Turbine & Engine Governor Solution — WOODWARD 5466-316 | Governor MPU & I/O Module
Where This Product Is Used
The WOODWARD 5466-316 Governor MPU & I/O Module is a critical control component deployed across demanding industrial environments where precise speed sensing and I/O signal management are non-negotiable. Typical application sites include:
- Gas & Steam Turbine Power Plants — Speed pickup and governor feedback loops for turbine overspeed protection and load control.
- Diesel & Gas Engine Generator Sets — Engine speed sensing (MPU) integrated with discrete I/O for start/stop sequencing, fuel control, and fault annunciation.
- Compressor Stations — Pipeline compressor driver control where governor stability and fast I/O response are essential for process safety.
- Marine Propulsion Systems — Shipboard engine governor systems requiring robust MPU signal conditioning in high-vibration environments.
- Industrial Cogeneration (CHP) Plants — Combined heat and power installations demanding synchronized governor control across multiple prime movers.
- Oil & Gas Upstream / Midstream — Wellhead and gathering station engine-driven equipment where WOODWARD governor systems are the OEM standard.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 5466-316 |
| Manufacturer | WOODWARD |
| Module Type | Governor MPU & I/O Module |
| Function | Magnetic Pickup Unit (MPU) speed sensing + discrete I/O interface |
| Compatible Governor Systems | WOODWARD 505, 505E, 723, MicroNet, NetCon series (verify with BOM) |
| Signal Input | Magnetic Pickup (MPU) speed signal |
| I/O Interface | Discrete digital I/O channels |
| Weight | 860 g |
| SKU / Part No. | 5466-316 |
| Condition | New / Refurbished (specify at inquiry) |
Note: For full electrical ratings, I/O channel count, and firmware compatibility, refer to WOODWARD Technical Manual 26247 or contact Konmask technical support.
Why Engineers Specify This Model
- Integrated MPU + I/O in a single module — Reduces panel wiring complexity and eliminates the need for separate signal conditioners.
- WOODWARD OEM pedigree — Designed and validated to interface natively with WOODWARD governor controllers; no third-party compatibility risk.
- High-noise immunity — MPU signal conditioning is engineered for industrial environments with strong electromagnetic interference from generators and motors.
- Proven field reliability — Deployed in thousands of turbine and engine installations globally; long MTBF track record in continuous-duty service.
- Drop-in replacement — Direct form-fit-function replacement for existing 5466-316 installations; no re-engineering required.
- Supports overspeed protection logic — Critical for compliance with API 670 and turbine safety standards.
Complete System Bill of Materials
The 5466-316 is typically specified alongside the following WOODWARD components for a complete governor control system:
- WOODWARD 505 / 505E Digital Governor Controller
- WOODWARD 723 Analog Governor Controller
- WOODWARD MicroNet TMR / Plus Controller
- WOODWARD Magnetic Pickup (MPU) Sensor — 8923-032 or equivalent
- WOODWARD Actuator / EG Series Actuator
- WOODWARD Power Supply Module (as applicable to chassis)
- WOODWARD I/O Expansion Modules (for larger I/O counts)
- Terminal blocks, shielded MPU cable, and DIN rail hardware
Contact [email protected] for complete BOM sourcing and cross-reference assistance.
Compliance & Industry Standards
- API 670 — Machinery Protection Systems (overspeed detection compatibility)
- IEC 61511 — Functional Safety for Process Industry (SIL-rated system integration)
- ISO 8528 — Generator set control and performance standards
- CE Marking — European conformity for industrial control equipment (verify with WOODWARD datasheet)
- RoHS — Restriction of Hazardous Substances compliance
- ATEX / IECEx — Consult WOODWARD for hazardous area classification requirements
Quality Assurance & Sourcing
Konmask.com sources WOODWARD 5466-316 modules through verified industrial supply channels. Our quality process includes:
- Authenticity verification — Each unit is inspected against WOODWARD OEM labeling, part number, and date code standards.
- Functional pre-shipment check — Available on request for refurbished units; includes power-on and I/O continuity verification.
- Secure anti-static packaging — ESD-safe packaging with moisture barrier for international shipment.
- Traceability documentation — Certificate of conformance and sourcing records available for regulated industries.
- Warranty — 90-day replacement warranty on all stocked units; extended warranty available on request.
How to Source This Part
- Confirm your part number — Verify 5466-316 against your existing module label or WOODWARD system documentation.
- Check compatibility — Confirm governor controller model (505, 723, MicroNet, etc.) and firmware revision with your engineering team.
- Request a quote — Email [email protected] or call +0086 19859288691 with your quantity and required delivery date.
- Place your order — Add to cart directly or request a formal proforma invoice for procurement departments.
- Receive & install — Typical lead time: 3–7 business days for stocked units. Express shipping available.
Application-Specific FAQ
Q: Is the 5466-316 compatible with the WOODWARD 505E Digital Governor?
A: The 5466-316 is designed for WOODWARD governor systems. Compatibility with the 505E depends on the specific chassis revision and I/O slot assignment. Contact our technical team with your 505E serial number for confirmation.
Q: Can this module be used as a direct replacement for a failed unit without reconfiguration?
A: In most cases, yes — the 5466-316 is a form-fit-function replacement. However, if the governor controller has been updated to a newer firmware revision, a parameter download may be required. Consult WOODWARD Technical Manual 26247.
Q: Do you supply the MPU sensor separately?
A: Yes. Konmask stocks compatible WOODWARD MPU sensors. Contact us with your engine/turbine tooth wheel specifications for the correct MPU part number.
Q: What is the lead time for this module?
A: Stocked units typically ship within 3–7 business days. For urgent requirements, contact us directly for expedited options.
Q: Can you provide a Certificate of Conformance for regulated plant maintenance?
A: Yes. CoC documentation is available upon request for all units sourced through Konmask.com.
