Servo Drive Control Solution – SYSTEM PDS-BX02S1421 PA03381-B399 | Servo Control Card Series
Where This Product Is Used
The SYSTEM PDS-BX02S1421 PA03381-B399 Servo Control Card is a precision motion control interface designed for demanding industrial automation environments. Typical deployment scenarios include:
- CNC Machining Centers – Provides closed-loop servo axis control for multi-axis milling, turning, and grinding machines requiring sub-micron positioning accuracy.
- Robotic Assembly Lines – Interfaces with servo amplifiers to coordinate joint motion in articulated and SCARA robots used in automotive and electronics manufacturing.
- Semiconductor Wafer Handling – Delivers the low-vibration, high-repeatability motion control required for wafer transfer stages and inspection platforms.
- Printing & Packaging Machinery – Synchronizes web tension and register control across multi-axis servo systems in high-speed printing presses and form-fill-seal machines.
- Injection Molding Machines – Controls servo-driven hydraulic pump axes and ejector mechanisms for energy-efficient, precision molding cycles.
- Medical Device Manufacturing – Supports the precise, repeatable motion demanded by automated dispensing, cutting, and assembly equipment in cleanroom environments.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | SYSTEM |
| Part Number | PDS-BX02S1421 PA03381-B399 |
| Module Type | Servo Control Card |
| Form Factor | PCB Card / Plug-in Module |
| Control Interface | Servo Drive Command & Feedback Interface |
| Feedback Compatibility | Encoder / Resolver (refer to OEM documentation) |
| Communication Bus | Proprietary SYSTEM Backplane Bus |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -25 °C to +70 °C |
| Humidity | 5% to 95% RH, non-condensing |
| Weight | 100 g (approx.) |
| Condition Available | New / Refurbished / Tested Surplus |
Note: Full electrical specifications are available in the SYSTEM OEM technical manual. Contact us for documentation support.
Why Engineers Specify This Model
- OEM-Matched Performance – Designed specifically for SYSTEM servo drive platforms, ensuring seamless parameter compatibility and eliminating cross-brand integration risk.
- High-Resolution Motion Control – Supports fine interpolation and real-time feedback processing critical for precision manufacturing applications.
- Proven Field Reliability – The PDS-BX02S1421 series has an established track record in high-duty-cycle industrial environments with demanding uptime requirements.
- Drop-In Replacement – Maintains original connector pinout and backplane interface, enabling fast swap-out during maintenance windows without system reconfiguration.
- Reduced Downtime Risk – Sourcing through Konmask ensures tested, verified stock is available for emergency replacement, avoiding extended OEM lead times.
Complete System Bill of Materials
The PDS-BX02S1421 PA03381-B399 Servo Control Card typically operates within a broader SYSTEM servo drive system. Common companion components include:
- SYSTEM Servo Drive / Amplifier Unit (matching axis rating)
- SYSTEM Main CPU / Controller Module
- SYSTEM Power Supply Module (24 VDC / 48 VDC as required)
- Encoder Feedback Cable Assembly (OEM-specified shielded cable)
- Servo Motor (matched torque/speed rating)
- Backplane / Rack Chassis (SYSTEM compatible)
- I/O Interface Module (digital inputs for limit switches, home sensors)
Contact our technical team to source complete system assemblies or individual replacement components.
Compliance & Industry Standards
- CE Marking – Manufactured in compliance with applicable EU Machinery and EMC Directives (verify with OEM documentation for specific revision).
- RoHS Compliance – Restriction of Hazardous Substances compliant per applicable manufacturing revision.
- IEC 61800 – Designed for use within adjustable speed electrical power drive systems per IEC 61800 series guidelines.
- ISO 9001 – SYSTEM manufacturing facilities operate under ISO 9001 quality management systems.
Compliance documentation available upon request. Please contact support@konmask.com for certificates.
Quality Assurance & Sourcing
At Konmask.com, every servo control card undergoes a structured quality verification process before dispatch:
- Visual Inspection – PCB, connectors, and component integrity checked against OEM reference standards.
- Functional Bench Test – Where applicable, modules are powered and tested for correct initialization and communication response.
- Anti-Static Packaging – All cards are shipped in ESD-safe bags with foam cushioning to prevent transit damage.
- Traceability – Batch records and sourcing documentation maintained for all stocked units.
- Warranty – 90-day replacement warranty on verified functional units. Extended warranty available on request.
How to Source This Part
- Add to Cart – Place your order directly through this product page for in-stock units.
- Request a Quote – For bulk orders, system assemblies, or urgent requirements, email support@konmask.com with your quantity and delivery timeline.
- Phone / WhatsApp – Reach our technical sales team at +0086 19859288691 for immediate assistance.
- Lead Time – In-stock units ship within 1–3 business days. Out-of-stock sourcing typically 7–21 business days depending on availability.
- Export & Customs – We support international shipments with full commercial invoice and packing list documentation for customs clearance.
Application-Specific FAQ
Q: Is the PDS-BX02S1421 PA03381-B399 compatible with all SYSTEM servo drives?
A: This card is designed for specific SYSTEM drive platforms. Please share your existing drive model number with our team to confirm compatibility before ordering.
Q: Can this card be used as a direct replacement for a failed unit without reprogramming?
A: In most cases, yes — provided the replacement unit matches the original firmware revision. Our team can advise on firmware matching requirements.
Q: Do you provide installation support?
A: We provide technical documentation and remote guidance. On-site commissioning support can be arranged through our partner network.
Q: What is the typical failure mode for this card?
A: Common failure modes include encoder feedback signal loss, overcurrent protection faults, and communication bus errors. Our team can assist with fault diagnosis prior to replacement.
Q: Can I return the card if it does not resolve my system fault?
A: Yes. We offer a 30-day return window for unused, uninstalled units. Tested and installed units are covered under our 90-day replacement warranty.
