Genuine Uniop MKDR-16-3545 - Industrial Automation Part

Uniop MKDR-16-3545 HMI Operator Panel | Industrial Man-Machine Interface

Send your required quantity, target delivery time, and destination country. Konmask will reply with availability and lead time.

SKU: MKDR-16-3545 Category: UniOP Tags: hmi, Man-Machine Interface, MKDR-16-3545, Operator Panel, UNIOP

Description

Uniop MKDR-16-3545 – Industrial HMI Operator Panel | MKDR Series Platform

Engineering Background: The Uniop MKDR-16-3545 is a ruggedized man-machine interface (HMI) operator panel engineered for demanding industrial automation environments. Designed within Uniop’s MKDR series, this unit delivers reliable real-time process visualization and operator control across a broad range of machine and plant applications. Uniop (a brand under Exor International) has decades of heritage in industrial HMI development, and the MKDR platform represents their commitment to robust, field-proven operator interface technology.

Product Positioning: The MKDR-16-3545 targets OEM machine builders, system integrators, and plant engineers who require a dependable, long-lifecycle HMI solution. It bridges the gap between operator and controller, enabling intuitive process monitoring, alarm management, and parameter adjustment without the complexity of PC-based solutions. Ideal as a direct replacement or upgrade in existing Uniop-equipped installations.

Complete Technical Specifications

Part Number / SKU: MKDR-16-3545
Manufacturer: Uniop (Exor International)
Series: MKDR
Product Type: HMI / Man-Machine Interface Operator Panel
Display Type: Backlit LCD / LED (model-specific; confirm datasheet)
Interface: Keypad-based operator input (membrane keys)
Communication Ports: Serial RS-232 / RS-485 (protocol-dependent configuration)
Power Supply: 24 VDC nominal (verify with official datasheet)
Operating Temperature: 0 °C to +50 °C
Storage Temperature: -20 °C to +70 °C
Protection Rating: IP65 front panel (typical MKDR series)
Mounting: Panel cut-out, flush mount
Weight: ~3.9 kg (shipping weight)
Certifications: CE (verify current listing)
Condition: New / Surplus New / Refurbished (specify at order)

Proven Application Environments

Machine Tool Control: CNC lathes, milling centers, and grinding machines requiring operator parameter input and status display at the machine front panel.
Packaging Machinery: Filling, sealing, and labeling lines where operators need real-time speed, count, and alarm feedback without a full SCADA terminal.
Plastics & Injection Molding: Cycle monitoring, temperature setpoint entry, and mold parameter management on injection molding machines.
Textile & Printing Equipment: Web tension control, color registration feedback, and production count display on high-speed printing and textile lines.
Food & Beverage Processing: Hygienic-area operator stations where a sealed front panel (IP65) is required for washdown environments.
HVAC & Building Automation: Local operator interface for chillers, air handling units, and BMS sub-controllers.
Water & Wastewater Treatment: Pump station local control panels requiring simple, reliable HMI without network dependency.

Engineering Advantages

Long Field Life: MKDR series panels are known for multi-decade operational reliability in harsh industrial environments, reducing unplanned downtime.
Direct Drop-In Replacement: Maintains physical and electrical compatibility with existing Uniop MKDR installations — no panel re-engineering required.
Simplified Commissioning: Uniop’s DesignerPro / NetDesigner software ecosystem enables rapid screen development and PLC driver configuration.
Wide PLC Compatibility: Native driver support for Siemens, Allen-Bradley, Mitsubishi, Omron, Modbus RTU/ASCII, and other major automation platforms.
Sealed Front Panel: IP65-rated front bezel protects against dust ingress and water spray — critical for food, chemical, and outdoor enclosure applications.
Low Total Cost of Ownership: Keypad-based interface eliminates touchscreen wear, reducing long-term maintenance costs in high-cycle applications.

System Architecture & Signal Flow

The MKDR-16-3545 operates as a serial HMI terminal connected to a host PLC or controller via RS-232 or RS-485. The operator panel polls the controller for data tags (registers, coils, status words) and renders them on the display as numeric values, bar graphs, or alarm messages. Operator keypad inputs are translated into write commands sent back to the controller — closing the man-machine control loop without requiring a separate PC or SCADA server. The panel stores screen projects in non-volatile memory, ensuring instant startup after power cycling.

Typical Signal Flow: PLC/Controller ↔ RS-232/RS-485 Serial Link ↔ MKDR-16-3545 HMI ↔ Operator Keypad & Display

Sourcing & Quality Verification

All units sourced through verified industrial surplus and authorized distribution channels.
Each unit undergoes visual inspection, label verification (part number, serial number, revision), and functional power-on check prior to shipment.
Original manufacturer packaging preserved where available; anti-static and foam-padded packaging used for all shipments.
Traceability documentation (purchase records, inspection reports) available upon request for regulated industries.
Konmask.com maintains a no-counterfeit policy — units failing authentication checks are quarantined and not listed for sale.

Procurement Process

Confirm Compatibility: Verify your existing Uniop project file version and PLC driver requirements match the MKDR-16-3545 firmware revision.
Request a Quote: Contact [email protected] or call +0086 19859288691 for current stock status, lead time, and volume pricing.
Place Order: Purchase directly via Konmask.com checkout or via proforma invoice for B2B/corporate procurement.
Inspection Window: 7-day incoming inspection period — notify us immediately if any discrepancy is found upon receipt.
Technical Support: Post-sale commissioning guidance available via email for verified purchasers.

Technical FAQ

Q: Is the MKDR-16-3545 compatible with Siemens S7-300/S7-400 PLCs?
A: Yes. Uniop MKDR panels support Siemens S7 MPI and Profibus DP drivers via the DesignerPro driver library. Confirm the specific driver version matches your firmware.

Q: Can I reuse my existing Uniop project file (.UPP) on this unit?
A: In most cases yes, provided the firmware revision is compatible. Contact us with your project file version for confirmation before ordering.

Q: What is the display resolution of the MKDR-16-3545?
A: The MKDR-16 series typically features a character-based or graphic LCD. Refer to the official Uniop MKDR-16-3545 datasheet for exact pixel resolution specifications.

Q: Do you provide a warranty?
A: Yes. Konmask.com offers a 90-day functional warranty on all tested units. Extended warranty options are available — contact us for details.

Q: Can you ship internationally?
A: Yes. We ship globally via DHL, FedEx, and UPS Express. Export documentation (commercial invoice, packing list, COO) provided for customs clearance.
