Genuine YOKOGAWA F3DA04-ON Analog Input/Output Module | FA-M3 Series – Verified Source
The YOKOGAWA F3DA04-ON is a high-precision Analog Input/Output Module designed for the FA-M3 Range-free Multi-controller platform. Sourced directly through verified supply channels, this module delivers the signal conditioning accuracy and reliability that process engineers demand in mission-critical automation environments.
Technical Specifications
| Part Number | F3DA04-ON |
| Manufacturer | YOKOGAWA Electric Corporation |
| Series | FA-M3 Range-free Multi-controller |
| Module Type | Analog Input/Output (Mixed I/O) |
| Analog Inputs | 4 channels |
| Analog Outputs | 4 channels |
| Input Signal Range | 4–20 mA / 1–5 V / 0–10 V (configurable) |
| Output Signal Range | 4–20 mA / 1–5 V / 0–10 V (configurable) |
| Resolution | 16-bit |
| Isolation | Channel-to-channel isolated |
| Power Consumption | Refer to FA-M3 system documentation |
| Operating Temperature | 0°C to 55°C |
| Weight | Approx. 1,480 g (with packaging) |
| Compliance | CE, UL, cUL |
Our 4-Step Quality Verification Process
Every YOKOGAWA module shipped from Konmask.com passes through a rigorous 4-step verification protocol before dispatch:
- Origin Traceability Check — We verify the supply chain documentation and manufacturer batch records for every unit to confirm authentic YOKOGAWA origin.
- Physical Inspection — Trained technicians inspect labeling, housing integrity, connector condition, and firmware version stamps against YOKOGAWA factory standards.
- Functional Bench Test — Where applicable, modules are powered up and signal I/O is verified against published YOKOGAWA specifications.
- Secure Packaging & Documentation — Units are packed in anti-static, moisture-resistant packaging with a quality inspection certificate included in every shipment.
Key Features & Benefits
- 16-bit resolution for high-accuracy analog signal processing
- Mixed I/O design reduces slot count and simplifies cabinet layout
- Channel-to-channel isolation eliminates ground loop interference
- Flexible signal range configuration supports diverse field instruments
- Seamless integration with FA-M3 CPU modules and engineering software
- Hot-swap capable (system-dependent) for minimal downtime maintenance
- Compact form factor optimized for high-density rack installations
Typical Applications
- Oil & Gas — Flow transmitter signal conditioning in pipeline SCADA systems
- Chemical Processing — Pressure and temperature loop control in batch reactors
- Power Generation — Turbine governor analog feedback and setpoint output
- Water Treatment — pH, dissolved oxygen, and flow rate monitoring and control
- Pharmaceutical — Validated analog I/O for GMP-compliant process control
- Food & Beverage — Temperature profiling and dosing control in continuous processes
Compatible System Components
- FA-M3 CPU Modules: F3SP22-0S, F3SP28-3S, F3SP38-6S, F3SP53-4H, F3SP58-6H, F3SP67-6S
- FA-M3 Base Units: F3BU04-0N, F3BU06-0N, F3BU13-0N
- Power Supply Modules: F3PU20-0S, F3PU10-0S
- YOKOGAWA FAST/TOOLS SCADA and Exaopc OPC server
- WideField3 Engineering Software (ladder / function block programming)
Global Sourcing & Shipping Capabilities
Konmask.com maintains an active global procurement network for YOKOGAWA FA-M3 components, including both current-production and legacy/discontinued modules. We ship worldwide with the following capabilities:
- Lead Time: In-stock units ship within 1–3 business days; sourced units typically 7–21 business days
- Shipping Methods: DHL Express, FedEx International Priority, UPS Worldwide, sea freight for bulk orders
- Export Documentation: Commercial invoice, packing list, certificate of origin, and CITES/EX declarations as required
- Customs Support: HS Code 8537.10 — we assist with import classification documentation
- Regions Served: Asia-Pacific, Europe, Middle East, Americas, Africa
Certifications & Compliance Statement
The YOKOGAWA F3DA04-ON is manufactured under YOKOGAWA’s ISO 9001-certified quality management system. Konmask.com operates as an independent distributor and does not represent YOKOGAWA Electric Corporation as an authorized reseller unless explicitly stated. All products are sourced through legitimate secondary market or authorized distribution channels and are sold as genuine OEM hardware.
- CE Marking — EMC Directive 2014/30/EU compliant
- UL / cUL Listed — suitable for North American installations
- RoHS Compliant — YOKOGAWA factory declaration
- ISO 9001:2015 — YOKOGAWA manufacturing quality system
How to Order
- Confirm Part Number — Verify F3DA04-ON matches your FA-M3 system revision and I/O requirements.
- Request a Quote — Email [email protected] with your required quantity, delivery address, and any urgency requirements.
- Review Proforma Invoice — We issue a proforma invoice with unit price, shipping cost, and lead time within 24 business hours.
- Confirm Payment — We accept T/T bank transfer, PayPal, and major credit cards for verified buyers.
- Dispatch & Tracking — Your order ships with full tracking and insurance. We send dispatch notification with AWB number.
Authenticity & Trust FAQ
Q: Are these genuine YOKOGAWA modules?
A: Yes. All units are genuine OEM YOKOGAWA hardware sourced through verified supply channels. We do not sell counterfeit, refurbished-as-new, or third-party compatible substitutes.
Q: Can you provide test reports or inspection certificates?
A: Yes. A quality inspection certificate is included with every shipment. Detailed test reports are available upon request for orders of 3+ units.
Q: What warranty do you offer?
A: We offer a 90-day return-to-base warranty covering manufacturing defects. Extended warranty options are available — contact us for details.
Q: Do you support urgent or emergency procurement?
A: Yes. Contact us directly at +0086 19859288691 for expedited sourcing and same-day quotation on urgent requirements.
Q: Can I order a single unit?
A: Yes. We supply single units through to bulk orders. Pricing scales with quantity — request a quote for volume pricing.
