Yaskawa JARCR-XOI01 XRC Extended I/O Board | Replacement, Equivalent & Selection Guide
The Yaskawa JARCR-XOI01 is an Extended I/O Board designed for Yaskawa XRC and DX200 robot controller systems, including the MA1400 welding robot series. This board expands the digital I/O capacity of the controller, enabling integration with external PLCs, sensors, and automation peripherals in demanding industrial environments. At Konmask.com, we specialize in sourcing, cross-referencing, and supplying this component with full traceability.
Technical Specifications
- Part Number: JARCR-XOI01
- Manufacturer: Yaskawa Electric Corporation
- Series: XRC / DX200 Controller Board Series
- Function: Extended Digital I/O Expansion Board
- Compatible Controllers: XRC, DX200
- Compatible Robot Models: MA1400, MA1900, EA1400N and related arc welding robots
- Related Servo Drive: SGMPH-01ANA-YR13
- Related Board: JANCD-YSF21-E (Safety Board)
- I/O Type: Digital Input / Output Expansion
- Form Factor: PCB Board Module
- Country of Origin: Japan
- Weight: ~800 g
- Condition Available: New, Refurbished, Tested Used
Compatible Replacement & Equivalent Models
When the JARCR-XOI01 is unavailable or discontinued, the following models may serve as functional equivalents or replacements depending on your controller revision. Always verify firmware and connector compatibility before substitution.
- JARCR-XOI02 – Revised I/O board for later XRC revisions; pin-compatible in most configurations
- JANCD-XIO01 – DX100/DX200 series I/O expansion; verify backplane slot compatibility
- JANCD-XIO02 – Extended I/O for DX200 with enhanced channel count
- Third-party I/O Expansion Modules – Must match Yaskawa MECHATROLINK-II or DeviceNet protocol if used externally
Note: Konmask.com can assist with cross-reference verification. Contact us before ordering a substitute.
Why Choose the Original JARCR-XOI01
- ✅ Guaranteed Compatibility: Factory-designed for XRC and DX200 backplane architecture
- ✅ Firmware Integrity: No re-flashing or parameter reconfiguration required
- ✅ Signal Fidelity: Maintains original I/O timing and noise immunity specs
- ✅ Warranty Compliance: Preserves OEM warranty on the controller system
- ✅ Reduced Downtime: Plug-and-play replacement with no software changes
Typical Applications
- Arc welding robot cells (MA1400 / MA1900 series)
- Automotive body-in-white welding lines
- Multi-robot coordinated welding systems
- PLC-to-robot I/O interfacing via XRC controller
- Safety interlock and peripheral device integration
- Retrofit and maintenance of legacy XRC-based robot systems
System Compatibility
| Controller | Robot Series | Compatibility |
|---|---|---|
| XRC | MA1400, MA1900, EA1400N | ✅ Direct Fit |
| DX200 | MA1400, MA2010, VA1400 | ✅ Confirmed Compatible |
| DX100 | MA1400 (early) | ⚠️ Verify Slot & Firmware |
| NX100 | Legacy Models | ❌ Not Compatible |
Selection Guide
Use the following criteria to confirm the correct I/O board for your system:
- Step 1 – Identify Controller Model: Check the controller nameplate for XRC or DX200 designation
- Step 2 – Count Existing I/O Slots: Determine how many I/O expansion slots are occupied
- Step 3 – Check Backplane Revision: XRC Rev. A–D boards may have different connector pinouts
- Step 4 – Confirm I/O Channel Requirements: Standard vs. extended I/O count needed for your application
- Step 5 – Verify with Konmask: Send your controller serial number and we will confirm the correct part
Quality Assurance & Sourcing
- All JARCR-XOI01 units sourced by Konmask.com undergo visual inspection and functional verification
- New units are supplied in original Yaskawa packaging with full traceability documentation
- Refurbished units are tested to OEM electrical specifications and include a 90-day warranty
- Certificates of conformance and test reports available upon request
- Anti-static packaging and secure export carton for international shipment
How to Order
- Add the JARCR-XOI01 to your cart on this page
- For bulk orders or custom sourcing, email support@konmask.com
- Provide your controller model and serial number for compatibility confirmation
- Lead time: In-stock units ship within 2–5 business days; sourced units 7–21 days
- International shipping available with DHL, FedEx, and UPS Express options
Replacement & Compatibility FAQ
Q: Can JARCR-XOI01 be used in a DX200 controller?
A: Yes. The JARCR-XOI01 is compatible with DX200 controllers used with MA1400 and related robot models. Verify the backplane slot designation before installation.
Q: Is JANCD-XIO02 a direct replacement for JARCR-XOI01?
A: Not always. While both are I/O expansion boards, connector pinouts and firmware handshake protocols may differ. Contact Konmask for a verified cross-reference.
Q: What is the difference between JARCR-XOI01 and JARCR-XOI02?
A: The XOI02 is a revised version with minor PCB changes for later XRC production runs. Functionally equivalent in most cases, but confirm with your controller revision.
Q: Do you supply tested used units?
A: Yes. Konmask.com offers new, refurbished, and tested-used JARCR-XOI01 boards. All used units are electrically tested and include a warranty.
Q: Can I get a datasheet or wiring diagram?
A: Yes. Contact support@konmask.com with your order or inquiry and we will provide available technical documentation.
