AZBIL C36-TC0UA1400 – Precision Temperature & Process Digital Controller | C36 Series Platform
Engineering Background
The AZBIL C36-TC0UA1400 is a high-performance digital controller engineered by Yamatake Corporation (AZBIL), a globally recognized leader in building automation and industrial process control instrumentation. The C36 series represents AZBIL’s commitment to delivering compact, reliable, and highly configurable control solutions for demanding industrial environments. With decades of field-proven deployment across Asia-Pacific and global manufacturing facilities, the C36 platform is a trusted choice for process engineers requiring precise closed-loop control.
Product Positioning
The C36-TC0UA1400 is positioned as a DIN-rail-compatible, single-loop digital controller optimized for temperature regulation and analog process variable management. It is designed for OEM panel builders, system integrators, and end-users in industries where measurement accuracy, PID stability, and long-term reliability are non-negotiable. Konmask.com supplies this unit as a verified, traceable component for industrial automation procurement teams.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | AZBIL (Yamatake Corporation) |
| Model Number | C36-TC0UA1400 |
| Series | C36 Digital Controller Series |
| Controller Type | Single-loop Digital PID Controller |
| Input Type | Thermocouple / RTD / Analog (model-dependent) |
| Control Mode | PID / ON-OFF / Manual |
| Output Type | Universal output (relay / voltage pulse / current, per suffix) |
| Display | Dual 4-digit LED display (PV / SV) |
| Sampling Period | Approx. 100 ms |
| Power Supply | 100–240 VAC, 50/60 Hz |
| Power Consumption | ≤ 7 VA |
| Ambient Temperature | 0 to 50°C (operating); -20 to 60°C (storage) |
| Humidity | 35 to 85% RH (non-condensing) |
| Enclosure Rating | IP54 (front panel) |
| Mounting | Panel mount, 1/16 DIN (48 × 48 mm cutout) |
| Weight | Approx. 200 g |
| Communication | RS-485 (optional, model-dependent) |
| Certifications | CE, UL (model-dependent) |
| Country of Origin | Japan |
Proven Application Environments
- Plastics & Rubber Processing: Extruder barrel temperature zone control with multi-setpoint ramp/soak profiles
- Food & Beverage Manufacturing: Pasteurization, sterilization, and oven temperature regulation
- Pharmaceutical Production: Cleanroom HVAC and autoclave process control requiring audit-trail compliance
- Chemical & Petrochemical Plants: Reactor temperature and pressure loop management
- Semiconductor Fabrication: Diffusion furnace and CVD chamber thermal management
- HVAC & Building Automation: Chiller, AHU, and boiler control integrated with BMS systems
- OEM Panel Builders: Embedded in custom control panels for machine builders across Asia and Europe
Engineering Advantages
- Auto-Tuning PID: One-touch AT function automatically calculates optimal P, I, D parameters, reducing commissioning time significantly
- Universal Input Flexibility: Accepts thermocouple (K, J, T, E, R, S, B, N), RTD (Pt100), and DC analog inputs without hardware modification
- Compact 1/16 DIN Form Factor: 48 × 48 mm panel cutout enables high-density panel layouts, maximizing cabinet real estate
- Dual Display Architecture: Simultaneous PV and SV readout eliminates operator error during setpoint verification
- Ramp/Soak Programming: Multi-step program capability supports complex thermal profiles for batch processes
- Alarm Outputs: Configurable process, deviation, and band alarms with latching/non-latching options
- Long Service Life: AZBIL’s industrial-grade component selection ensures MTBF exceeding 100,000 hours in standard operating conditions
System Architecture & Signal Flow
The C36-TC0UA1400 operates as a standalone closed-loop controller within a standard process control architecture:
- Sensor Input Stage: Field sensor (thermocouple/RTD) connects to the universal input terminal block. The controller performs cold-junction compensation and linearization internally.
- PID Computation Engine: The measured PV is compared against the operator-set SV. The PID algorithm computes the manipulated variable (MV) output at each 100 ms sampling cycle.
- Output Stage: MV is delivered via relay, voltage pulse (SSR drive), or 4–20 mA current output to the final control element (heater, valve, VFD).
- Communication Interface (optional): RS-485 Modbus RTU allows SCADA/DCS integration for remote setpoint adjustment, PV monitoring, and alarm status polling.
- Alarm & Interlock: Discrete alarm outputs interface with PLC safety circuits or annunciator panels for process deviation notification.
Sourcing & Quality Verification
- Authorized Supply Chain: Konmask.com sources AZBIL products through verified distribution channels with full traceability documentation available upon request
- Authenticity Guarantee: Each unit undergoes visual inspection and label verification against AZBIL’s official part numbering schema before dispatch
- Packaging Integrity: Products are shipped in original OEM packaging with factory seals intact; any deviation is disclosed prior to order confirmation
- Documentation Support: Datasheet, wiring diagram, and operation manual available for download or provided upon request
- Warranty: 12-month warranty against manufacturing defects; DOA replacement policy within 7 days of receipt
Procurement Process
- Inquiry Submission: Contact Konmask.com via email or phone with your required quantity, delivery timeline, and any special configuration requirements
- Quotation & Lead Time: Formal quotation issued within 1 business day; typical lead time 3–7 business days for in-stock units
- Order Confirmation: Purchase order accepted via email; proforma invoice issued for prepayment or credit-term customers
- Quality Inspection & Dispatch: Pre-shipment inspection completed; tracking number provided within 24 hours of dispatch
- After-Sales Support: Technical support available via email and phone for installation, commissioning, and parameter configuration queries
Technical FAQ
Q: Is the C36-TC0UA1400 compatible with Type K thermocouples?
A: Yes. The C36 series supports Type K, J, T, E, R, S, B, and N thermocouples as well as Pt100 RTD inputs. Input type is configured via front-panel parameter settings.
Q: Can this controller be integrated with a Siemens or Mitsubishi PLC via Modbus?
A: Yes, provided the RS-485 communication option is included in the model suffix. The controller supports Modbus RTU protocol, compatible with any PLC or SCADA system with an RS-485 master port.
Q: What is the difference between C36-TC0UA1400 and other C36 variants?
A: The model suffix encodes the input type, output configuration, power supply, and communication options. The TC0UA1400 suffix specifies this unit’s particular combination. Contact Konmask.com for cross-reference assistance if you require an alternative configuration.
Q: Does Konmask.com provide installation and commissioning support?
A: Yes. Our technical team provides remote support for parameter configuration, PID tuning guidance, and wiring verification. On-site support can be arranged for large-scale projects.
Q: What is the minimum order quantity (MOQ)?
A: MOQ is 1 unit. Volume pricing is available for orders of 5 units or more. Contact us for a tiered pricing schedule.
