Motion Control Solution – YOKOGAWA F3NC1Z-ON-Z01 | FA-M3 Series Position Module
Where This Product Is Used
The YOKOGAWA F3NC1Z-ON-Z01 is a high-performance position module designed for the FA-M3 programmable controller platform. It is widely deployed in applications demanding precise axis positioning and coordinated motion control:
- CNC Machine Tools – Multi-axis servo coordination for milling, turning, and grinding centers
- Semiconductor & Electronics Manufacturing – Die bonding, wafer handling, and pick-and-place systems requiring sub-micron repeatability
- Automotive Assembly Lines – Robotic welding positioners, press-fit stations, and transfer systems
- Packaging Machinery – High-speed indexing, filling, and labeling lines with synchronized motion profiles
- Printing & Converting Equipment – Register control and tension management on web-fed presses
- Material Handling & Logistics – Stacker cranes, AS/RS systems, and precision conveyor positioning
- Process Industries – Valve positioners and actuator control in oil & gas, chemical, and power generation plants
Technical Specifications
| Attribute | Value |
|---|---|
| Part Number / SKU | F3NC1Z-ON-Z01 |
| Manufacturer | YOKOGAWA Electric Corporation |
| Series / Platform | FA-M3 (STARDOM / Sequence CPU compatible) |
| Module Type | Position / Motion Control Module |
| Controlled Axes | Up to 1 axis (single-axis positioning) |
| Command Interface | FA-M3 backplane bus |
| Output Type | Pulse train output (open collector / line driver) |
| Encoder Input | Incremental encoder (A/B/Z phase) |
| Max Pulse Output Frequency | 500 kpps |
| Positioning Resolution | 32-bit counter |
| Operating Temperature | 0 °C to 55 °C |
| Storage Temperature | -20 °C to 70 °C |
| Power Consumption | Supplied via FA-M3 backplane (5 VDC) |
| Weight | Approx. 2,140 g (module + packaging) |
| Compliance | CE, UL, cUL |
| Country of Origin | Japan |
Specifications are based on YOKOGAWA published datasheets. Contact us to confirm the latest revision details.
Why Engineers Specify This Model
- Native FA-M3 Integration – Slots directly into any FA-M3 base unit; no external motion controller or gateway required, reducing panel footprint and wiring complexity.
- High-Speed Pulse Output – 500 kpps maximum output supports high-resolution servo drives without sacrificing cycle time.
- 32-Bit Position Counter – Eliminates counter overflow issues in long-travel or high-resolution applications.
- Deterministic Scan Cycle – Synchronized with the FA-M3 CPU scan for tight real-time control loops.
- Proven Reliability – YOKOGAWA FA-M3 hardware is field-proven in mission-critical process and discrete manufacturing environments worldwide.
- Simplified Programming – Configured via YOKOGAWA’s WideField3 / ToolBox software with dedicated function blocks, reducing commissioning time.
Complete System Bill of Materials
For a complete FA-M3 motion control system using the F3NC1Z-ON-Z01, engineers typically specify:
- FA-M3 CPU Module (e.g., F3SP71-4S or F3SP76-7S)
- FA-M3 Base Unit (e.g., F3BU04-0N, F3BU06-0N, or F3BU13-0N)
- FA-M3 Power Supply Module (e.g., F3PU20-0S)
- F3NC1Z-ON-Z01 Position Module (this item)
- Compatible Servo Drive (YOKOGAWA or third-party with pulse/direction interface)
- Incremental Encoder (matched to servo motor)
- FA-M3 I/O Modules for digital/analog I/O as required
- WideField3 Programming Software License
Contact support@konmask.com for bundle pricing on complete system configurations.
Compliance & Industry Standards
- CE Marking – Compliant with EU Machinery Directive and EMC Directive
- UL / cUL Listed – Recognized for use in North American industrial control panels
- RoHS Compliant – Meets EU Directive 2011/65/EU on restriction of hazardous substances
- IEC 61131-2 – Programmable controllers hardware requirements
- SEMI Standards – Suitable for semiconductor equipment integration per SEMI E10 / E30 guidelines
Quality Assurance & Sourcing
- All units sourced from authorized YOKOGAWA distributors or verified secondary-market suppliers with documented chain of custody.
- Each module undergoes incoming inspection including visual examination, label verification, and functional power-on check prior to shipment.
- Serialized tracking maintained for full traceability.
- 30-day return window for DOA (Dead on Arrival) units with RMA authorization.
- Konmask.com specializes in industrial automation components for B2B buyers — we do not sell consumer-grade or counterfeit parts.
How to Source This Part
- Add to Cart – Click “Add to Cart” for standard in-stock orders. Lead time is typically 3–7 business days for international shipping.
- Request a Quote – For volume orders (5+ units), OEM projects, or system configurations, email support@konmask.com for a formal quotation within 24 hours.
- Urgent Requirements – Call or WhatsApp +0086 19859288691 for same-day response on critical spares.
- Export & Customs – We handle export documentation (commercial invoice, packing list, COO) for international buyers. HS Code: 8537.10 (programmable controllers).
Application-Specific FAQ
Q: Is the F3NC1Z-ON-Z01 compatible with all FA-M3 base units?
A: Yes, it is compatible with all standard FA-M3 base units (F3BU04, F3BU06, F3BU13, etc.) as long as the base unit has an available slot and the power budget is not exceeded.
Q: Can this module control a servo drive with an analog ±10 V command interface?
A: No. The F3NC1Z-ON-Z01 outputs pulse train (pulse + direction or CW/CCW). For analog command output, consider the YOKOGAWA F3NC32-0N analog position module.
Q: What programming software is required?
A: YOKOGAWA WideField3 (or ToolBox FA) is required for configuration and ladder/function block programming. Contact us if you need software licensing assistance.
Q: Do you provide a warranty?
A: We offer a 90-day functional warranty on all modules. Extended warranty options are available for volume orders — contact us for details.
Q: Can you supply the full FA-M3 system (CPU + base + I/O + position module)?
A: Yes. Konmask.com stocks a wide range of FA-M3 components. Send your BOM to support@konmask.com and we will provide a consolidated quote.
