YOKOGAWA ADV561-P11 S1 Digital Output Module | Replacement, Equivalent & Selection Guide
The YOKOGAWA ADV561-P11 S1 is a high-reliability digital output module designed for use within YOKOGAWA’s CENTUM VP and CS 3000 distributed control systems (DCS). This page provides full technical specifications, compatible replacement models, application guidance, and sourcing information to support engineers and procurement teams in making accurate selection decisions.
Technical Specifications
- Model: ADV561-P11 S1
- Manufacturer: YOKOGAWA Electric Corporation
- Module Type: Digital Output (DO)
- Output Points: 16 points (typical for ADV561 series)
- Output Type: Transistor (sink/source, model-dependent)
- Rated Voltage: 24 VDC
- Isolation: Optical isolation between field and system bus
- Communication: Vnet/IP or ESB bus (system-dependent)
- Mounting: DIN rail / node unit slot
- Weight: Approx. 300 g
- Operating Temperature: 0°C to 55°C
- Compliance: CE, UL (refer to YOKOGAWA datasheet for full certifications)
Note: Always verify specifications against the official YOKOGAWA datasheet and your system’s I/O module list before procurement.
Compatible Replacement & Equivalent Models
When the ADV561-P11 S1 is discontinued, out of stock, or requires a cost-effective alternative, the following models may be considered as functional equivalents or replacements. Compatibility must be validated against your specific system revision and firmware version.
- YOKOGAWA ADV561-P11 S2 – Revised suffix variant; verify firmware and terminal block compatibility
- YOKOGAWA ADV551-P11 – Alternative DO module within CENTUM VP; check point count and output type
- YOKOGAWA ADV161-P11 – Compact DO module; suitable for lower-density applications
- YOKOGAWA AAV541-S00 – Analog output alternative if application allows signal type change
- Third-party DCS DO modules – Consult Konmask engineering team for cross-brand compatibility assessment
Important: Replacement modules must match the node unit slot type, output signal type, and system bus protocol. Always perform a loop check after substitution.
Why Choose the Original Model
- Guaranteed system compatibility – Factory-validated for CENTUM VP / CS 3000 environments
- Proven field reliability – Widely deployed in petrochemical, power, and process industries
- Full YOKOGAWA support – Firmware updates, diagnostics, and technical documentation available
- Reduced integration risk – No re-engineering of I/O assignments or control logic required
- Traceability – Original serial number and factory test records for audit compliance
Typical Applications
- Oil & gas upstream/downstream process control
- Chemical and petrochemical plant automation
- Power generation and utilities
- Pharmaceutical batch control systems
- Pulp, paper, and continuous manufacturing
- Water treatment and environmental monitoring
System Compatibility
- YOKOGAWA CENTUM VP (R4.xx and above – verify with release notes)
- YOKOGAWA CS 3000 (compatible node units)
- Node Unit: ANB10D, ANR10D, or equivalent (confirm slot type)
- Engineering Tool: CENTUM VP Builder / CS 3000 Builder
- Bus Protocol: ESB / Vnet/IP (model suffix determines bus type)
Suffix “-P11” typically denotes a specific terminal block and wiring configuration. Confirm suffix compatibility with your node unit before ordering.
Selection Guide
Use the following criteria to confirm the ADV561-P11 S1 is the correct module for your application:
- Step 1 – Identify DCS platform: Confirm CENTUM VP or CS 3000 and system revision
- Step 2 – Check node unit type: Match the module to the correct node unit slot (ANB/ANR series)
- Step 3 – Verify output type: Transistor sink vs. source; match field device requirements
- Step 4 – Count I/O points: Confirm 16-point capacity meets your loop count
- Step 5 – Check suffix: “-P11” = specific terminal block; “-S1” = style/revision indicator
- Step 6 – Review certifications: Confirm CE/UL/ATEX requirements for your installation zone
- Step 7 – Contact Konmask: Submit your I/O list or system drawing for expert verification
Quality Assurance & Sourcing
- All modules sourced through Konmask.com undergo visual inspection and functional pre-shipment checks
- Original factory packaging and labels preserved where available
- Traceability documentation (COO, test reports) provided on request
- New, refurbished, and surplus stock options available – clearly labeled at time of quotation
- Export compliance screening performed for all international orders
How to Order
- Email: support@konmask.com with model number, quantity, and required delivery date
- Phone/WhatsApp: +0086 19859288691
- Online: Add to cart directly on this page, or request a formal quotation
- Lead time: typically 3–15 business days depending on stock status
- Bulk and project pricing available – contact us for volume discounts
Replacement & Compatibility FAQ
Q: Can I use ADV561-P11 S2 instead of S1?
A: The suffix “S1” vs “S2” typically denotes a hardware revision. In many cases they are interchangeable, but you must verify with YOKOGAWA’s compatibility matrix or contact Konmask for confirmation.
Q: Is this module compatible with CENTUM VP R6?
A: Compatibility depends on the node unit and firmware version. Please provide your system revision when inquiring.
Q: Do you supply refurbished units?
A: Yes. All refurbished units are clearly identified and tested. New OEM stock is also available subject to lead time.
Q: Can this module be used in a safety instrumented system (SIS)?
A: The ADV561-P11 S1 is a standard DCS I/O module and is not SIL-rated. For SIS applications, consult YOKOGAWA’s ProSafe-RS product line.
Q: What is the warranty on your supplied modules?
A: Konmask provides a standard 90-day warranty on all supplied modules. Extended warranty options are available on request.
