE32-2AA0 operate as a standalone drive without a Line Module?
A: No. As a booksize Motor Module, it requires a separate SINAMICS S120 Line Module to supply the DC bus. It cannot be powered directly from AC mains.
Q: What is the maximum cable length between the Motor Module and the motor?
A: Siemens specifies a maximum shielded motor cable length of 50 m (standard) or up to 100 m with an output reactor (6SL3202-0AE21-8CA0). Longer runs require engineering review.
Q: Is STO wiring required for standard operation?
A: STO terminals must be correctly wired or bridged for the drive to enable. In non-safety applications, the STO inputs are typically bridged with 24 V DC. In safety-rated installations, they must be connected to a certified safety controller.
Q: Which Control Unit firmware version is compatible?
A: The 6SL3224-0BE32-2AA0 is compatible with CU320-2 firmware V4.7 SP10 and above. Always verify compatibility in the Siemens SINAMICS S120 compatibility matrix before upgrading firmware.
Q: Can this module be used in a multi-axis configuration?
A: Yes. Multiple Motor Modules share a common DC bus via the booksize busbar system, enabling coordinated multi-axis motion under a single Control Unit (up to 6 axes per CU320-2, depending on firmware and performance class).
Q: What is the lead time for this part?
A: Lead time depends on current stock levels. Contact us at [email protected] or +0086 19859288691 for real-time availability.
