VIBRO METER VM600 CPU M 200-595-041-113 — Central Processing Card | VM600 Machinery Protection Platform
Engineering Background
The VIBRO METER VM600 platform is a modular, rack-based machinery protection and condition monitoring system widely deployed in rotating equipment applications — including gas turbines, steam turbines, compressors, and large pumps. Developed by Meggitt (formerly Vibro-Meter SA), the VM600 architecture separates signal conditioning, processing, and communication functions across dedicated card slots, enabling high-channel-density monitoring with deterministic response times compliant with API 670 and IEC 61511 safety requirements.
Product Positioning
The CPU M (P/N 200-595-041-113) is the central processing unit card of the VM600 rack. It governs real-time data acquisition from all installed I/O and signal-conditioning cards, executes protection logic, manages rack-level communication (Modbus, Profibus, or proprietary VM600 bus depending on firmware), and interfaces with the host SCADA or DCS. Procurement engineers replacing a failed CPU M or commissioning a redundant rack will find this card is the single most critical active component in the VM600 chassis.
Complete Technical Specifications
| Manufacturer | VIBRO METER (Meggitt SA) |
| Part Number | 200-595-041-113 |
| Model / Card Type | VM600 CPU M — Central Processing Module |
| Platform | VM600 Machinery Protection & Condition Monitoring Rack System |
| Form Factor | Single-slot Eurocard (3U VME-compatible rack card) |
| Processor Architecture | Dedicated real-time DSP / embedded processor (VM600 proprietary) |
| Communication Interfaces | VM600 internal rack bus; RS-485 / Modbus RTU; optional Profibus DP (firmware-dependent) |
| Operating Voltage | Supplied via VM600 rack backplane (±15 VDC, +5 VDC) |
| Operating Temperature | 0 °C to +60 °C (storage: −25 °C to +70 °C) |
| Humidity | 5 % to 95 % RH, non-condensing |
| Protection Class | IP20 (installed in VM600 rack enclosure) |
| Certifications | CE; designed to API 670 4th/5th Edition; SIL-capable architecture |
| Weight | Approx. 500 g |
| Condition Available | New / Refurbished / Tested surplus (specify at inquiry) |
| SKU | VM600 CPU M 200-595-041-113 |
Proven Application Environments
- Gas & Steam Turbine Protection — real-time overspeed, vibration, and axial displacement monitoring per API 670
- Centrifugal & Reciprocating Compressors — continuous bearing vibration and process parameter surveillance
- Large Rotating Machinery (Pumps, Fans, Gearboxes) — condition monitoring integrated with plant DCS
- Offshore & Onshore Oil & Gas Platforms — SIL-rated protection loops requiring deterministic CPU response
- Power Generation Plants — turbine supervisory instrumentation (TSI) rack upgrades and replacements
- Petrochemical & Refinery Units — continuous operation environments with high MTBF requirements
Engineering Advantages
- Deterministic Real-Time Processing — dedicated CPU architecture ensures sub-millisecond protection response, critical for API 670 trip logic
- Modular Hot-Swap Architecture — card-level replacement without full rack shutdown minimizes plant downtime
- Multi-Protocol Communication — native Modbus RTU and optional Profibus DP simplify integration with existing SCADA/DCS infrastructure
- Backward Compatibility — compatible with existing VM600 rack chassis, I/O cards, and MPC4/RPS6 power supply modules
- Long Service Life — industrial-grade components rated for continuous 24/7 operation in harsh environments
- Centralized Rack Intelligence — single CPU M manages all channel cards, reducing wiring complexity and single-point failure risk
System Architecture & Signal Flow
Within the VM600 rack, the CPU M occupies the designated CPU slot (typically slot 1 or as specified by the rack configuration). Signal flow proceeds as follows:
- Sensor Input — Accelerometers, proximity probes, and process transmitters connect to dedicated I/O cards (e.g., AMC8, IOC4T, RLC16)
- Signal Conditioning — Analog front-end cards perform filtering, integration, and RMS/peak computation
- CPU M Processing — The CPU M polls all card slots via the VM600 internal bus, executes protection logic (alarm/danger thresholds), and generates relay outputs
- Communication Output — Processed data and status are transmitted to the host DCS/SCADA via Modbus RTU or Profibus DP
- Relay & Trip Output — Hardware relay cards execute machine trip or alarm actions based on CPU M logic decisions
Sourcing & Quality Verification
- All VM600 CPU M cards are sourced from OEM-authorized channels, certified distributors, or verified surplus inventories
- Each unit undergoes functional bench testing prior to shipment: power-on self-test (POST), bus communication verification, and firmware version confirmation
- Units are shipped in ESD-safe packaging with anti-static bags and foam inserts to prevent transit damage
- Traceability documentation (test report, serial number record, condition certificate) provided upon request
- Firmware version and hardware revision confirmed and disclosed at time of order confirmation
Procurement Process
- Submit Inquiry — Contact us with your required quantity, acceptable condition (new/refurbished/tested), and target delivery date
- Stock Confirmation & Quote — We confirm available stock, firmware revision, and provide a formal quotation within 1 business day
- Order Confirmation — Purchase order accepted; payment terms agreed (T/T, L/C, or platform checkout)
- Pre-Shipment Inspection — Functional test performed; test report and photos shared for customer approval
- Shipment & Tracking — Shipped via DHL / FedEx / UPS Express with full tracking; export documentation (commercial invoice, packing list, COO) included
- After-Sales Support — 12-month warranty on tested units; technical support available for installation and commissioning queries
Technical FAQ
Q: Is the VM600 CPU M 200-595-041-113 compatible with all VM600 rack chassis generations?
A: Yes, the CPU M is designed for backward and forward compatibility within the VM600 platform. Confirm your rack chassis revision with our technical team if you are integrating with a legacy installation.
Q: Can the CPU M be replaced without shutting down the entire rack?
A: In redundant CPU configurations, hot-swap replacement is supported. In single-CPU racks, a brief rack restart is required. Consult your VM600 system manual for the specific procedure.
Q: What firmware version is supplied?
A: Firmware version is confirmed at order time. We can supply units with specific firmware versions upon request, subject to availability.
Q: Do you provide a test report?
A: Yes. A functional test report including POST results, bus communication check, and firmware version is provided with every unit upon request.
Q: What is the lead time?
A: In-stock units ship within 2–5 business days. For sourced units, lead time is typically 2–4 weeks. Contact us for current availability.
Q: Can you supply multiple units for a rack expansion or spare parts program?
A: Yes. Volume pricing is available for orders of 2+ units. Contact support@konmask.com for a bulk quotation.
