Machinery Protection Solution — VIBRO METER VM600 CPU-M | VM600 Series
The VIBRO METER VM600 CPU-M (Part No. 200-595-064-114) is the central processing unit card of the VM600 modular machinery protection and condition monitoring rack system. Designed for continuous, safety-critical monitoring of rotating machinery in power generation, oil & gas, petrochemical, and heavy industrial environments, this CPU card orchestrates all data acquisition, alarm management, and communication functions within the VM600 chassis.
Where This Product Is Used
The VM600 CPU-M is deployed wherever rotating machinery must be continuously monitored to API 670 or equivalent safety standards:
- Power Generation — Steam turbines, gas turbines, and hydro generators at utility and industrial power plants requiring 24/7 vibration and position monitoring with trip-level protection.
- Oil & Gas Upstream & Midstream — Compressor trains, centrifugal pumps, and expanders on offshore platforms and onshore processing facilities where unplanned downtime carries extreme cost and safety risk.
- Petrochemical & Refining — Critical rotating equipment in ethylene crackers, reformers, and LNG liquefaction trains where continuous overspeed and radial vibration protection is mandatory.
- Pulp & Paper / Steel Mills — Large induced-draft fans, ID/FD fans, and rolling mill drives requiring real-time bearing condition data.
- Marine Propulsion — Shaft monitoring systems on vessels where VIBRO METER VM600 racks are integrated into the vessel management system.
- OEM Machine Builders — Turbomachinery OEMs embedding VM600 racks as the standard protection platform shipped with new equipment.
Technical Specifications
- Part Number: 200-595-064-114
- Module Designation: CPU-M
- Platform: VIBRO METER VM600 Rack System
- Form Factor: Single-slot Eurocard module (VM600 chassis compatible)
- Primary Function: Central processing, system coordination, alarm/trip logic, and communication gateway for the VM600 rack
- Communication Interfaces: Ethernet (Modbus TCP / OPC), serial RS-232/RS-485 (Modbus RTU), and rack backplane bus
- Supported I/O Modules: Compatible with all VM600 series I/O cards (AMC8, MPC4, RPS6, IOC4T, etc.)
- Operating Temperature: 0 °C to +60 °C
- Storage Temperature: −40 °C to +85 °C
- Power Supply: Supplied via VM600 rack backplane (24 VDC nominal)
- Weight: Approx. 500 g
- Certifications: CE marked; designed to meet API 670 4th Edition machinery protection requirements
Note: Full electrical specifications are available in the VIBRO METER VM600 CPU-M datasheet. Contact Konmask for documentation.
Why Engineers Specify This Model
- Centralised Intelligence — The CPU-M acts as the single point of control for the entire VM600 rack, eliminating the need for external PLCs to manage alarm logic and reducing system complexity.
- Deterministic Real-Time Processing — Dedicated real-time OS ensures alarm and trip outputs are generated within defined latency windows, critical for API 670 compliance.
- Dual Redundancy Support — Supports hot-standby CPU redundancy configurations, enabling continuous protection even during CPU module replacement or failure.
- Open Communication — Native Modbus TCP and OPC connectivity allows direct integration with DCS (DeltaV, Ovation, ABB 800xA) and SCADA platforms without additional gateways.
- Non-Intrusive Configuration — System parameters can be updated via the VM600 software suite without interrupting live monitoring — essential for brownfield retrofits.
- Long Product Lifecycle — VM600 platform has been in continuous service for 20+ years; spare CPU-M cards are essential for long-term asset management strategies.
Complete System Bill of Materials
A typical VM600 machinery protection rack for a single turbine train includes:
- VM600 Rack Chassis (6-slot or 12-slot)
- VM600 CPU-M (200-595-064-114) — This module
- VM600 RPS6 Rack Power Supply (200-595-xxx) — Redundant pair recommended
- VM600 AMC8 Analogue Monitoring Card — For vibration/position channel inputs
- VM600 MPC4 Machinery Protection Card — For trip relay outputs
- VM600 IOC4T I/O Conditioner — For 4–20 mA retransmission outputs
- Proximity probes / velocity sensors / accelerometers (Meggitt/VIBRO METER compatible)
- Junction boxes and field cabling per API 670 installation guidelines
Konmask can source complete VM600 rack assemblies or individual replacement modules. Contact us for a full BOM quotation.
Compliance & Industry Standards
- API 670 — Machinery Protection Systems (4th Edition): The VM600 platform is designed to meet the requirements for continuous vibration, position, and speed monitoring of critical rotating equipment.
- IEC 61508 — Functional Safety of E/E/PE Safety-related Systems: Applicable to safety instrumented function implementations using VM600.
- CE Marking — Compliant with applicable EU directives for industrial electronic equipment.
- ISO 10816 / ISO 20816 — Mechanical vibration evaluation standards referenced in alarm setpoint configuration.
- ATEX / IECEx — The VM600 rack is installed in safe areas; field sensors connected to the system may carry ATEX certification for hazardous area use.
Quality Assurance & Sourcing
Konmask sources VM600 CPU-M modules through verified industrial supply channels. Every unit offered is subject to the following quality process:
- Visual Inspection — Board-level inspection for physical damage, corrosion, and component integrity.
- Functional Verification — Where test equipment is available, modules are powered and communication interfaces are verified prior to shipment.
- Traceability — Serial number and firmware revision recorded at time of dispatch.
- Packaging — ESD-safe anti-static bags, foam-lined cartons, and moisture-barrier packaging for international shipment.
- Warranty — 90-day return-to-base warranty against defects in materials and workmanship (see full terms at Konmask.com).
Konmask is an independent distributor and is not an authorised VIBRO METER / Meggitt dealer. All trademarks remain the property of their respective owners.
How to Source This Part
- Confirm Part Number — Verify 200-595-064-114 against your VM600 rack documentation or existing module label.
- Check Firmware Compatibility — Note the firmware revision of your existing CPU-M if replacing a failed unit; contact Konmask to match revision.
- Request a Quote — Email support@konmask.com or call +0086 19859288691 with your required quantity and delivery timeline.
- Lead Time — Ex-stock units typically ship within 3–5 business days. For urgent requirements, expedited air freight is available.
- Payment & Export — We support T/T bank transfer, and can provide commercial invoice, packing list, and certificate of origin for customs clearance.
Application-Specific FAQ
Q: Can the VM600 CPU-M be replaced while the rack is powered and monitoring is active?
A: In a redundant CPU configuration, the standby CPU-M can be swapped without interrupting protection. In a single-CPU configuration, the rack must be taken offline during replacement — coordinate with your operations team for a planned outage window.
Q: What software is required to configure the CPU-M after replacement?
A: VIBRO METER’s VM600 configuration software (typically supplied with the original system) is required to upload the rack configuration file to the new CPU-M. Konmask can advise on software version compatibility.
Q: Is the 200-595-064-114 compatible with all VM600 chassis generations?
A: The CPU-M is designed for the standard VM600 rack backplane. Compatibility with specific chassis revisions should be confirmed against the VIBRO METER compatibility matrix — contact Konmask for guidance.
Q: Can Konmask supply a tested spare for long-term storage?
A: Yes. We recommend purchasing a tested spare CPU-M for critical machinery trains. We can supply with full inspection report and ESD-safe long-term storage packaging.
Q: What is the typical failure mode of the VM600 CPU-M?
A: Common failure indicators include loss of Ethernet communication, rack configuration errors on startup, and watchdog resets. If your rack is displaying CPU fault alarms, contact Konmask for a replacement unit before the primary fails completely.
