TOX PRESSOTECHNIK 0610520IF120243B – Machinery Protection Monitor | Force Monitoring & Press Control Platform
Engineering Background
TOX PRESSOTECHNIK is a globally recognized leader in press-fit, clinching, and force-controlled joining technology. The 0610520IF120243B is a precision machinery protection monitor engineered for industrial press systems, assembly lines, and force-critical manufacturing processes. Designed to safeguard both tooling and workpieces, this unit continuously evaluates force signatures in real time, triggering protective shutdowns before mechanical damage occurs.
Product Positioning
Targeted at process engineers and maintenance teams operating high-cycle press systems, the 0610520IF120243B integrates seamlessly into existing TOX PRESSOTECHNIK control architectures. It is the preferred choice for OEMs and system integrators requiring deterministic force monitoring with minimal integration overhead. Konmask.com supplies this unit as verified OEM stock, fully traceable and ready for immediate deployment.
Complete Technical Specifications
| Manufacturer | TOX PRESSOTECHNIK GmbH & Co. KG |
| Part Number | 0610520IF120243B |
| Product Family | Machinery Protection Monitor |
| Function | Real-time force monitoring & overload protection for press systems |
| Interface | IF (Interface module) — integrates with TOX control platforms |
| Signal Type | Analog force signal input with digital output triggers |
| Monitoring Channels | Configurable per system architecture |
| Protection Class | IP20 (panel-mount installation) |
| Supply Voltage | 24 V DC (nominal) |
| Weight | 2,900 g |
| SKU / Order Code | 0610520IF120243B |
| Compliance | CE marked; designed to EN/IEC industrial standards |
Proven Application Environments
- Automotive body-in-white press and clinching stations
- Electronic component press-fit assembly (PCB, connectors)
- Metal stamping and forming lines requiring force envelope monitoring
- Medical device assembly with strict force traceability requirements
- Aerospace sub-assembly joining processes
- General industrial press systems with overload protection mandates
Engineering Advantages
- Real-Time Overload Detection: Continuously compares live force curves against programmed envelopes; triggers immediate shutdown on deviation.
- Tooling & Workpiece Protection: Prevents costly die damage and scrap by catching anomalies within the press stroke.
- Seamless TOX Ecosystem Integration: Native compatibility with TOX PRESSOTECHNIK press controllers and HMI platforms eliminates custom wiring overhead.
- Deterministic Response: Hardware-level reaction times ensure protection is not subject to PLC scan-cycle delays.
- Compact Panel-Mount Form Factor: Optimized for control cabinet integration with minimal DIN rail footprint.
- Configurable Monitoring Windows: Force thresholds and monitoring zones are programmable to match specific process requirements.
System Architecture & Signal Flow
The 0610520IF120243B operates as an interface module within the TOX PRESSOTECHNIK control hierarchy. Force transducer signals (load cell or piezoelectric) are routed through the IF module, which conditions and evaluates the signal against pre-configured force-time envelopes. On detection of an out-of-tolerance event, the module issues a digital stop signal to the press drive — independent of the host PLC — ensuring sub-millisecond protective response. Diagnostic data is simultaneously logged and made available to the supervisory control layer via the system bus.
Sourcing & Quality Verification
- OEM Origin: All units sourced directly from TOX PRESSOTECHNIK authorized distribution channels.
- Traceability: Full batch and serial traceability available upon request for regulated industries.
- Inspection: Units undergo incoming inspection at Konmask warehouse prior to dispatch.
- Packaging: Shipped in original OEM packaging with all factory documentation.
- Warranty: 12-month Konmask supply warranty against manufacturing defects.
Procurement Process
- Step 1 — Inquiry: Submit your RFQ via the product page or email [email protected] with quantity and delivery requirements.
- Step 2 — Quotation: Receive a formal quotation with lead time, pricing (HKD/USD), and shipping options within 1 business day.
- Step 3 — Order Confirmation: Confirm PO; payment via T/T, credit card, or approved net terms.
- Step 4 — Dispatch: Units shipped with tracking; DHL / FedEx / SF Express available for international orders.
- Step 5 — After-Sales: Technical support and warranty claims handled directly by Konmask engineering team.
Technical FAQ
Q: Is the 0610520IF120243B compatible with third-party press controllers?
A: The unit is optimized for TOX PRESSOTECHNIK platforms. Integration with third-party PLCs is possible via digital I/O but may require custom signal conditioning — contact our team for a compatibility assessment.
Q: What force transducer types are supported?
A: The module is designed for use with TOX-compatible load cells and piezoelectric sensors. Consult the TOX system documentation or contact Konmask for transducer pairing guidance.
Q: Can monitoring envelopes be modified in the field?
A: Yes. Force envelopes and monitoring windows are configurable via the TOX HMI or programming interface without hardware changes.
Q: What is the typical lead time?
A: In-stock units ship within 2–5 business days. For out-of-stock items, lead time is 4–8 weeks depending on factory availability.
Q: Do you provide a Certificate of Conformance (CoC)?
A: Yes. CoC and test reports are available upon request for all units.
