SIGMATEK ETT1233 (01-230-1233) – Industrial HMI Touch Screen Panel | SIGMATEK ETT Series
Engineering Background
The SIGMATEK ETT1233, part number 01-230-1233, is a high-performance industrial Human-Machine Interface (HMI) touch screen panel engineered for demanding automation environments. SIGMATEK, an Austrian automation specialist, developed the ETT series to deliver robust, real-time visualization and operator control within its LASAL-based control architecture. The ETT1233 integrates seamlessly with SIGMATEK’s DIAS (Distributed Intelligent Automation System) platform, making it a preferred choice for machine builders and system integrators across Europe and globally.
Product Positioning
Designed for procurement engineers sourcing reliable HMI components for industrial control panels, the ETT1233 offers a proven combination of touch responsiveness, industrial-grade durability, and native compatibility with SIGMATEK controllers. Whether for OEM replacement, system expansion, or new machine builds, this unit delivers consistent performance in production-critical applications.
Complete Technical Specifications
- Manufacturer: SIGMATEK GmbH & Co KG (Austria)
- Model Number: ETT1233
- Part Number: 01-230-1233
- Series: ETT (Embedded Touch Terminal) Series
- Display Type: Industrial TFT LCD Touch Screen
- Interface: Resistive or Capacitive Touch (ETT Series standard)
- Communication: Compatible with SIGMATEK DIAS-Bus / Ethernet / CANopen (per system configuration)
- Operating Voltage: 24 VDC (nominal)
- Protection Rating: IP65 front panel (panel-mount installation)
- Operating Temperature: 0°C to +50°C
- Storage Temperature: -20°C to +70°C
- Weight: Approx. 300 g
- Mounting: Panel cut-out, front-mount
- Software Platform: SIGMATEK LASAL Class / LASAL Visualization
- Certifications: CE marked; compliant with applicable EU Machinery Directive requirements
Proven Application Environments
- Packaging machinery and conveyor control systems
- Plastics injection molding and extrusion lines
- Textile and printing machine HMI stations
- Woodworking and CNC machining centers
- Building automation and HVAC control panels
- Food & beverage processing equipment
- Renewable energy and power management systems
Engineering Advantages
- Native SIGMATEK Integration: Plug-and-play compatibility with SIGMATEK DIAS controllers eliminates custom driver development and reduces commissioning time.
- Industrial-Grade Durability: IP65 front panel protection guards against dust and water ingress in harsh factory environments.
- LASAL Visualization Ready: Supports SIGMATEK’s LASAL Class visualization objects for rapid HMI screen development without third-party SCADA software.
- Compact Panel-Mount Form Factor: Optimized for space-constrained control cabinet installations with standard panel cut-out dimensions.
- Long Service Life: SIGMATEK’s industrial-grade component selection ensures extended MTBF suitable for 24/7 production environments.
System Architecture & Signal Flow
The ETT1233 operates as a visualization and operator input node within the SIGMATEK DIAS automation architecture. It connects to the host SIGMATEK controller (e.g., DIAS-CPU or LASAL controller) via the DIAS-Bus or Ethernet interface, receiving real-time process data and transmitting operator commands. The LASAL Visualization runtime executes directly on the terminal, rendering HMI screens defined in the LASAL Class development environment. Signal flow: Operator Input → ETT1233 Touch Panel → DIAS-Bus/Ethernet → SIGMATEK Controller → Field Devices (I/O, Drives, Sensors).
Sourcing & Quality Verification
- Stock Status: Verified surplus / new-old-stock (NOS) units available at Konmask.com
- Inspection: Each unit undergoes visual inspection and functional verification prior to shipment
- Authenticity: All units sourced from traceable industrial supply channels; counterfeit-free guarantee
- Packaging: Anti-static packaging with protective foam insert for safe international transit
- Lead Time: Typically ships within 3–7 business days; expedited options available
- Warranty: 90-day functional warranty against manufacturing defects
Procurement Process
- Confirm Part Number: Verify ETT1233 / 01-230-1233 matches your system’s BOM or existing installed unit label.
- Request Quote: Contact [email protected] with quantity, delivery address, and required lead time.
- Order Confirmation: Receive proforma invoice with unit price, shipping cost, and estimated delivery date.
- Payment & Dispatch: Payment via T/T, PayPal, or credit card. Unit dispatched with tracking number within agreed lead time.
- Incoming Inspection: Recommended: verify part number label, inspect for physical damage, and bench-test before installation.
Technical FAQ
Q: Is the ETT1233 compatible with all SIGMATEK controllers?
A: The ETT1233 is designed for use within the SIGMATEK DIAS ecosystem. Compatibility depends on the specific controller firmware and LASAL software version. Please consult your SIGMATEK system documentation or contact us for compatibility confirmation.
Q: Can the ETT1233 be used as a standalone HMI with non-SIGMATEK PLCs?
A: The ETT1233 is optimized for SIGMATEK’s proprietary DIAS-Bus and LASAL environment. Integration with third-party PLCs would require custom communication drivers and is not a standard supported configuration.
Q: What is the display resolution of the ETT1233?
A: Exact display resolution specifications are available in the SIGMATEK ETT1233 datasheet. Contact [email protected] for the full technical datasheet.
Q: Do you provide installation support?
A: Konmask.com provides pre-sales technical consultation and can connect you with qualified SIGMATEK system integrators. On-site installation services are not included but can be arranged upon request.
Q: What is the minimum order quantity (MOQ)?
A: MOQ is 1 unit. Volume pricing is available for orders of 3 units or more.
