WOODWARD 5441-413 – Relay Interface Module | Governor & Turbine Control Platform
Engineering Background
WOODWARD is a globally recognized leader in energy control solutions, with over a century of engineering heritage in governor systems, turbine controls, and power management. The 5441-413 Relay Interface Module is purpose-engineered for integration within WOODWARD’s modular governor control architecture, providing reliable discrete I/O relay switching in demanding industrial environments where signal integrity and system uptime are non-negotiable.
Product Positioning
The 5441-413 serves as a critical bridge between the governor controller and field-level actuators, solenoids, and alarm circuits. It is specified by control engineers in power generation, oil & gas, and marine propulsion applications where deterministic relay response and robust isolation are required. This module is a direct-fit replacement and expansion component for WOODWARD governor control panels.
Complete Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 5441-413 |
| Manufacturer | WOODWARD |
| Module Type | Relay Interface Module |
| Platform Compatibility | WOODWARD Governor Control Systems |
| Output Type | Discrete relay outputs |
| Isolation | Galvanic isolation between control and field circuits |
| Operating Temperature | -40°C to +70°C (industrial grade) |
| Mounting | DIN rail / panel-mount (system-specific) |
| Weight | 300 g (approx.) |
| Condition Available | New, Refurbished, Tested Surplus |
Note: Full datasheet available upon request. Contact Konmask for OEM documentation.
Proven Application Environments
- Gas Turbine Power Plants — Relay interface for fuel valve solenoids, trip circuits, and alarm annunciators in WOODWARD governor-controlled turbines.
- Steam Turbine Control Panels — Discrete output switching for steam admission valves and overspeed protection relay logic.
- Diesel Generator Sets — Integration with genset governor panels for start/stop relay sequencing and load-sharing signal conditioning.
- Marine Propulsion Systems — Relay I/O for bridge control and engine room governor panels on vessels requiring DNV or ABS compliance.
- Oil & Gas Compression Stations — Compressor driver governor control with relay outputs to ESD (Emergency Shutdown) systems.
- Industrial Cogeneration (CHP) — Relay interface between WOODWARD controllers and utility interconnect protection relays.
Engineering Advantages
- Direct OEM Compatibility — Designed and manufactured by WOODWARD; plug-and-play replacement within existing 5441-series control panels with no firmware modification required.
- Galvanic Isolation — Protects the governor controller backplane from field-side voltage transients, ground loops, and inductive kickback from relay coils.
- Deterministic Switching — Relay response time is consistent and predictable, critical for trip and protection logic where millisecond-level timing affects turbine safety.
- Wide Temperature Range — Rated for harsh industrial environments including outdoor substations and unheated machinery spaces.
- Modular Architecture — Slots into WOODWARD’s modular governor chassis, enabling hot-swap maintenance and incremental I/O expansion without system shutdown.
- Long Service Life — Industrial-grade relay contacts rated for high cycle counts, reducing maintenance intervals in continuous-duty applications.
System Architecture & Signal Flow
In a typical WOODWARD governor control system, the 5441-413 Relay Interface Module occupies a dedicated I/O slot within the governor chassis. The signal flow is as follows:
- Controller Command — The governor CPU issues a discrete output command via the internal backplane bus.
- Relay Interface Module — The 5441-413 receives the logic-level signal and energizes the corresponding relay coil, providing galvanic isolation.
- Field Output — The relay dry contact closes, switching the field-side circuit (solenoid valve, alarm horn, trip relay, or indicator lamp).
- Feedback / Status — Relay status may be monitored by the governor controller for diagnostics and fault annunciation.
This architecture ensures that field-side faults (short circuits, ground faults) do not propagate to the governor controller logic, maintaining system integrity during fault conditions.
Sourcing & Quality Verification
- Authorized & Verified Supply Chain — Konmask sources WOODWARD modules through vetted industrial distributors and OEM-authorized channels. Each unit is traceable to its supply origin.
- Incoming Inspection — All units undergo visual inspection, label verification (part number, revision, date code), and functional continuity checks prior to listing.
- Anti-Counterfeit Measures — We verify OEM markings, PCB revision codes, and component authenticity. Suspected non-genuine units are quarantined and not sold.
- Condition Grading — Units are graded as New (sealed OEM), Refurbished (tested and reconditioned), or Tested Surplus (pulled from service, fully tested). Grade is disclosed at time of quotation.
- Documentation — OEM datasheet, test reports, and certificate of conformance available upon request for critical applications.
Procurement Process
- Submit RFQ — Contact Konmask via email or phone with your part number (5441-413), required quantity, and preferred condition grade.
- Quotation — Receive a formal quotation with unit price, lead time, and available stock within 1 business day.
- Order Confirmation — Approve the quotation and submit a purchase order. Payment terms available for qualified accounts.
- Quality Check & Dispatch — Each unit is inspected and packed to IEC 60068 transport standards before shipment.
- Delivery & Support — Worldwide shipping with tracking. Post-delivery technical support available from Konmask’s engineering team.
Technical FAQ
Q: Is the WOODWARD 5441-413 compatible with all WOODWARD governor systems?
A: The 5441-413 is designed for specific WOODWARD governor control platforms. Please provide your governor model number when requesting a quote so our team can confirm compatibility.
Q: Can this module be used as a direct replacement for a failed unit in the field?
A: Yes. As an OEM part, the 5441-413 is a direct replacement. No firmware changes are required. Ensure the governor chassis is de-energized before module swap per WOODWARD maintenance procedures.
Q: Do you supply the full WOODWARD 5441-series module range?
A: Konmask maintains stock and sourcing capability across the WOODWARD 5441-series. Contact us with your specific part numbers for availability.
Q: What is the lead time for the 5441-413?
A: Lead time depends on stock availability and condition grade. In-stock units ship within 3–5 business days. Out-of-stock items are sourced within 2–4 weeks typically.
Q: Can you provide a certificate of conformance or test report?
A: Yes. Documentation packages including CoC, incoming inspection reports, and OEM datasheets are available for critical plant and marine applications upon request.
Q: What warranty is provided?
A: Konmask provides a 90-day functional warranty on all tested and refurbished units. New OEM-sealed units carry the standard WOODWARD warranty terms.
