Westinghouse 5X00167G01 – Digital Output Module | WDPF Distributed Control System
Engineering Background: The Westinghouse 5X00167G01 is a digital output (DO) I/O module designed for the Westinghouse WDPF (Westinghouse Distributed Processing Family) distributed control system platform — one of the most widely deployed DCS architectures in power generation, petrochemical, and heavy industrial facilities worldwide. WDPF systems remain operational across hundreds of critical infrastructure sites, making reliable spare-part sourcing a strategic priority for plant engineers and maintenance teams.
Product Positioning: The 5X00167G01 serves as a field-interface card responsible for converting controller-level digital commands into discrete output signals that drive actuators, relays, solenoids, and other field devices. It is a direct-fit replacement for aging WDPF installations requiring like-for-like hardware without system reconfiguration or software changes.
Complete Technical Specifications
- Part Number / SKU: 5X00167G01
- Manufacturer: Westinghouse Electric Corporation (now Emerson / Ovation legacy)
- Module Type: Digital Output (DO) I/O Module
- Platform: WDPF (Westinghouse Distributed Processing Family) DCS
- Output Type: Discrete digital output signals
- Form Factor: Standard WDPF card cage plug-in module
- Signal Interface: Compatible with WDPF field termination assemblies (FTAs)
- Power Supply: Supplied via WDPF card cage backplane
- Operating Temperature: 0°C to 60°C (typical industrial DCS range)
- Weight: Approx. 100 g
- Condition: Surplus / Refurbished — tested and verified
Proven Application Environments
- Coal-fired and gas-fired power generation plants running legacy WDPF DCS
- Nuclear auxiliary systems with Westinghouse WDPF control architecture
- Petrochemical and refinery process control loops
- Pulp and paper mill automation systems
- Water treatment and municipal utility SCADA/DCS hybrid installations
- Steel and metals processing facilities with long-lifecycle DCS deployments
Engineering Advantages
- Drop-in Replacement: Direct hardware substitute — no firmware changes, no re-engineering required for WDPF card cage installations.
- Lifecycle Extension: Extends operational life of WDPF DCS infrastructure without costly platform migration projects.
- Verified Surplus Stock: Each unit undergoes functional inspection and bench testing prior to shipment.
- Fast Availability: In-stock surplus units ship within 1–3 business days, minimizing unplanned downtime exposure.
- Traceability: Full documentation package available on request (test records, photos, condition report).
System Architecture & Signal Flow
Within the WDPF architecture, the 5X00167G01 resides in the I/O subsystem tier. The DCS controller node issues digital command words over the WDPF data highway; the DO module decodes these commands and drives corresponding output channels to the field termination assembly (FTA). The FTA then interfaces with field wiring connected to actuators, motor starters, solenoid valves, or alarm annunciators. This modular signal-flow design allows individual I/O cards to be replaced without disrupting adjacent channels or controller logic.
Sourcing & Quality Verification
- All units sourced from decommissioned plant inventories or authorized surplus channels.
- Visual inspection: PCB integrity, connector condition, component seating.
- Functional bench test performed prior to listing.
- Anti-static packaging with moisture barrier for safe international shipping.
- Certificate of conformance and test report available upon request.
- 30-day return policy for DOA (Dead on Arrival) units.
Procurement Process
- Confirm Part Number: Verify 5X00167G01 against your WDPF system BOM or existing card label.
- Request Quote: Contact us at support@konmask.com or +0086 19859288691 for volume pricing or expedited shipping options.
- Place Order: Secure checkout via Konmask.com — accepts T/T wire transfer, credit card, and PayPal.
- Receive & Install: Unit ships with inspection report. Install into WDPF card cage per OEM slot assignment.
Technical FAQ
Q: Is the 5X00167G01 compatible with all WDPF card cage revisions?
A: The module is designed for standard WDPF card cage backplanes. Confirm your cage revision with Westinghouse/Emerson documentation or contact our engineers for compatibility verification.
Q: Can this module be used in Ovation DCS systems?
A: No. The 5X00167G01 is specific to the WDPF platform. Ovation uses a different I/O architecture and card form factor.
Q: Do you provide a warranty?
A: Yes — 30-day DOA warranty with full replacement. Extended warranty options available for volume orders.
Q: What is the lead time for out-of-stock units?
A: Typical sourcing lead time is 2–6 weeks for units not in current inventory. Contact us to join the availability notification list.
Q: Can you provide a datasheet or OEM manual?
A: We can provide available technical documentation upon request. Contact support@konmask.com.
