CNC & Robotics Automation Solution — Trio Motion Technology PicA2-V03A Y45-N1010-521 | PicA2 Series
Where This Product Is Used
The Trio Motion PicA2-V03A (Y45-N1010-521) is a compact, high-performance motion controller engineered for demanding multi-axis applications across industrial sectors:
- CNC Machining Centers — Coordinated 4-axis contouring for milling, turning, and grinding machines requiring sub-micron path accuracy.
- Cartesian & SCARA Robotics — High-speed pick-and-place, assembly, and dispensing cells where deterministic cycle times are critical.
- Packaging & Converting Machinery — Flying shear, registration control, and cam-profiled winding applications.
- Semiconductor & Electronics Manufacturing — Wafer handling, PCB drilling, and precision gantry positioning.
- Medical Device Assembly — Cleanroom-compatible motion sequences with full audit-trail logging.
- Textile & Printing Equipment — Synchronized multi-axis web tension and registration control.
Technical Specifications
| Part Number | PicA2-V03A |
| Manufacturer Part / Order Code | Y45-N1010-521 |
| Brand | Trio Motion Technology |
| Series | PicA2 |
| Controller Type | Multi-Axis Motion Controller |
| Axes Supported | Up to 4 axes (expandable via EtherCAT) |
| Communication Interfaces | EtherCAT, USB, Ethernet (TCP/IP) |
| Programming Language | TrioBASIC / IEC 61131-3 (Motion Perfect software) |
| Digital I/O | Onboard digital inputs/outputs (model-dependent) |
| Supply Voltage | 24 V DC |
| Operating Temperature | 0 °C to +50 °C |
| Mounting | DIN rail / panel mount |
| Enclosure Rating | IP20 |
| Weight | Approx. 100 g (controller module only) |
Why Engineers Specify This Model
- EtherCAT Real-Time Bus — Sub-millisecond cycle times enable tight synchronization across servo drives, I/O modules, and encoders without proprietary cabling.
- Compact Form Factor — DIN-rail footprint reduces panel space by up to 40% versus rack-based alternatives, ideal for machine-integrated cabinets.
- TrioBASIC + IEC 61131-3 Dual Programming — Engineers can write motion sequences in familiar BASIC syntax while integrating PLC ladder logic in the same project.
- Motion Perfect IDE — Oscilloscope, cam editor, and one-click firmware updates reduce commissioning time significantly.
- Scalable Architecture — Start with 4 axes; expand to 64+ axes via EtherCAT slaves without changing the controller hardware.
- Proven Reliability — Trio Motion Technology has 30+ years of field deployment across aerospace, automotive, and semiconductor OEMs globally.
Complete System Bill of Materials
For a fully operational motion control system based on the PicA2-V03A, engineers typically specify:
- Trio PicA2-V03A Y45-N1010-521 — Motion Controller (this unit)
- EtherCAT-compatible servo drives (e.g., Trio SD Series or third-party)
- Servo motors with encoder feedback (incremental or absolute)
- 24 V DC DIN-rail power supply (min. 5 A recommended)
- EtherCAT I/O expansion modules (digital/analog)
- USB Type-B or Ethernet cable for Motion Perfect PC connection
- DIN rail, terminal blocks, and cabinet wiring accessories
Contact support@konmask.com for a complete BOM quotation and compatibility check.
Compliance & Industry Standards
- CE Marking — Compliant with EU Machinery Directive and EMC Directive
- RoHS — Restriction of Hazardous Substances compliant
- IEC 61131-3 — Programming language standard for industrial controllers
- EtherCAT (IEC 61158) — Fieldbus communication standard
- UL/cUL — Listed for North American markets (verify with current datasheet)
Quality Assurance & Sourcing
Konmask.com sources the Trio PicA2-V03A Y45-N1010-521 exclusively through authorized distribution channels and verified industrial surplus networks. Every unit undergoes:
- Visual and dimensional inspection against OEM specifications
- Firmware version verification and functional power-on test
- Anti-static packaging with humidity indicator cards
- Serialized traceability documentation available on request
We do not sell counterfeit, refurbished-as-new, or unverified grey-market components.
How to Source This Part
- Add to Cart — Purchase directly online for in-stock units with same-day dispatch (order before 14:00 CST).
- Request a Quote — Email support@konmask.com for volume pricing, lead-time confirmation, or alternative part numbers.
- Technical Pre-Sales — Call +0086 198 5928 8691 for application compatibility review before ordering.
- Expedited Sourcing — If not currently in stock, our procurement team can locate and qualify units within 3–7 business days.
Application-Specific FAQ
Q: Is the PicA2-V03A compatible with third-party EtherCAT servo drives?
A: Yes. The PicA2-V03A supports any CoE (CANopen over EtherCAT) compliant drive. Trio provides pre-configured drive parameter files for major brands including Panasonic, Yaskawa, and Mitsubishi.
Q: What software is required to program this controller?
A: Trio Motion Perfect 4 (free download from Trio’s website). It runs on Windows 10/11 and connects via USB or Ethernet.
Q: Can this controller handle electronic gearing and cam profiles?
A: Yes. The PicA2 series natively supports electronic gearing, cam tables, and flying shear profiles via TrioBASIC commands and the built-in cam editor in Motion Perfect.
Q: What is the difference between PicA2-V03A and earlier PicA2 revisions?
A: The V03A hardware revision includes updated firmware support and improved EMC filtering. Always verify firmware compatibility with your Motion Perfect version before deployment.
Q: Do you provide a warranty?
A: Yes. Konmask.com provides a 90-day functional warranty on all verified units. Extended warranty options are available — contact us for details.
