Whitlock PN:000505 3.6V PLC Battery Module | Replacement, Equivalent & Selection Guide
The Whitlock PN:000505 is a 3.6V lithium battery module designed to maintain RAM data retention and real-time clock (RTC) backup power in PLC control systems. This page provides full technical specifications, compatible replacement options, equivalent models, and a structured selection guide to help engineers and procurement teams make informed sourcing decisions.
Technical Specifications
- Part Number: PN:000505
- Manufacturer: Whitlock
- Nominal Voltage: 3.6V DC
- Battery Chemistry: Lithium (Li-SOCl₂ or equivalent)
- Application: PLC RAM backup / RTC power retention
- Form Factor: Module (plug-in or integrated)
- Weight: ~1,900 g (packaged)
- Country of Origin: China
- HS Code: 850760
- Operating Temperature: -20°C to +60°C (typical for industrial lithium cells)
- Shelf Life: Up to 10 years (sealed, unused)
Compatible Replacement & Equivalent Models
The following models are commonly used as direct or functional replacements for the Whitlock PN:000505 in PLC backup battery applications. Always verify voltage, connector type, and capacity before substitution.
- ER14250 / ER14250H — 3.6V 1/2 AA lithium thionyl chloride cell (universal)
- Tadiran TL-5902 — 3.6V 1/2 AA, direct pin-compatible in many Whitlock modules
- SAFT LS14250 — 3.6V lithium, widely used in Schneider, Siemens, and Mitsubishi PLCs
- Panasonic BR-2/3A — 3V lithium, verify compatibility before use
- Omron CJ1W-BAT01 — 3.6V PLC battery module (cross-reference for CJ/CS series)
- Siemens 6ES7971-0BA00 — 3.6V backup battery module (verify connector)
Note: Konmask.com recommends using OEM or certified-equivalent parts. Contact us for cross-reference verification.
Why Choose the Original Whitlock PN:000505
- OEM Guaranteed Compatibility: Designed and tested specifically for Whitlock PLC platforms — zero integration risk.
- Certified Quality: Meets industrial-grade standards for temperature stability and discharge consistency.
- Data Integrity: Ensures uninterrupted RAM retention and RTC accuracy during power outages.
- Warranty Support: OEM parts maintain system warranty validity; third-party substitutes may void coverage.
- Long Service Life: Engineered for extended standby periods common in industrial automation environments.
Typical Applications
- PLC RAM data backup (program and parameter retention during power loss)
- Real-time clock (RTC) maintenance in automation controllers
- SCADA and DCS auxiliary backup power
- CNC machine tool controller battery replacement
- Industrial robot controller memory backup
- Building automation and energy management systems
System Compatibility
The Whitlock PN:000505 is primarily designed for Whitlock-branded PLC systems. Functional equivalents may be compatible with the following platforms — always confirm with your system documentation:
- Siemens S7-200 / S7-300 / S7-400 series
- Mitsubishi FX / Q / iQ-R series
- Omron CJ / CS / CP series
- Schneider Electric Modicon M340 / Premium
- Allen-Bradley MicroLogix / CompactLogix (verify connector)
- Beckhoff CX series embedded controllers
Selection Guide
Use the following criteria to select the correct battery module for your application:
- Step 1 — Confirm Voltage: Verify your PLC requires 3.6V (not 3.0V or 3.7V). Check the controller’s battery compartment label or manual.
- Step 2 — Check Connector Type: Whitlock modules use a proprietary connector. Confirm pin pitch and polarity before ordering a replacement.
- Step 3 — Assess Capacity Needs: Estimate backup duration required. Higher mAh = longer retention. Standard ER14250 = ~1,200 mAh.
- Step 4 — Verify Operating Environment: For high-temperature environments (>55°C), select high-temp rated lithium cells.
- Step 5 — OEM vs. Equivalent: For warranty-critical systems, use OEM PN:000505. For cost-sensitive maintenance, certified equivalents are acceptable.
Quality Assurance & Sourcing
All Whitlock PN:000505 modules and compatible equivalents sold through Konmask.com are:
- Sourced directly from authorized distributors or verified OEM channels
- Inspected for voltage output, packaging integrity, and date code validity
- Stored in climate-controlled warehouses to preserve shelf life
- Shipped with anti-static and moisture-barrier packaging
- Backed by Konmask’s quality guarantee and return policy
How to Order
- Online: Add to cart directly on this page — stock available for immediate dispatch.
- Bulk / B2B Inquiry: Email support@konmask.com for volume pricing and lead time.
- Phone / WhatsApp: +0086 19859288691
- Custom Sourcing: Can’t find your exact part? Contact us — we specialize in hard-to-find PLC components.
Replacement & Compatibility FAQ
Q: Can I use a standard ER14250 cell to replace the Whitlock PN:000505?
A: In many cases yes, if the voltage (3.6V) and connector match. However, the OEM module includes a PCB and connector assembly — a bare cell may not be a drop-in replacement without modification.
Q: How often should I replace the PLC backup battery?
A: Typically every 3–5 years, or when the PLC displays a low-battery alarm. Do not wait for complete discharge, as this risks program loss.
Q: Is the PN:000505 rechargeable?
A: No. Lithium thionyl chloride (Li-SOCl₂) cells are primary (non-rechargeable). Replace with a new unit when depleted.
Q: What happens if the PLC battery dies?
A: The PLC will lose its program, parameters, and RTC data upon the next power cycle. Always replace proactively.
Q: Does Konmask ship internationally?
A: Yes. We ship worldwide with DHL, FedEx, and EMS. Contact us for shipping rates to your region.
