SURUGA SEIKI KXL06075V-C2-S40 VIF-AA1C1 – High-Precision Linear Ball Guide | KXL Series Stage Platform
Engineering Background: SURUGA SEIKI (駿河精機) is a Japanese precision instrument manufacturer with decades of expertise in optical stages, motion control, and positioning systems. The KXL series represents their high-load, compact linear ball guide platform engineered for demanding laboratory, semiconductor, and industrial automation environments where sub-micron repeatability is non-negotiable.
Product Positioning: The KXL06075V-C2-S40 with VIF-AA1C1 interface and part number 0100-09366 is a motorized-ready linear ball guide stage designed for integration into multi-axis systems. Its C2-grade ball screw and 75 mm travel make it ideal for precision alignment, inspection, and micro-positioning tasks where rigidity and low backlash are critical procurement criteria.
Complete Technical Specifications
- Manufacturer: SURUGA SEIKI Co., Ltd. (Japan)
- Model / SKU: KXL06075V-C2-S40
- Interface Adapter: VIF-AA1C1 / PB30-2
- Part Number: 0100-09366
- Series: KXL — Compact Linear Ball Guide Stage
- Travel Range: 75 mm
- Ball Screw Grade: C2 (JIS standard, high-precision class)
- Drive Type: Ball screw, motorized-ready (S40 motor mount)
- Stage Width: 60 mm (KXL06 platform)
- Guide Type: Linear ball guide (recirculating ball)
- Mounting Interface: VIF-AA1C1 — compatible with standard stepper/servo motor adapters
- Country of Origin: Japan
- Weight: Approx. 2.6 kg
- HS Code: 8482.10.10
Proven Application Environments
- Optical alignment and beam steering in laser systems
- Semiconductor wafer inspection and probe station integration
- Microscopy and imaging stage automation
- PCB assembly and SMT pick-and-place sub-systems
- Industrial metrology and CMM auxiliary axes
- Photonics packaging and fiber alignment rigs
- Multi-axis gantry and XYZ stage configurations
Engineering Advantages
- C2-Grade Ball Screw: Delivers ≤0.006 mm/300 mm lead error — critical for closed-loop positioning accuracy
- Recirculating Ball Guide: Low friction, high rigidity, and long service life under continuous duty cycles
- VIF-AA1C1 Motor Interface: Direct coupling to SURUGA SEIKI and third-party stepper/servo motors without custom machining
- Compact 60 mm Platform: Space-efficient footprint for benchtop and rack-mounted systems
- Japanese Manufacturing Precision: 100% factory-inspected with traceable dimensional certification
- Modular Architecture: Stackable with KXL/KXG/KXR series for XY, XYZ, and rotary configurations
System Architecture & Signal Flow
The KXL06075V-C2-S40 integrates into motion control architectures as follows:
- Motor Input: S40 mount accepts NEMA 17 / SURUGA SEIKI standard stepper or servo motors via VIF-AA1C1 adapter
- Drive Transmission: C2 ball screw converts rotary motor torque to linear displacement with minimal backlash
- Position Feedback: Compatible with external linear encoders for closed-loop servo control
- Controller Interface: Works with standard pulse/direction (P&D) and analog velocity controllers — compatible with SURUGA SEIKI SC controllers, Parker, Aerotech, and generic motion controllers
- Limit Switches: Mechanical end-of-travel limits; optional home sensor mounting provisions
Sourcing & Quality Verification
- All units sourced directly from authorized SURUGA SEIKI distribution channels or verified OEM surplus
- Each unit inspected for: smooth travel, backlash within spec, motor mount integrity, and surface condition
- Original part number 0100-09366 verified against SURUGA SEIKI official catalog
- Packaging: anti-static foam, moisture barrier bag, and rigid outer carton for international transit
- Traceability documentation available upon request for regulated industries (semiconductor, medical device)
Procurement Process
- Step 1: Confirm part number KXL06075V-C2-S40 / VIF-AA1C1 / 0100-09366 matches your BOM
- Step 2: Contact us for real-time stock confirmation and lead time: support@konmask.com
- Step 3: Submit PO with shipping address — we support DDP, DAP, EXW Incoterms
- Step 4: Receive unit with inspection report and packing list within agreed lead time
- Payment: T/T, PayPal, credit card accepted; net terms available for qualified accounts
Technical FAQ
Q: Is the VIF-AA1C1 adapter included with the stage?
A: Yes — the VIF-AA1C1/PB30-2 motor interface adapter is included as part of the complete assembly (P/N 0100-09366).
Q: What motors are compatible with the S40 mount?
A: The S40 mount is designed for SURUGA SEIKI standard motors and is also compatible with NEMA 17 frame stepper motors using the VIF-AA1C1 adapter. Verify shaft diameter (typically 5 mm) before ordering.
Q: Can this stage be used in a vertical (Z-axis) orientation?
A: Yes, with appropriate counterbalance or brake motor. The C2 ball screw provides sufficient holding torque when paired with a stepper motor with holding current enabled.
Q: What is the maximum load capacity?
A: The KXL06 platform is rated for up to 5 kg horizontal load. Consult SURUGA SEIKI load-moment diagrams for vertical and cantilevered configurations.
Q: Is a calibration certificate available?
A: Factory calibration data is available for new units. For surplus/refurbished stock, we can arrange third-party metrology verification upon request.
