WESTINGHOUSE 1X00188H01 Analog Output Module | Replacement, Equivalent & Selection Guide
The WESTINGHOUSE 1X00188H01 is an industrial-grade Analog Output Module designed for use in Westinghouse/Ovation distributed control systems (DCS). This page provides full technical specifications, compatible replacement options, equivalent models from alternative manufacturers, and a practical selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 1X00188H01 |
| Manufacturer | Westinghouse / Emerson (Ovation) |
| Module Type | Analog Output Module |
| Output Channels | Typically 4–8 channels (verify with system documentation) |
| Output Signal | 4–20 mA / 0–10 V (configurable) |
| Communication | DCS backplane bus |
| Power Supply | 24 VDC (system-supplied) |
| Weight | 600 g |
| Operating Temperature | 0°C to 60°C |
| Mounting | DIN rail / rack-mount (system chassis) |
| Certifications | CE, UL (verify current listing) |
Note: Always cross-reference with the official Westinghouse/Ovation system manual for your specific firmware and chassis revision.
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as functional replacements or equivalents for the 1X00188H01. Compatibility depends on your specific DCS revision, firmware version, and I/O configuration — always validate before deployment.
- 1X00188H02 / H03 – Later hardware revisions of the same module; typically drop-in compatible
- 5X00119G01 – Ovation analog output module used in similar rack configurations
- 1C31227G01 / G02 – Ovation I/O analog output, compatible in select Ovation controller generations
- Emerson Ovation AO Module (current generation) – Consult Emerson for direct cross-reference
- Third-party equivalents – Contact Konmask.com for vetted alternative sourcing options
⚠ Important: Substituting modules in a live DCS environment requires engineering review. Do not replace without verifying firmware compatibility and I/O mapping.
Why Choose the Original Model
- Guaranteed system compatibility – Designed and validated for Westinghouse/Ovation DCS architectures
- Stable signal integrity – Factory-calibrated analog output for precision process control
- Reduced integration risk – No firmware re-mapping or I/O reconfiguration required
- Long field service record – Proven reliability in power generation, petrochemical, and utilities sectors
- OEM traceability – Full documentation and part history available for regulated industries
Typical Applications
- Power plant DCS control loops (boiler, turbine, feedwater systems)
- Petrochemical and refinery process automation
- Water and wastewater treatment control systems
- Pulp and paper manufacturing automation
- Steel and metals processing lines
- Any Ovation-based DCS requiring analog output I/O expansion or module replacement
System Compatibility
- Platform: Westinghouse Ovation DCS (Emerson)
- Compatible Controllers: Ovation OCR400, OCR1100, and related controller families (verify by system revision)
- I/O Chassis: Standard Ovation I/O rack / remote I/O enclosures
- Software: Ovation Developer Studio (ODS) — module must be configured in the I/O database
- Firmware: Confirm firmware version compatibility with your site’s Ovation release
Selection Guide
Use the following criteria to determine whether the 1X00188H01 or an alternative is the right choice for your application:
- Step 1 – Confirm your DCS platform: Verify you are running a Westinghouse/Ovation system. This module is not compatible with ABB, Siemens, or Honeywell DCS platforms.
- Step 2 – Check hardware revision: Identify the H-revision (H01, H02, etc.) required by your chassis and firmware. Later revisions may offer enhanced diagnostics.
- Step 3 – Verify channel count & signal type: Confirm the number of analog output channels and whether 4–20 mA or voltage output is required.
- Step 4 – Assess lead time vs. risk: If the original part is unavailable, evaluate tested equivalents. Contact Konmask.com for availability and cross-reference support.
- Step 5 – Spare parts strategy: For critical systems, maintain at least one cold-standby spare on-site to minimize unplanned downtime.
Quality Assurance & Sourcing
- All modules sourced through Konmask.com undergo visual inspection and functional verification prior to shipment
- Original OEM packaging preserved where available; condition clearly stated (New / Refurbished / Tested Used)
- Traceability documentation provided upon request for regulated industries
- Anti-static packaging and secure export carton as standard
- Global shipping with DHL / FedEx / UPS — export documentation included
How to Order
- Online: Add to cart directly from this page
- Email: support@konmask.com — include part number, quantity, and required condition
- Phone / WhatsApp: +0086 19859288691
- Bulk / Project orders: Request a formal quotation via email for volume pricing and lead time confirmation
- Lead time: In-stock items ship within 1–3 business days; sourced items typically 5–15 business days
Replacement & Compatibility FAQ
Q: Can I use a 1X00188H02 in place of the 1X00188H01?
A: In most cases yes — later H-revisions are backward compatible — but always confirm with your Ovation system documentation or contact Emerson support.
Q: Is this module compatible with non-Ovation DCS platforms?
A: No. The 1X00188H01 is designed exclusively for the Westinghouse/Ovation DCS backplane and is not interchangeable with other manufacturers’ systems.
Q: Do you supply refurbished units?
A: Yes. Refurbished units are fully tested and clearly labeled. Contact us for condition details and pricing.
Q: Can Konmask.com help identify the correct replacement if my part number is unclear?
A: Absolutely. Send us your system nameplate data, chassis model, and current module label — we will cross-reference and recommend the correct part.
Q: What warranty is provided?
A: All units carry a minimum 90-day warranty against defects. Extended warranty options available — inquire at time of order.
