Triconex TCM 4355X – High-Integrity Communication Module | Tricon TMR Safety PLC Platform
Engineering Background: The Triconex TCM 4355X is a dedicated communication module engineered for the Tricon Triple Modular Redundancy (TMR) safety programmable logic controller platform — one of the most widely deployed safety systems in the global process industries. Developed by Triconex (a Schneider Electric brand), the TCM 4355X provides deterministic, fault-tolerant data exchange between the Tricon main chassis and external host systems, DCS networks, and SCADA infrastructure.
Product Positioning: Designed for SIL 3-capable safety instrumented systems (SIS), the TCM 4355X is the preferred communication interface for engineers who require certified, high-availability connectivity in oil & gas, petrochemical, nuclear, and power generation environments. Its TMR architecture ensures no single-point failure can interrupt communication integrity — a non-negotiable requirement in functional safety applications governed by IEC 61511 and IEC 61508.
Complete Technical Specifications
- Part Number / SKU: TCM 4355X
- Manufacturer: Triconex (Schneider Electric)
- Module Type: Communication Module (TCM)
- Platform Compatibility: Tricon TMR Safety PLC (v9.x / v10.x chassis)
- Architecture: Triple Modular Redundancy (TMR) — three independent processing paths with 2-out-of-3 voting
- Communication Protocol: TriStation 1131 protocol; supports Modbus TCP/IP, OPC, and peer-to-peer Tricon links
- Network Interface: Dual Ethernet ports (10/100 Mbps)
- Safety Integrity Level: SIL 3 capable (per IEC 61508 / IEC 61511)
- Operating Temperature: 0°C to +60°C (32°F to 140°F)
- Storage Temperature: -40°C to +85°C
- Relative Humidity: 5% to 95% non-condensing
- Power Consumption: Per Tricon chassis power budget (refer to system manual)
- Form Factor: Single-slot Tricon module card
- Weight: Approx. 500 g
- Certifications: TÜV-certified, FM approved, CE marked
- Country of Origin: United States
Proven Application Environments
- Oil & Gas: Upstream wellhead control, midstream pipeline ESD, downstream refinery SIS
- Petrochemical & Chemical: Reactor protection systems, burner management systems (BMS)
- Power Generation: Turbine protection, boiler safety shutdown, nuclear auxiliary systems
- LNG & Offshore: FPSO safety systems, LNG terminal ESD and F&G integration
- Pulp & Paper / Mining: High-availability process control with safety overlay
Engineering Advantages
- True TMR Redundancy: Three independent communication paths vote 2-out-of-3 — no single hardware failure disrupts data integrity or safety function
- Hot-Swap Capable: Module replacement without system shutdown, minimizing process downtime during maintenance windows
- Deterministic Latency: Guaranteed scan-cycle communication timing critical for SIS response time budgets
- Backward Compatibility: Integrates with legacy Tricon v9 and current v10 chassis without firmware re-engineering
- Dual-Port Ethernet: Supports redundant network topologies for SCADA and DCS host connectivity
- Diagnostics & Self-Test: Continuous online diagnostics with fault annunciation to TriStation 1131 engineering workstation
System Architecture & Signal Flow
The TCM 4355X occupies a dedicated communication slot in the Tricon main chassis backplane. Each of the three TMR legs independently processes communication requests; the on-board voter arbitrates responses before transmission to the host network. Inbound commands from SCADA/DCS are validated across all three legs before being passed to the Tricon application program. This architecture ensures that a single-leg hardware fault, firmware anomaly, or network transient cannot corrupt the safety application state or generate a spurious trip.
Typical signal flow: Host SCADA/DCS → Dual Ethernet → TCM 4355X (TMR voter) → Tricon backplane → Safety I/O modules → Field devices
Sourcing & Quality Verification
- Stock Condition: Genuine Triconex surplus / refurbished — fully tested prior to shipment
- Inspection Standard: Visual inspection, power-on functional test, firmware version verification
- Traceability: Serial number recorded; documentation available upon request
- Warranty: 12-month Konmask operational warranty against manufacturing defects
- Anti-Counterfeit: All units sourced through verified industrial surplus channels; counterfeit screening applied
Procurement Process
- Step 1: Submit RFQ via Konmask.com product page or email support@konmask.com with your required quantity and delivery timeline
- Step 2: Receive formal quotation with lead time, unit price (HKD/USD), and shipping options within 24 business hours
- Step 3: Confirm purchase order — T/T bank transfer, PayPal, or credit card accepted
- Step 4: Module ships with test report, packing list, and commercial invoice; DHL / FedEx express available worldwide
- Step 5: Post-delivery technical support available via email or WhatsApp (+86 198 5928 8691)
Technical FAQ
Q: Is the TCM 4355X compatible with Tricon v9 and v10 chassis?
A: Yes. The TCM 4355X is backward-compatible with Tricon v9.x chassis and fully supported in v10.x systems. Confirm firmware revision with your TriStation 1131 project before installation.
Q: Can this module be replaced online without a system shutdown?
A: Yes. The Tricon TMR architecture supports hot-swap module replacement. The remaining two legs maintain the safety function during replacement, subject to your site’s MOC (Management of Change) procedures.
Q: What communication protocols does the TCM 4355X support?
A: The module supports Modbus TCP/IP, OPC DA, and native Tricon peer-to-peer communication. Consult the Triconex Communication Guide for full protocol configuration details.
Q: Do you provide a test report with each unit?
A: Yes. Every TCM 4355X shipped from Konmask includes a functional test report. Additional FAT (Factory Acceptance Test) documentation can be arranged upon request.
Q: What is the lead time for the TCM 4355X?
A: Standard lead time is 3–7 business days for in-stock units. Express DHL/FedEx delivery to most global destinations within 5–10 business days after shipment.
