YOKOGAWA F3XD08-6N 8-Point Digital Input Module | Replacement, Equivalent & Selection Guide
The YOKOGAWA F3XD08-6N is an 8-point DC digital input module designed for the YOKOGAWA FA-M3 / FA-M3R programmable logic controller (PLC) platform. It accepts 24 VDC sink/source signals and is widely deployed in process automation, manufacturing lines, and utility control systems. This page provides full technical specifications, compatible replacement options, application guidance, and sourcing information to help engineers and procurement teams make confident decisions.
Technical Specifications
- Model: F3XD08-6N
- Manufacturer: YOKOGAWA Electric Corporation
- Series: FA-M3 / FA-M3R
- Module Type: Digital Input (DI)
- Number of Input Points: 8 points
- Input Voltage: 24 VDC
- Input Type: Sink / Source (NPN/PNP compatible)
- Isolation: Photocoupler isolation
- Response Time: Approx. 1 ms (ON→OFF / OFF→ON)
- Operating Temperature: 0 °C to 55 °C
- Storage Temperature: −20 °C to 70 °C
- Relative Humidity: 10 % to 90 % RH (non-condensing)
- Weight: Approx. 1,480 g (module + packaging)
- Mounting: FA-M3 base unit slot
- Certifications: CE, UL (refer to YOKOGAWA datasheet for current listing)
Compatible Replacement & Equivalent Models
When the F3XD08-6N is unavailable or end-of-life, the following models may serve as functional equivalents. Always verify electrical and mechanical compatibility before substitution.
- YOKOGAWA F3XD16-6N – 16-point version; same voltage class, expanded I/O count
- YOKOGAWA F3XD32-6N – 32-point high-density digital input; same FA-M3 platform
- YOKOGAWA F3XD08-3N – 8-point variant with different connector type; verify pinout
- YOKOGAWA F3XD08-6H – High-speed input variant; suitable for encoder/pulse applications
- Third-party FA-M3 compatible modules – Consult Konmask for vetted alternatives with full compatibility verification
Note: Cross-brand substitution requires firmware and base-unit compatibility checks. Contact our technical team for assistance.
Why Choose the Original F3XD08-6N
- Guaranteed FA-M3 compatibility – Native integration with YOKOGAWA CPU modules, no configuration workarounds
- Proven reliability – Photocoupler isolation protects against field-side transients and ground loops
- Consistent response time – 1 ms typical response ensures deterministic control loop performance
- Long-term support – YOKOGAWA provides extended lifecycle support and spare-parts availability
- Regulatory compliance – CE/UL marks simplify system certification in regulated industries
Typical Applications
- Process plant DCS/PLC hybrid architectures (oil & gas, petrochemical, power generation)
- Discrete manufacturing: conveyor control, machine interlocking, safety circuits
- Water & wastewater treatment plant automation
- Pharmaceutical batch control systems
- Building management and HVAC control panels
- Utility substation monitoring and control
System Compatibility
- Compatible PLC Platform: YOKOGAWA FA-M3 / FA-M3R series
- Compatible Base Units: F3BU04-0N, F3BU06-0N, F3BU13-0N, F3BU16-0N (and variants)
- Compatible CPU Modules: F3SP22-0S, F3SP28-3N, F3SP38-6N, F3SP53-4H, F3SP58-6S, F3SP67-6S, F3SP76-7S (and others)
- Programming Software: YOKOGAWA WideField3 / WideField2
- Communication: Via CPU module (Ethernet, RS-232C, RS-485 depending on CPU)
Selection Guide
Use the criteria below to confirm the F3XD08-6N is the right module for your application, or to identify a suitable alternative:
- I/O Point Count: Need exactly 8 DI points → F3XD08-6N ✓ | Need 16 points → F3XD16-6N | Need 32 points → F3XD32-6N
- Signal Voltage: 24 VDC field signals → F3XD08-6N ✓ | 100–120 VAC signals → consider F3XD08-1N
- Wiring Type: Sink or source (NPN/PNP) → F3XD08-6N ✓ (dual-polarity)
- Response Speed: Standard control (≥1 ms) → F3XD08-6N ✓ | High-speed pulse/encoder → F3XD08-6H
- Connector Style: Confirm terminal block type matches existing wiring harness
- Slot Availability: Verify available slots on your FA-M3 base unit before ordering
Quality Assurance & Sourcing
- Authentic parts only – All YOKOGAWA modules at Konmask.com are sourced from authorized distributors or verified surplus channels with full traceability
- Inspection & testing – Each unit undergoes visual inspection and functional verification before shipment
- Warranty – 12-month warranty against manufacturing defects; replacement or refund policy applies
- Documentation – Datasheet, wiring diagram, and certificate of conformance available on request
- Export compliance – Proper HS code classification and export documentation provided for international orders
How to Order
- Step 1: Confirm your FA-M3 base unit model and available slot count
- Step 2: Verify field wiring voltage (24 VDC) and signal polarity (NPN/PNP)
- Step 3: Add YOKOGAWA F3XD08-6N to cart or contact us for bulk/project pricing
- Step 4: Provide your shipping address — we ship worldwide with DHL, FedEx, and UPS
- Step 5: Receive tracking number and documentation within 1 business day of dispatch
For urgent requirements or large-quantity orders, email [email protected] or call +0086 19859288691 for priority handling.
Replacement & Compatibility FAQ
Q: Can I replace F3XD08-6N with F3XD16-6N without changing the program?
A: The F3XD16-6N occupies the same slot but maps 16 points. You must update the I/O assignment in WideField3 and verify that unused points do not trigger unintended logic.
Q: Is F3XD08-6N compatible with the older FA-M3 (non-R) base units?
A: Yes, the F3XD08-6N is compatible with both FA-M3 and FA-M3R base units. Confirm the base unit firmware version supports the module revision you receive.
Q: Can I mix NPN and PNP field devices on the same F3XD08-6N module?
A: The F3XD08-6N supports both sink (NPN) and source (PNP) wiring per point, but all points share a common terminal. Mixing polarity types on the same module is not recommended without consulting the wiring diagram.
Q: What is the lead time for F3XD08-6N?
A: In-stock units ship within 1–3 business days. For out-of-stock situations, typical lead time is 2–6 weeks depending on sourcing channel. Contact us for real-time availability.
Q: Do you provide a certificate of authenticity?
A: Yes. A certificate of conformance and sourcing documentation are available upon request for all orders.
