GE IC697ALG320 Analog Output Module | Replacement, Equivalent & Selection Guide
The GE IC697ALG320 is a high-performance Analog Output Module designed for the GE Series 90-70 PLC platform. Whether you are maintaining an existing control system, sourcing a direct replacement, or evaluating equivalent alternatives, this guide provides the technical depth and selection clarity that industrial engineers and procurement teams require. Konmask.com specializes in verified, in-stock automation components — helping you minimize downtime and make confident sourcing decisions.
Technical Specifications
- Manufacturer: General Electric (GE Automation / GE Fanuc)
- Part Number: IC697ALG320
- Module Type: Analog Output Module
- Compatible Platform: GE Series 90-70 PLC
- Output Channels: 8 channels (voltage and current selectable)
- Output Range (Voltage): 0 to +10 VDC / ±10 VDC
- Output Range (Current): 4–20 mA
- Resolution: 12-bit
- Isolation: Optically isolated outputs
- Power Consumption: Supplied via Series 90-70 backplane
- Operating Temperature: 0°C to 60°C
- Weight: 840 g
- Form Factor: Single-slot Series 90-70 rack module
- Compliance: CE, UL listed
Compatible Replacement & Equivalent Models
When the IC697ALG320 is unavailable or end-of-life, the following models may serve as functional replacements depending on your system configuration. Always verify compatibility with your specific rack, CPU, and software revision before substitution.
- IC697ALG321 — Enhanced version with expanded channel configuration options; direct form-fit-function replacement in most Series 90-70 applications
- IC697ALG322 — Higher-density analog output variant; requires configuration verification
- IC697ALG440 — Combined analog I/O module; suitable when input capability is also needed
- Emerson (GE Vernova) PACSystems RX7i Analog Output Modules — Next-generation platform replacement for full system migrations
- Third-party equivalents — Contact Konmask.com for cross-reference assistance; we verify pin-compatibility and firmware support before recommendation
⚠️ Note: Replacement modules must be validated against your Series 90-70 CPU firmware version and I/O configuration software (Proficy Machine Edition or equivalent).
Why Choose the Original IC697ALG320
- Proven field reliability — Deployed in thousands of industrial installations worldwide across power, oil & gas, and manufacturing sectors
- Native platform integration — Zero configuration risk; plug-and-play within existing Series 90-70 racks
- Exact firmware compatibility — No driver updates or software patches required for legacy systems
- Predictable signal performance — 12-bit resolution with stable output across full operating temperature range
- Regulatory continuity — Maintains existing CE/UL compliance documentation for audited facilities
- Lower total cost of ownership — Avoids re-engineering, re-validation, and retraining costs associated with platform migration
Typical Applications
- Process control loops (flow, pressure, temperature, level setpoint output)
- Variable speed drive (VSD/VFD) speed reference signals
- Valve positioner control (4–20 mA current loop)
- Proportional control of pneumatic actuators
- SCADA and DCS integration via analog signal conditioning
- Power generation plant control systems
- Water and wastewater treatment automation
- Chemical and petrochemical process control
- Automotive assembly line control
- Food and beverage production line management
System Compatibility
- Compatible Racks: IC697CHS750, IC697CHS782, IC697CHS790 (Series 90-70 5/9/16-slot racks)
- Compatible CPUs: IC697CPU731, IC697CPU771, IC697CPU781, IC697CPU782, IC697CPU788, IC697CPU789
- Programming Software: Proficy Machine Edition (Logic Developer PLC), GE Logicmaster 90-70
- Power Supplies: IC697PWR710, IC697PWR711, IC697PWR724, IC697PWR748
- Bus Controllers: Compatible with Genius Bus Controller (IC697BEM713) and Ethernet modules
- Not compatible with: Series 90-30, Series 90-20, or PACSystems RX3i racks (different backplane architecture)
Selection Guide
Use the following decision framework to determine whether the IC697ALG320 or an alternative is the right choice for your application:
- Existing Series 90-70 system, like-for-like replacement needed → IC697ALG320 (original) — recommended for zero-risk swap
- Need more output channels in same slot → Evaluate IC697ALG322 or IC697ALG440
- System migration to modern platform planned → Consider PACSystems RX7i with Emerson migration tools
- Budget-constrained, refurbished acceptable → Konmask.com offers tested refurbished IC697ALG320 units with 90-day warranty
- Uncertain about compatibility → Contact our engineering team with your CPU part number and rack configuration for a free compatibility check
Quality Assurance & Sourcing
- All IC697ALG320 units sourced through verified industrial distributors and OEM-authorized channels
- Pre-shipment functional testing: power-on, channel output verification, and communication handshake test
- Visual inspection: PCB condition, connector integrity, label authenticity
- Serialization check against known counterfeit databases
- Secure anti-static packaging with humidity indicators for international shipment
- Certificate of conformance available upon request
- 90-day warranty on all units; extended warranty available for volume orders
How to Order
- Add to Cart — Select quantity and proceed to checkout directly on this page
- Request a Quote — For volume orders (5+ units), email support@konmask.com for preferential pricing
- Provide System Details — Share your CPU part number and rack configuration for compatibility pre-verification (optional but recommended)
- Payment — Secure checkout via credit card, wire transfer (T/T), or PayPal; LC accepted for large orders
- Shipping — DHL / FedEx / UPS express worldwide; EXW Xiamen or CIF available; typical lead time 1–3 business days for in-stock units
- Documentation — Commercial invoice, packing list, and certificate of conformance included; FORM E / CO available for applicable trade zones
Replacement & Compatibility FAQ
Q: Can I use IC697ALG321 as a direct drop-in replacement for IC697ALG320?
A: In most Series 90-70 configurations, yes. The IC697ALG321 is the enhanced successor with backward-compatible I/O mapping. However, verify your Proficy Machine Edition configuration file does not reference IC697ALG320-specific parameters.
Q: Is the IC697ALG320 still in production?
A: GE Fanuc (now Emerson / GE Vernova) has transitioned the Series 90-70 platform to end-of-life status. Konmask.com maintains stock of new-surplus and refurbished units to support legacy system maintenance.
Q: Can I mix IC697ALG320 with IC697ALG321 in the same rack?
A: Yes, Series 90-70 racks support mixed analog output modules. Each slot is independently configured in the I/O configuration table.
Q: What is the difference between voltage and current output modes?
A: The IC697ALG320 supports both ±10 VDC voltage output and 4–20 mA current output, selectable per channel via jumper or software configuration. Current output (4–20 mA) is preferred for long cable runs due to noise immunity.
Q: Do you provide a warranty on replacement units?
A: Yes. All units carry a 90-day functional warranty. Extended 12-month warranty available for volume purchases. Contact us for details.
Q: Can Konmask.com help with full system migration away from Series 90-70?
A: Yes. We provide cross-reference consulting and can source PACSystems RX7i equivalents. Contact our engineering team for a migration assessment.
