YOKOGAWA ADV151-P00 S2 — 32-Channel Digital Input Module | CENTUM VP / CS 3000 DCS Platform
Engineering Background
The ADV151-P00 S2 is a field-proven digital input (DI) module designed for Yokogawa’s CENTUM VP and CS 3000 Distributed Control Systems — the backbone of process automation in refining, petrochemical, power generation, and pharmaceutical plants worldwide. As a core I/O component of the CENTUM platform, it provides reliable, high-density discrete signal acquisition from field devices including limit switches, pushbuttons, relay contacts, and proximity sensors.
Product Positioning
Procurement engineers sourcing replacement or expansion I/O for CENTUM VP / CS 3000 systems will find the ADV151-P00 S2 to be a direct, plug-compatible solution. Konmask.com maintains verified stock of this module, supporting both emergency MRO procurement and planned capital project builds. Every unit is inspected against Yokogawa’s published specifications before dispatch.
Complete Technical Specifications
| Part Number | ADV151-P00 S2 |
| Manufacturer | YOKOGAWA Electric Corporation |
| Module Type | Digital Input (DI) |
| Compatible Platform | CENTUM VP, CENTUM CS 3000 |
| Number of Channels | 32 channels |
| Input Signal Type | Dry contact / Wet contact (voltage-free or voltage input) |
| Input Voltage Range | 24 V DC (nominal) |
| Isolation | Optical isolation between field and system bus |
| Scan Cycle | Synchronized with FCS (Field Control Station) scan period |
| Module Weight | 240 g |
| Mounting | Nest-mount (CENTUM I/O nest, hot-swap capable) |
| Communication Bus | Internal CENTUM V-net / ESB bus |
| Redundancy Support | Supports dual-redundant I/O configuration |
| Diagnostic Functions | Online self-diagnostics, LED status indication per channel |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -20 °C to +60 °C |
| Humidity | 5% to 95% RH (non-condensing) |
| Certifications | CE, UL (per Yokogawa platform certification) |
| SKU / Part Reference | ADV151-P00 S2 |
Proven Application Environments
- Oil & Gas: Upstream wellhead control, downstream refinery unit operations, compressor station monitoring
- Petrochemical: Reactor interlock systems, valve position feedback, motor run/stop status acquisition
- Power Generation: Turbine control auxiliaries, switchgear status monitoring, BOP (Balance of Plant) I/O
- Pharmaceutical / Fine Chemical: Batch process DI acquisition, clean-room equipment status, GMP-compliant control loops
- Pulp & Paper / Water Treatment: Pump and agitator status, level switch inputs, sequential logic control
Engineering Advantages
- High Channel Density: 32 DI channels per module slot minimizes nest space and reduces wiring infrastructure cost
- Hot-Swap Capability: Module can be replaced under power without shutting down the FCS, supporting zero-downtime maintenance
- Optical Isolation: Full galvanic isolation protects the DCS backplane from field-side transients, ground loops, and surge events
- Dual-Redundancy Ready: Supports Yokogawa’s dual-redundant I/O architecture for SIL-rated and high-availability applications
- Integrated Diagnostics: Per-channel LED indicators and online self-test routines reduce MTTR and simplify commissioning
- Platform Longevity: CENTUM VP is Yokogawa’s current-generation DCS; CS 3000 modules remain in active MRO demand globally
System Architecture & Signal Flow
The ADV151-P00 S2 mounts into a standard CENTUM I/O nest and communicates with the Field Control Station (FCS) via the internal ESB (Extended Serial Bus) or V-net backplane. Field wiring terminates at the module’s front-face terminal block or via a marshalling cabinet with pre-wired cables. Each of the 32 channels is individually optically isolated, with the on-board ASIC scanning all inputs synchronously and presenting the digital state to the FCS at each control scan cycle. The FCS then makes the data available to the HIS (Human Interface Station) and historian via the Vnet/IP control network.
Signal path: Field device → Terminal block → Optical isolator → Channel ASIC → ESB backplane → FCS CPU → Vnet/IP → HIS / Historian
Sourcing & Quality Verification
- All ADV151-P00 S2 units listed on Konmask.com are sourced from authorized distributors, decommissioned plant inventories, or verified surplus channels with documented provenance
- Each module undergoes visual inspection (PCB, connectors, label integrity) and functional power-on verification prior to listing
- Original Yokogawa firmware revision and hardware suffix (S2) are confirmed and documented
- Units are shipped in anti-static packaging with desiccant; ESD-safe handling throughout the fulfillment process
- Certificates of conformance and inspection reports available upon request for regulated industries
Procurement Process
- Step 1 — Inquiry: Submit your BOM or part number via the product page or email support@konmask.com with quantity and required delivery window
- Step 2 — Quote: Konmask issues a formal quotation within 1 business day including unit price, lead time, and shipping options
- Step 3 — Order Confirmation: Purchase order accepted via the online store, email PO, or bank transfer (T/T); VAT invoices issued
- Step 4 — Dispatch: Modules are packed, photographed, and dispatched with tracking; DHL / FedEx / SF Express available for international shipments
- Step 5 — After-Sales: 90-day warranty on all verified units; technical support available for installation and commissioning queries
Technical FAQ
Q: Is the ADV151-P00 S2 compatible with both CENTUM VP and CS 3000?
A: Yes. The ADV151 series I/O modules are cross-compatible across CENTUM CS 3000 and CENTUM VP platforms, subject to FCS firmware version. Consult your FCS release notes or contact Konmask for compatibility confirmation.
Q: Can this module be used in a redundant I/O configuration?
A: Yes. The ADV151-P00 S2 supports Yokogawa’s dual-redundant I/O pairing when installed in a redundant nest with a paired module and appropriate FCS configuration.
Q: What is the difference between the S1 and S2 hardware suffix?
A: The S2 suffix denotes the second hardware revision, which includes minor PCB and component updates for improved reliability and EMC performance. S2 is the current production standard.
Q: Do you provide a test report or certificate of conformance?
A: Yes. Inspection reports and certificates of conformance are available upon request. Please specify your requirement at the time of order.
Q: What is the lead time for in-stock units?
A: In-stock units typically ship within 1–3 business days. For large quantities or urgent requirements, contact support@konmask.com directly.
Q: Can I return a module if it is not compatible with my system?
A: Konmask accepts returns within 14 days for unused, uninstalled modules in original packaging. Please review our returns policy or contact support before ordering if compatibility is uncertain.
