Safety Instrumented System Solution – TRICONEX 3006 | Main Processor Module
Where This Product Is Used
The TRICONEX 3006 Main Processor Module is the computational core of the Tricon TMR (Triple Modular Redundancy) Safety System. It is deployed in mission-critical Safety Instrumented Systems (SIS) across the following industries and applications:
- Oil & Gas – Upstream: Wellhead control panels, emergency shutdown (ESD) systems, and high-integrity pressure protection systems (HIPPS) on production platforms and onshore facilities.
- Oil & Gas – Downstream / Refining: Burner management systems (BMS), compressor anti-surge control, and process shutdown logic in refineries and LNG terminals.
- Petrochemical & Chemical Plants: Reactor protection systems, toxic gas release prevention, and SIL 2/SIL 3 rated interlock loops in ethylene, ammonia, and methanol plants.
- Power Generation: Turbine overspeed protection, boiler safety shutdown, and nuclear auxiliary system interlocks.
- Pipeline & Transmission: Compressor station ESD, leak detection logic controllers, and SCADA-integrated safety layers.
- Offshore Platforms: Fire & gas (F&G) system integration, process shutdown (PSD), and emergency depressurization (EDP) logic.
Technical Specifications
| Part Number | 3006 |
| Manufacturer | TRICONEX (Schneider Electric) |
| Module Type | Main Processor Module (MP) |
| Compatible System | Tricon TMR Safety System (v9.x / v10.x chassis) |
| Architecture | Triple Modular Redundancy (TMR) – 2-out-of-3 voting |
| Safety Integrity Level | SIL 3 (IEC 61508 certified) |
| Processor | Dual 32-bit RISC processors per leg |
| Memory | Program and data RAM with battery-backed retention |
| Communication Ports | TriStation 1131 programming port; peer-to-peer Tribus network |
| Scan Time | Configurable; typical 50–250 ms depending on program size |
| Power Consumption | Refer to Tricon chassis power budget documentation |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Humidity | 5% to 95% non-condensing |
| Weight | Approx. 2.0 kg |
| Form Factor | Single-slot Tricon chassis module |
Why Engineers Specify This Model
- True TMR Architecture: Three independent processor legs execute logic simultaneously; a 2-of-3 voter ensures no single-point failure can cause a spurious trip or missed shutdown — critical for SIL 3 loop integrity.
- Online Repair Without Process Interruption: The 3006 supports hot-swap replacement of individual legs while the system remains in service, eliminating planned downtime for module maintenance.
- Deterministic Execution: Fixed-cycle scan execution guarantees response times within defined safety function windows, satisfying IEC 61511 proof-test and response-time requirements.
- Proven Field History: The Tricon platform has accumulated decades of operational hours in the most demanding SIS environments globally, with the 3006 being a cornerstone module of that installed base.
- TriStation 1131 Compatibility: Fully programmable via Schneider Electric’s TriStation 1131 engineering workstation using IEC 61131-3 function block and ladder logic, reducing engineering ramp-up time.
- Backward Compatibility: Interoperable with existing Tricon v9 and v10 chassis infrastructure, protecting capital investment in legacy safety system installations.
Complete System Bill of Materials
The TRICONEX 3006 operates within the Tricon TMR chassis ecosystem. A complete SIS node typically includes:
- 3006 – Main Processor Module (this item)
- 3008 – Communication Module (for TriStation and peer-to-peer links)
- 3700A / 3703E – Digital Input Modules (field device signal acquisition)
- 3805E – Digital Output Module (actuator drive)
- 3703E – Analog Input Module (4–20 mA process variable inputs)
- 3805E – Relay Output Module (hardwired ESD outputs)
- 3721 – Tricon Chassis (9-slot or 15-slot main chassis)
- 3001 – Power Supply Module (redundant pair recommended)
- 3625 – Remote I/O Module (for distributed field junction boxes)
Contact support@konmask.com for complete BOM quotations and system configuration support.
Compliance & Industry Standards
- IEC 61508: Functional Safety of E/E/PE Safety-related Systems – SIL 3 certified
- IEC 61511: Functional Safety for the Process Industry Sector
- IEC 61131-3: Programmable Controller Languages (TriStation 1131 compliant)
- ANSI/ISA-84: Safety Instrumented Systems for the Process Industry Sector
- ATEX / IECEx: Compatible with ATEX-rated field devices in Zone 1/Zone 2 installations (controller located in safe area)
- CE Marking: Compliant with applicable EU directives
- FM / UL: Refer to current Schneider Electric product certification documentation for applicable listings
Quality Assurance & Sourcing
Konmask.com specializes in industrial automation components for mission-critical applications. Every TRICONEX 3006 module offered through our platform is subject to the following sourcing and quality controls:
- Verified Origin: Modules are sourced from authorized distributors, decommissioned plant inventories, or certified refurbishment partners — provenance documented on request.
- Pre-Shipment Functional Check: Each unit undergoes bench-level power-on verification and visual inspection prior to dispatch.
- Firmware Version Disclosure: Firmware revision is confirmed and disclosed at time of quotation to ensure compatibility with your existing TriStation project.
- Packaging: ESD-safe anti-static bags, foam-lined cartons, and double-boxing for international freight.
- Documentation: Certificate of conformance and test report available upon request for regulated site installations.
How to Source This Part
- Request a Quote: Email support@konmask.com with your required quantity, delivery timeline, and site location.
- Urgent Requirement: Call or WhatsApp +0086 19859288691 for same-day response on critical spares.
- Bulk / Project Orders: We support EPC contractors and plant operators with project-quantity pricing, staged delivery, and vendor qualification documentation.
- Exchange Program: Core-exchange pricing available for repairable units — send your faulty 3006 and receive a tested replacement at reduced cost.
- Lead Time: Ex-stock units ship within 3–5 business days internationally. Contact us to confirm current availability.
Application-Specific FAQ
Q: Is the TRICONEX 3006 compatible with the Tricon v10 chassis?
A: Yes. The 3006 is designed for the Tricon TMR platform and is compatible with both v9 and v10 chassis configurations. Always verify firmware revision compatibility with your TriStation project version before installation.
Q: Can the 3006 be replaced online without shutting down the process?
A: Yes. The TMR architecture allows individual leg replacement while the remaining two legs maintain 2-of-3 voting and process control continuity. Follow Schneider Electric’s online repair procedures.
Q: What is the difference between the 3006 and the 3008 module?
A: The 3006 is the Main Processor Module responsible for executing the safety application logic. The 3008 is the Communication Module handling TriStation programming connections and peer-to-peer Tribus network links. Both are required in a standard Tricon node.
Q: Do you supply a warranty with refurbished units?
A: Yes. Konmask.com provides a 12-month functional warranty on all tested units. Warranty terms are provided in writing at time of sale.
Q: Can you supply the 3006 with a specific firmware version for our existing project?
A: We will confirm the firmware revision of available stock prior to shipment. If a specific version is required, please state this in your inquiry so we can match accordingly.
Q: Do you provide export documentation for international shipments?
A: Yes. We provide commercial invoice, packing list, certificate of origin, and can arrange CITES/export compliance documentation as required by destination country regulations.
