Yaskawa YRC1000 + GP8 – High-Speed 6-Axis Industrial Robot System | Motoman Series
Engineering Background: The Yaskawa Motoman GP8 paired with the YRC1000 controller represents Yaskawa’s fourth-generation compact robot platform, engineered for high-throughput manufacturing environments where speed, precision, and compact footprint are critical. Introduced as part of the GP-series lineup, this system supersedes the legacy MH5/MH6 family with a 30% reduction in cycle time and a significantly lighter arm structure.
Product Positioning: Designed for procurement engineers sourcing a proven, high-reliability 6-axis robot system for assembly, material handling, machine tending, and inspection applications. The YRC1000 controller’s compact 598×490×427mm cabinet integrates seamlessly into space-constrained workcells. Available as a complete verified system from Konmask.com with full traceability documentation.
Complete Technical Specifications
| Parameter | Specification |
|---|---|
| Model (Robot) | Yaskawa Motoman GP8 |
| Model (Controller) | Yaskawa YRC1000 |
| Series / Platform | Motoman GP Series |
| Axes | 6 (S, L, U, R, B, T) |
| Payload Capacity | 8 kg |
| Maximum Reach | 727 mm |
| Repeatability | ±0.02 mm |
| Robot Mass | Approx. 130 kg |
| System Gross Weight | 323 kg (robot + controller + cables) |
| Controller Dimensions | 598 × 490 × 427 mm (W×H×D) |
| Controller Mass | Approx. 60 kg |
| Power Supply | 3-phase AC 200–480V, 50/60Hz |
| Power Consumption | 1.5 kVA (typical) |
| Ambient Temperature | 0–45°C (operating) |
| Protection Rating | IP54 (robot arm) |
| Programming Language | INFORM III |
| I/O Points | 40 DI / 40 DO (standard); expandable |
| Communication | EtherNet/IP, DeviceNet, PROFIBUS, CC-Link (optional) |
| Country of Origin | Japan |
| HS Code Reference | 8479.50 (Industrial Robots) |
Proven Application Environments
- Assembly & Sub-Assembly: Electronics PCB handling, small-part assembly lines requiring ±0.02mm positional accuracy
- Machine Tending: CNC lathe/milling loading/unloading with short cycle times (<0.5s for short-stroke moves)
- Material Handling: Pick-and-place, palletizing, and bin-picking with vision integration
- Inspection & Testing: Camera-guided inspection cells, force-controlled testing fixtures
- Welding Preparation: Part positioning and fixture loading for MIG/TIG welding workcells
- Cleanroom-Adjacent: Suitable for ISO Class 6+ environments with appropriate end-effector selection
Engineering Advantages
- Compact YRC1000 Controller: 40% smaller footprint vs. prior-generation DX200, enabling cabinet-integrated or floor-mount installation
- High-Speed Cycle Performance: 0.37s cycle time (25mm stroke, ISO 9283 standard), outperforming comparable 8kg-class robots
- Unified Software Ecosystem: Compatible with MotoSim EG-VRC offline simulation, MotoPlus SDK for custom application development
- Functional Safety (FS): Integrated dual-channel safety monitoring; SIL2/PLd compliant without external safety PLC
- Wrist Flexibility: ±360° T-axis rotation enables complex tool orientations without singularity interruption
- Cable Management: Internal wrist cabling reduces wear and simplifies end-effector integration
System Architecture & Signal Flow
The GP8 arm communicates with the YRC1000 controller via a proprietary high-speed serial bus (SERCOS-based) over a single composite cable (power + signal). The YRC1000 houses the motion CPU, safety CPU, and I/O expansion rack in a unified chassis. Field device integration is achieved through the front-panel I/O terminal block or optional fieldbus interface boards (EtherNet/IP, PROFIBUS-DP, DeviceNet). The teach pendant (YPU) connects via USB-C and provides full INFORM III programming, job management, and real-time monitoring. External PLC coordination is typically implemented via EtherNet/IP or hardwired DI/DO for start/stop/alarm signals.
Sourcing & Quality Verification
- Source: Decommissioned from controlled manufacturing environments; full operational history available on request
- Inspection Standard: Each unit undergoes power-on functional test, axis calibration verification, and controller diagnostic scan prior to shipment
- Documentation: Original Yaskawa manuals (YRC1000 Maintenance Manual, GP8 Instructions), calibration records, and CE/UL declaration of conformity available
- Traceability: Serial number verified against Yaskawa production database; no counterfeit risk
- Warranty: 90-day operational warranty from Konmask; extended coverage available
Procurement Process
- Inquiry: Submit RFQ via support@konmask.com with required quantity, delivery timeline, and destination port
- Quotation: Formal quotation with CIF/FOB pricing issued within 24 business hours
- Order Confirmation: Pro-forma invoice issued; 30% deposit to confirm allocation
- Inspection & Documentation: Pre-shipment inspection report and photos provided; third-party inspection available
- Shipping: LCL/FCL sea freight or air freight; export customs clearance handled by Konmask logistics team
- After-Sales: Remote commissioning support, spare parts sourcing, and on-site service coordination available
Technical FAQ
Q: Is the YRC1000 compatible with older Motoman robot arms (e.g., MH6, MA1400)?
A: No. The YRC1000 uses a new servo amplifier architecture and is only compatible with GP-series, HC-series, and select newer Motoman arms. Legacy DX200/NX100 arms require their respective controllers.
Q: Can the GP8 be ceiling or wall mounted?
A: Yes. The GP8 supports floor, ceiling (inverted), and wall-mount configurations. Load ratings and reach envelopes vary by mounting orientation — consult the GP8 installation manual for axis torque limits.
Q: What fieldbus options are available for the YRC1000?
A: Standard: EtherNet/IP (built-in). Optional interface boards: PROFIBUS-DP, DeviceNet, CC-Link, PROFINET. Boards must be specified at order time or retrofitted by a qualified Yaskawa integrator.
Q: What is the lead time for this system?
A: In-stock units ship within 5–10 business days after order confirmation. Contact us for current inventory status.
Q: Does Konmask provide integration support?
A: Yes. We offer remote commissioning guidance, INFORM III programming consultation, and can coordinate with local Yaskawa-certified integrators in your region.
