TRICONEX 8110 High Density Main Chassis | Tricon Triple Modular Redundant Safety Platform
Engineering Background
The TRICONEX 8110 is the foundational main chassis of the Tricon Safety System — Schneider Electric’s flagship Triple Modular Redundant (TMR) programmable safety controller. Designed to meet IEC 61508 SIL 3 and IEC 61511 requirements, the Tricon platform is the global benchmark for high-integrity process safety in oil & gas, petrochemical, nuclear, and power generation industries. The 8110 chassis provides the physical and electrical backbone for all Tricon I/O and communication modules, enabling fault-tolerant control with continuous self-diagnostics and zero-downtime operation.
Product Positioning
The 8110 High Density Main Chassis is engineered for applications where process uptime and personnel safety are non-negotiable. Its high-density slot configuration maximizes I/O capacity within a compact footprint, making it the preferred choice for brownfield expansions and greenfield SIS (Safety Instrumented System) projects alike. Procurement engineers specify the 8110 when system architecture demands maximum channel density, deterministic response, and proven field reliability across decades of continuous operation.
Complete Technical Specifications
- Part Number: 8110
- Platform: Tricon (Triple Modular Redundant — TMR)
- Chassis Type: High Density Main Chassis
- Architecture: TMR — three independent processing legs with voted outputs
- Safety Integrity Level: SIL 3 (IEC 61508 / IEC 61511)
- Module Slots: High-density configuration (supports full complement of Tricon I/O and communication modules)
- Backplane Bus: Tricon proprietary high-speed TMR backplane
- Power Input: Compatible with Tricon power supply modules (redundant power supported)
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Relative Humidity: 5% to 95% non-condensing
- Mounting: 19-inch rack mount
- Weight: Approx. 24.5 kg (chassis assembly)
- Certifications: TÜV, FM, CSA, CE, ATEX (zone 2 with appropriate enclosure)
- Communication: Compatible with Tricon communication modules (Modbus, HART, Profibus, OPC)
- Diagnostics: Continuous online self-test; fault isolation to single leg without process interruption
Proven Application Environments
- Oil & Gas: Emergency Shutdown Systems (ESD), High Integrity Pressure Protection Systems (HIPPS), Burner Management Systems (BMS)
- Petrochemical & Refining: Reactor safety interlocks, compressor protection, fired heater control
- Power Generation: Turbine protection, boiler safety, nuclear auxiliary systems
- Offshore Platforms: Fire & Gas detection integration, wellhead control
- Pipeline & Terminal: Overpressure protection, leak detection, custody transfer safety
- Chemical Processing: Batch reactor interlocks, toxic release prevention
Engineering Advantages
- True TMR Architecture: Three independent processing legs vote 2-out-of-3 (2oo3) on all outputs — no single point of failure can cause a spurious trip or dangerous failure
- Online Repair: Faulty modules can be replaced under power without process shutdown, maximizing plant availability
- High Density I/O: Maximizes channel count per rack unit, reducing panel footprint and installation cost
- Deterministic Scan Time: Guaranteed cycle time ensures predictable safety response within defined SIL 3 parameters
- Backward Compatibility: Integrates with existing Tricon installations, protecting prior capital investment
- Extensive Diagnostics: >99% diagnostic coverage — faults are detected, annunciated, and isolated before they can affect process safety
- Global Installed Base: Thousands of Tricon systems in continuous operation worldwide since the 1980s — unmatched field-proven reliability
System Architecture & Signal Flow
The 8110 chassis houses the Tricon Main Processor Modules (MPMs) across three redundant legs (Leg A, Leg B, Leg C). Each leg independently executes the safety application program and reads field I/O. The TMR voter compares outputs from all three legs and passes the 2oo3 majority vote to field actuators. The high-density backplane routes power, communications, and I/O signals between all installed modules with full electrical isolation between legs. The chassis also accommodates the Tricon Communication Module (TCM) for integration with DCS, SCADA, and historian systems via standard industrial protocols.
Sourcing & Quality Verification
- Source: Konmask.com sources TRICONEX 8110 units from authorized distributors, decommissioned plant inventories, and certified refurbishers with documented chain of custody
- Inspection: Each unit undergoes visual inspection, firmware version verification, and functional bench test prior to shipment
- Authenticity: All units are verified against Schneider Electric / TRICONEX part number databases; counterfeit screening is standard procedure
- Condition: New surplus, refurbished (tested), and used-serviceable grades available — condition stated explicitly on each listing
- Documentation: Test reports and inspection certificates available upon request for critical SIS applications
Procurement Process
- Step 1 — Inquiry: Contact Konmask.com with your required part number, quantity, required condition grade, and delivery timeline
- Step 2 — Quotation: Receive a formal quotation with unit price, lead time, and available stock confirmation within 24 hours
- Step 3 — Order Confirmation: Submit purchase order; payment terms available for qualified accounts
- Step 4 — Quality Check: Pre-shipment inspection completed; documentation package prepared
- Step 5 — Shipment: Secure anti-static packaging; export documentation for international orders; DHL / FedEx / freight forwarding available
- Step 6 — After-Sales: Technical support available post-delivery; warranty terms stated per condition grade
Technical FAQ
Q: Is the TRICONEX 8110 compatible with my existing Tricon system?
A: The 8110 is the standard main chassis for the Tricon platform. Compatibility depends on your system revision and firmware version. Contact our technical team with your system serial number for confirmation.
Q: Can the 8110 chassis be used in a SIL 3 application?
A: Yes. The Tricon platform including the 8110 chassis is TÜV-certified for use in SIL 3 Safety Instrumented Functions when installed and maintained per Schneider Electric’s functional safety manual.
Q: What is the lead time for the TRICONEX 8110?
A: Lead time varies by stock availability. In-stock units typically ship within 3–5 business days. Contact us for current availability.
Q: Do you provide a warranty?
A: Yes. Warranty terms are provided per condition grade. Refurbished and tested units carry a standard 12-month warranty against functional defects.
Q: Can you supply the full Tricon system or just the chassis?
A: Konmask.com can supply individual modules, complete chassis assemblies, and full Tricon system builds. Contact us with your BOM for a comprehensive quotation.
