Machinery Protection Solution — VIBRO METER VM600 MPC4 | VM600 Series
Where This Product Is Used
The VIBRO METER VM600 MPC4 (P/N: 200-510-070-113) is a machinery protection card deployed in mission-critical rotating equipment monitoring systems across heavy industry. Typical installation environments include:
- Power Generation: Steam and gas turbine protection panels in utility-scale power plants, where continuous shaft vibration and position monitoring is mandatory per API 670.
- Oil & Gas: Compressor trains, centrifugal pumps, and expanders on upstream and midstream facilities requiring SIL-rated protection loops.
- Petrochemical & Refining: Reactor feed compressors and critical agitators where unplanned downtime carries six-figure-per-hour cost exposure.
- Marine & Offshore: Propulsion and auxiliary machinery protection on FPSOs and offshore platforms subject to DNV/ABS class requirements.
- Pulp, Paper & Steel: High-speed rolls, fans, and ID/FD fans where bearing failure prediction is integrated into DCS/SCADA architectures.
The MPC4 card slots into the VM600 rack chassis and interfaces directly with eddy-current proximity probes, velocity transducers, and accelerometers to deliver real-time protection trip outputs and 4–20 mA monitoring signals.
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | VIBRO METER (Meggitt) |
| Part Number | 200-510-070-113 |
| Model | VM600 MPC4 |
| Series | VM600 Machinery Protection System |
| Card Type | Machinery Protection Card (4-channel) |
| Input Channels | 4 (configurable per channel) |
| Measurement Types | Vibration (displacement, velocity, acceleration), position, speed |
| Output | Relay trip outputs + 4–20 mA analog monitoring |
| Communication | Rack backplane bus; optional Modbus/Profibus via gateway |
| Power Supply | Via VM600 rack backplane (24 VDC nominal) |
| Operating Temperature | 0 °C to +60 °C |
| Humidity | 5–95% RH, non-condensing |
| Approvals | CE, cULus; SIL 2 capable (system-level) |
| Form Factor | VM600 standard card — single-slot |
| Weight | ~100 g (card only) |
Specifications are based on published VIBRO METER documentation. Confirm exact revision details against your system’s configuration record before installation.
Why Engineers Specify This Model
- API 670 Compliance by Design: The VM600 platform is engineered to meet the machinery protection standard most widely enforced by EPC contractors and end-user machinery specifications globally.
- 4-Channel Density: The MPC4 provides four independently configurable protection channels per card slot, maximising rack utilisation and reducing panel footprint versus single-channel alternatives.
- Flexible Transducer Compatibility: Accepts eddy-current probes (Bently Nevada-compatible), velocity sensors, and IEPE accelerometers without external signal conditioning, simplifying BOM and wiring.
- Deterministic Trip Response: Hardware-based trip logic ensures sub-millisecond relay response independent of software scan cycles — a critical requirement for high-speed machinery protection.
- Proven Field Reliability: The VM600 series has accumulated decades of installed-base hours in tier-1 power and O&G facilities, with documented MTBF exceeding 100,000 hours.
- Seamless System Expansion: Cards are hot-swappable within a powered VM600 rack (with appropriate rack configuration), supporting maintenance without process shutdown.
Complete System Bill of Materials
The MPC4 card operates as part of a complete VM600 machinery protection system. A typical BOM for a 4-channel protection loop includes:
- VM600 Rack Chassis (e.g., RPS6U or equivalent) — power supply and backplane
- VM600 MPC4 Card (200-510-070-113) — this item
- VM600 IOC4T or IOC4 I/O Card — terminal block interface for field wiring
- Eddy-current proximity probe system (probe + extension cable + driver, e.g., VM600-compatible or Bently 3300 series)
- Keyphasor® probe (1× per shaft, for speed and phase reference)
- VM600 RMC (Rack Monitoring Card) — optional, for Modbus/Ethernet gateway
- DIN rail terminal blocks and shielded instrumentation cable (per site specification)
Contact support@konmask.com for complete system quotations or to source companion cards and accessories.
Compliance & Industry Standards
- API 670 — Machinery Protection Systems (5th Edition): The VM600 platform is designed to satisfy the protection, monitoring, and alarm/trip requirements defined in this standard for critical and essential machinery.
- IEC 61511 / IEC 61508: SIL 2 capable at system level when configured per VIBRO METER’s functional safety documentation.
- CE Marking: Compliant with applicable EU directives for industrial control equipment.
- cULus Listed: Recognised for use in North American industrial installations.
- ISO 10816 / ISO 20816: Measurement methodology compatible with vibration severity evaluation per these standards.
Quality Assurance & Sourcing
Konmask.com specialises in the procurement of genuine, traceable industrial automation and machinery protection components. Our sourcing process for the VM600 MPC4 includes:
- Authenticity Verification: Each unit is inspected against manufacturer labelling, firmware revision markings, and physical construction benchmarks prior to dispatch.
- Functional Pre-check: Where test infrastructure permits, cards are bench-verified for power-up integrity and communication response before shipment.
- Traceability Documentation: Country of origin, batch/lot references, and inspection records are retained and available on request.
- Packaging: Anti-static ESD packaging with desiccant, consistent with IPC/JEDEC J-STD-033 handling guidelines for sensitive electronics.
- Warranty: 12-month warranty against manufacturing defects. Contact us for extended coverage options on multi-unit orders.
How to Source This Part
- Add to Cart directly on this page for standard single-unit orders.
- Request a Quote for volume orders (3+ units), project BOM packages, or expedited delivery requirements — email support@konmask.com with your project timeline and quantity.
- Provide Your P/N Confirmation: Always reference part number 200-510-070-113 and your VM600 rack revision when ordering to ensure hardware compatibility.
- Lead Time: In-stock units ship within 2 business days. Out-of-stock units are sourced to order — typical lead time 7–21 business days depending on global availability.
- Export & Customs: We handle export documentation for international shipments. ECCN classification and HS code available on request for customs pre-clearance.
Application-Specific FAQ
Q: Is the VM600 MPC4 (200-510-070-113) compatible with Bently Nevada 3500 series probes?
A: The MPC4 accepts eddy-current probe drivers with standard output characteristics (−24 VDC bias, −200 mV/mil or −7.87 V/mm scale factor). Many Bently Nevada 3300/3500-compatible probes are electrically compatible, but always verify the driver output specification against the VM600 input range before installation.
Q: Can this card be used as a drop-in replacement for an older VM600 MPC4 revision?
A: The VM600 platform maintains backward hardware compatibility across most card revisions within the same rack generation. Confirm the firmware revision and rack backplane version with your system documentation or contact us for a compatibility assessment.
Q: Do you supply the matching IOC4T I/O card?
A: Yes. Contact support@konmask.com with your full BOM and we will quote companion cards, cables, and rack accessories as a package.
Q: Is this product available for export to the EU, Middle East, or Southeast Asia?
A: Yes. We ship internationally with full export documentation. Duties and import taxes are the buyer’s responsibility unless a DDP (Delivered Duty Paid) arrangement is agreed in writing.
Q: What is the return policy if the card does not match our system?
A: Unused, unopened units may be returned within 14 days of receipt. Please contact support before returning any item to obtain an RMA number and return instructions.
